Auto LANstreamer PCI Adapter
04H8095
Installation Guide
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing, performance, or use
of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft
Corporation.
MMXTM is a trademark of Intel Corporation.
Pentium® is a registered trademark of Intel Corporation.
Hewlett-Packard France
Commercial Desktop Computing Division
38053 Grenoble Cedex 9
France
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
1 Connecting to a Netware 3.12 Server
Windows for
Workgroups
Requirements
• HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed.
• IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.01.
• Driver Name: IBMMPC.DOS Size: 59KB Date: 5/22/95
• Novell Netware server that supports Net BEUI, NWLink IPX/SPX, and
NWLink NetBIOS transfer protocols.
• Netware client for DOS and MS-Windows.
Device Configuration
• Interrupt 9 (2)
• I/O Address FCC0-h
Procedure
1With the HP Vectra turned off install the IBM LANStreamer 16/4 PCI TR
adapter card into a PCI slot.
2Insert the IBM LANStreamer TR drivers disk 1 of 6 (AUTO LANStreamer
PCI Diagnostic Disk) and power on the machine.
3After the machine boots, verify that the adapter finished testing and that
the adapter is “OK.”
4Click on “F3” to exit, and then press “CTRL+ALT+DEL.”
5Boot the machine to a DOS prompt, and Netware client for DOS and MS-
Windows disk 1.
6Execute INSTALL.EXE and set lines 1-5 as listed below;
• C:\NWCLIENT
•YES
•YES
C:\WINDOWS
•NO
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
• IBM Auto LANStreamer PCI Adapter (use the driver on disk 3 of 5, Net-
ware DOS requester Installation disk)
7Highlight option 6 to continue with installation.
8When prompted, insert the corresponding disks to complete file transfer
and driver installation.
9When the install utility is finished, press <CRTL><ALT><DEL> to restart
the machine.
10 After windows loads, open the “NETWORK” folder, and double-click the
“NETWORK SETUP” icon.
11 Select “Networks” and verify that “Novell Netware (Workstation Shell 4.0
and above)” is selected under “Install Windows support for the following
network only:”
12 Click on “OK” twice and the installation is complete.
1 Connecting to Netware 3.12 Server
Windows 95 SR2
Windows 95 SR2 Requirements
• HP Vectra with Windows 95 SR2 installed.
• IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.01.
• Driver Name: Windows 95 Default
• Novell Netware server that supports Net BEUI, NWLink IPX/SPX, and
NWLink NetBIOS transfer protocols.
Device Configuration
• Interrupt 9 (2)
• I/O Address FCC0-h
Procedure
1With the HP Vectra turned off install the IBM LANStreamer 16/4 PCI TR
adapter card into a PCI slot.
2Insert the IBM LANStreamer TR drivers disk 1 of 6 (AUTO LANStreamer
PCI Diagnostic Disk) and power on the machine.
3After the machine boots, verify that the adapter finished testing and that
the adapter is “OK.”
4Click on “F3” to exit, and then press “CTRL+ALT+DEL.”
5Upon booting, Windows 95 will automatically recognize the adapter. Click
on “Next.”
6When prompted, click on “Other Locations.”
7Insert drivers disk 4 of 6 (Auto LANStreamer PCI NDIS 3.0 Driver
Diskette), set the path to “A:\” and click “OK.” (If you have an HP
preloaded HDD, set the path to “C:\LANDRV\LNSTRM\DISK4\”)
8Verify that “IBM Auto LANStreamer PCI Adapter (NDIS3)” is listed and
click on “Finish.”
9When prompted to insert disk labeled “IBM Streamer Family Adapter
Option Diskette”, click on “OK.”
10 Insert disk 2 of 6 (Auto LANStreamer PCI Driver Diskette), set the path
to “A:\” and click “OK.” (If you have an HP preloaded HDD, set the path
to “C:\LANDRV\LNSTRM\DISK2\”)
11 At the “Copying Files” window, click on “OK.”
1 Connecting to Netware 3.12 Server
Windows 95 SR2
12 Click “OK” to provide your Computer and Workgroup names.
13 Enter your Computer Name, Workgroup Name, Computer Description,
and click on “Close.”
14 Accept the default properties, and click on “OK.”
15 When prompted to insert the Windows 95 CD-ROM, click on “OK.”
16 Set the path to your Windows 95 files and click on “OK.” (If you have an
HP pre-loaded HDD, set the path statement
C:\MASTERS\WIN95\SYSTEM\CABS\”).
17 When prompted to insert the disk labeled “IBM Streamer Family Adapter
Option Diskette”, click on “OK.”
