Etherlink III PCI Network Interface
Card (10BT)
3C590-TPO
Installation Guide
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing, performance, or use
of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft
Corporation.
MMXTM is a trademark of Intel Corporation.
Pentium® is a registered trademark of Intel Corporation.
Hewlett-Packard France
Commercial Desktop Computing Division
38053 Grenoble Cedex 9
France
© 1998 Hewlett Packard Company
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
1 Connecting to a Netware 3.12 Server
Windows for
Workgroups
Requirements
• HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed.
• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.1A.
DOS ODI - File Name: EL59X.DOS Size: 27KB Date: 10/04/96
• DOS and MS-Windows for Workgroups 3.11 media.
• Novell Netware server 3.12 that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
• Netware client for DOS and MS-Windows.
Device Configuration
• Network Driver Optimization Normal
• Full Duplex Disabled
• Boot PROM Disabled
• Media Type 10BASE-T
Procedure
1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B
adapter card into an ISA slot.
2Power on the machine and allow it to boot to a DOS prompt.
3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s
website) and execute 3C59XCFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
Vectra VL8 Vectra VL7 Vectra VE7/VE8
I/O Base Address FCCO (PCI) FCC0h (PCI) DC00h (PCI)
Interrupt Request
Level
10 (PCI) 9 (PCI) 10 (PCI)
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
6Remove the 3com cards driver diskette and insert Netware client for DOS
and MS-Windows disk 1.
If you are using a Vectra VL7 or VE7/VE8, follow the instructions below to
complete the installation. If you are using a VL8, go directly to step 7.
aExecute INSTALL.EXE.
bSpecify the settings as listed below:
• C:\NWCLIENT
•Yes
•Yes
• C:\WINDOWS
•No
• 3Com Fast Etherlink/Etherlink III Bus Master
cUnder the heading "Select the driver for your network board", insert
the 3Com 3C590 drivers disk and set the path to "A:\NETWARE\
CLIENT." (If you have an HP preloaded HDD, set path to "C:\Masters\
LanDrv\3C590\NETWARE\CLIENT\)
dPress "Enter" to continue the installation.
eWhen prompted, insert the corresponding disks to complete file trans-
fer and driver installation.
fWhen the install utility is finished, press <CRTL><ALT><DEL> to
restart the machine.
gAfter Windows loads, open the "NETWORK" folder, double-click the
"NETWORK SETUP" icon.
hSelect "Networks" and verify that "Novell Netware (Workstation Shell
4.0 and above)" is selected under "Install Windows support for the
following network only:"
iSelect "OK" twice, and the installation is complete.
7Execute INST_DOS.EXE and enter Yes to accept the agreement.
8Accept the default products by pressing Enter, and then press “F10” to
continue.
9Select 16-bit LAN Drivers and hit the Enter key.
10 Page down the Board Drivers list to “USER SPECIFIED 16 BIT DRIVER”
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
and hit enter.
11 Insert the 3COM Etherlink 3C590 Ethernet card and drivers disk, set the
path to “A:\NETWARE\CLIENT\” and press enter.
12 Select “3Com Fast Etherlink / Etherlink III Bus Master Family” and press
enter.
13 Accept the default settings, press “F10” to continue, and verify the
following entries for the “Installation Configuration Summary”:
❒YES
❒C:\NOVELL\CLIENT32
❒C:\WINDOWS
❒16-bit LAN drivers
❒3Com Fast Etherlink / Etherlink III Bus Master Family
14 Press “F10” to save and continue.
15 When prompted, insert the corresponding disks to complete file transfer
and driver installation.
16 When the install utility is finished, press <CRTL><ALT><DEL> to restart
the machine.
17 After windows loads, open the “NETWORK” folder, double-click the
“NETWORK SETUP” icon.
18 Select “Networks”, and verify that “Novell Netware (Workstation Shell 4.0
and above)” is listed under “Install Windows support for the following
network only:” and click on “OK.”
1 Connecting to a Netware 3.12 Server
Windows for Workgroups
1 Connecting to a Netware 3.12 Server
Windows 95 SR2
Windows 95 SR2 Requirements
• HP Vectra with Windows 95 SR2 installed.
• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.1a.
• File Name: EL59X.VXD Size: 38KB Date: 1/27/97
Driver for Vectra VE7/VE8: Windows 95 Embedded
• Windows 95 SR2 media (If you have an HP preloaded HDD, the media is
located at C:\Masters\Win95\System\Cabs\)
• Novell Netrware 3.12 server that supports Net BEUI, NWLink IPX/SPX,
and NWLink NetBIOS transfer protocols.
Device Configuration
• Network Driver Optimization Normal
• Full Duplex Disabled
• Boot PROM Disabled
• Media Type 10BASE-T
Procedure
1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B
adapter card into an ISA slot.
2Power on the machine and restart Windows 95 SR2 in MS-DOS Mode.
3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s
website) and execute 3C59XCFG.EXE.
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
6Remove the 3com cards driver diskette and restart the machine.
7Windows 95 SR2 should automatically recognize the 3COM 3C590
Vectra VL8 Vectra VL7 Vectra VE7/VE8
I/O Base Address FCC0h (PCI) FCE0h (PCI) DC00h (PCI)
Interrupt Request
Level
10 (PCI) 9 (PCI) 10 (PCI)
1 Connecting to a Netware 3.12 Server
Windows 95 SR2
ethernet card
8When prompted, click on “OK” to continue.
9Enter “Computer Name”, “Workgroup”, and “Computer Description” data
and then open the “Configuration” folder.
10 In the “Configuration” folder, click on “Add”, then click on “Protocol” and
click on “Add” once again.
11 Listed under “Manufacturers”, select “Microsoft”, then select “TCP/IP”
under “Network Protocols:” and click on “OK.”
12 In the “Network” window, click on “Close” to continue the installation.
13 After files copy, you will be asked to restart your computer. Click on
“Yes.”
2 Connecting to a Netware 4.11 Server
Windows for Workgroups
2 Connecting to a Netware 4.11 Server
Windows for
Workgroups
Requirements
• HP Vectra with DOS and MS-Windows for Workgroups 3.11 installed.
• 3COM Etherlink 3C509-B ethernet card and drivers disk ver. 5.1a.
DOS ODI -
Vectra VL8 Driver File Name: 3C59X.COM Size: 55KB Date:10/04/96
• Vectra VL7 and VE7/VE8 Driver File Name: EL59X.DOS Size:27KB
Date: 10/04/96
• DOS and MS-Windows for Workgroups 3.11 media.
• Novell Netware server 4.1 that supports Net BEUI, NWLink IPX/SPX, and
NWLink NetBIOS transfer protocols.
• Netware client for DOS and MS-Windows.
Device Configuration
• Network Driver Optimization Normal
• Full Duplex Disabled
• Boot PROM Disabled
• Media Type 10BASE-T
Procedure
1With the HP Vectra turned off install the 3COM Etherlink III 3C509-B
adapter card into an ISA slot.
2Power on the machine and allow it to boot to a DOS prompt.
3Insert the 3COM drivers diskette (ver. 5.0 downloaded from 3COM’s
website) and execute 3C59XCFG.EXE.
Vectra VL8 Vectra VL7 Vectra VE7/VE8
I/O Base Address FCC0h (PCI) FCC0h (PCI) DC00h (PCI)
Interrupt Request
Level
10 (PCI) 9 (PCI) 10 (PCI)
2 Connecting to a Netware 4.11 Server
Windows for Workgroups
4Select “CONFIGURE NIC,” and verify the resource settings listed above
under the heading “Device Configuration.”
5If changes are required, save those changes and exit.
6Remove the 3com cards driver diskette and insert Netware client for DOS
and MS-Windows disk 1.
If you are using a Vectra VL8, go directly to step 7.
If you are using a VL7 or VE7/VE8, follow the instructions below to
complete the installation.
aExecute INSTALL.EXE.
bSpecify the settings as listed below:
• C:\NWCLIENT
•Yes
•Yes
• C:\WINDOWS
•No
• 3Com Fast Etherlink/Etherlink III Bus Master
cUnder the heading "Select the driver for your network board", insert
the 3Com 3C590 drivers disk and set the path to "A:\NETWARE\CLI-
ENT." (If you have an HP preloaded HDD, set path to "C:\Masters\Lan-
Drv\3C590\NETWARE\CLIENT\)
dPress "Enter" to continue the installation.
eWhen prompted, insert the corresponding disks to complete file trans-
fer and driver installation.
fWhen the install utility is finished, press <CRTL><ALT><DEL> to re-
start the machine.
gAfter windows loads, open the "NETWORK" folder, double-click the
"NETWORK SETUP" icon.
hSelect "Networks" and verify that "Novell Netware (Workstation Shell
4.0 and above)" is selected under "Install Windows support for the fol-
lowing network only:"
iSelect "OK" twice, and the installation is complete.
7Execute INST_DOS.EXE and enter Yes to accept the agreement.