18 Insert disk 4 of 6 (Auto LANStreamer PCI Driver Diskette), set the path
to “A:\Win95\” and click “OK.” (If you have an HP preloaded HDD, set the
path to “C:\LANDRV\LNSTRM\DISK4\WIN95\”)
19 Click on “Yes” to restart your computer and finish the installation.
2 Connecting to a Netware 4.11 Server
Windows for Workgroups
2 Connecting to a Netware 4.11 Server
Windows for
Workgroups
Requirements
• HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed.
• IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.01.
• Driver Name: IBMMPC.DOS Size: 59KB Date: 5/22/95
• Novell Netware 4.11 server that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
• Netware client for DOS and MS-Windows.
Device Configuration
• Interrupt 9 (2)
• I/O Address FCC0-h
Procedure
1With the HP Vectra turned off install the IBM LANStreamer 16/4 PCI TR
adapter card into a PCI slot.
2Insert the IBM LANStreamer TR drivers disk 1 of 6 (AUTO LANStreamer
PCI Diagnostic Disk) and power on the machine.
3After the machine boots, verify that the adapter finished testing and that
the adapter is “OK.”
4Click on “F3” to exit, and then press “CTRL+ALT+DEL.”
5Boot the machine to a DOS prompt, and Netware client for DOS and MS-
Windows disk 1.
6Execute INSTALL.EXE and set lines 1-5 as listed below;
• C:\NWCLIENT
•YES
•YES
C:\WINDOWS
•NO
2 Connecting to a Netware 4.11 Server
Windows for Workgroups
• IBM Auto LANStreamer PCI Adapter (use the driver on disk 3 of 5, Net-
ware DOS requester Installation disk)
7Highlight option 6 to continue with installation.
8When prompted, insert the corresponding disks to complete file transfer
and driver installation.
9When the install utility is finished, press <CRTL><ALT><DEL> to restart
the machine.
10 After windows loads, open the “NETWORK” folder, and double-click the
“NETWORK SETUP” icon.
11 Select “Networks” and verify that “Novell Netware (Workstation Shell 4.0
and above)” is selected under “Install Windows support for the following
network only:”
12 Click on “OK” twice and the installation is complete.
2 Connecting to a Netware 4.11 Server
Windows 95 SR2
Windows 95 SR2 Requirements
• HP Vectra with Windows 95 SR2 installed.
• IBM LANStreamer 16/4 PCI TR adapter and drivers diskettes ver 1.01.
• Driver Name: Windows 95 Default
• Novell Netware 4.11 server that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
Device Configuration
• Interrupt 9 (2)
• I/O Address FCC0-h
Procedure
1With the HP Vectra turned off install the IBM LANStreamer 16/4 PCI TR
adapter card into a PCI slot.
2Insert the IBM LANStreamer TR drivers disk 1 of 6 (AUTO LANStreamer
PCI Diagnostic Disk) and power on the machine.
3After the machine boots, verify that the adapter finished testing and that
the adapter is “OK.”
4Click on “F3” to exit, and then press “CTRL+ALT+DEL.”
5Upon booting, Windows 95 will automatically recognize the adapter. Click
on “Next.”
6When prompted, click on “Other Locations.”
7Insert drivers disk 4 of 6 (Auto LANStreamer PCI NDIS 3.0 Driver
Diskette), set the path to “A:\” and click “OK.” (If you have an HP
preloaded HDD, set the path to “C:\LANDRV\LNSTRM\DISK4\”)
8Verify that “IBM Auto LANStreamer PCI Adapter (NDIS3)” is listed and
click on “Finish.”
9When prompted to insert disk labeled “IBM Streamer Family Adapter
Option Diskette”, click on “OK.”
10 Insert disk 2 of 6 (Auto LANStreamer PCI Driver Diskette), set the path
to “A:\” and click “OK.” (If you have an HP preloaded HDD, set the path
to “C:\LANDRV\LNSTRM\DISK2\”)
11 At the “Copying Files” window, click on “OK.”
2 Connecting to a Netware 4.11 Server
Windows 95 SR2
12 Click “OK” to provide your Computer and Workgroup names.
13 Enter your Computer Name, Workgroup Name, Computer Description,
and click on “Close.”
14 Accept the default properties, and click on “OK.”
15 When prompted to insert the Windows 95 CD-ROM, click on “OK.”
16 Set the path to your Windows 95 files and click on “OK.” (If you have an
HP pre-loaded HDD, set the path statement
C:\MASTERS\WIN95\SYSTEM\CABS\”).
17 When prompted to insert the disk labeled “IBM Streamer Family Adapter
Option Diskette”, click on “OK.”
18 Insert disk 4 of 6 (Auto LANStreamer PCI Driver Diskette), set the path
to “A:\Win95\” and click “OK.” (If you have an HP preloaded HDD, set the
path to “C:\LANDRV\LNSTRM\DISK4\Win95\”)
19 Click on “Yes” to restart your computer and finish the installation.
