HPE H3C S9500 Series Manuale utente

Operation Manual – Reliability

H3C S9500 Series Routing Switches Table of Contents

Table of Contents

Chapter 1 VRRP Configuration....................................................................................................1-1

1.1 Introduction to VRRP.........................................................................................................1-1

1.2 Configuring VRRP .............................................................................................................1-2

1.2.1 Enabling/Disabling the Function to Ping the Virtual IP Address.............................1-3

1.2.2 Enabling/Disabling the Check of TTL Value of VRRP Packet................................1-3

1.2.3 Setting Correspondence between Virtual IP Address and MAC Address ..............1-3

1.2.4 Adding/Deleting a Virtual IP Address......................................................................1-4

1.2.5 Configuring the Priority of Switches in the Virtual Router.......................................1-5

1.2.6 Configuring Preemption and Delay for a Switch within a Virtual Router.................1-5

1.2.7 Configuring Authentication Type and Authentication Key.......................................1-6

1.2.8 Configuring Virtual Router Timer.............................................................................1-7

1.2.9 Configuring Switch to Track a Specified Interface..................................................1-8

1.3 Displaying and debugging VRRP ......................................................................................1-9

1.4 VRRP Configuration Example ...........................................................................................1-9

1.4.1 VRRP Single Virtual Router Example.....................................................................1-9

1.4.2 VRRP Tracking Interface Example ....................................................................... 1-11

1.4.3 Multiple Virtual Routers Example..........................................................................1-12

1.5 Troubleshooting VRRP....................................................................................................1-13

Chapter 2 HA Configuration.........................................................................................................2-1

2.1 Introduction to HA..............................................................................................................2-1

2.2 Configuring HA...................................................................................................................2-2

2.2.1 Restarting the Slave System Manually ...................................................................2-2

2.2.2 Starting the Master-Slave Switchover Manually .....................................................2-2

2.2.3 Enabling/Disabling Automatic Synchronization.......................................................2-2

2.2.4 Synchronizing the Configuration File Manually.......................................................2-3

2.2.5 Configuring the Load Mode of the Master and Slave boards .................................2-3

2.3 Displaying and Debugging HA Configuration....................................................................2-4

2.4 HA Configuration Example ................................................................................................2-4

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-1

Chapter 1 VRRP Configuration

1.1 Introduction to VRRP

Virtual Router Redundancy Protocol (VRRP) is a fault-tolerant protocol. In general, a

default route (for example, 10.100.10.1 as shown in the following internetworking

diagram) will be configured for every host on a network, so that the packets destined to

some other network segment from the host will go through the default route to the Layer

3 Switch, implementing communication between the host and the external network. If

Switch is down, all the hosts on this segment taking Switch as the next-hop on the

default route will be disconnected from the external network.

Ethernet

Switch

Host 1 Host 2 Host 3

10.100.10.7 10.100.10.8 10.100.10.9

10.100.10.1

Network

Figure 1-1 Network diagram for LAN

VRRP, designed for LANs with multicast and broadcast capabilities (such as Ethernet)

settles the above problem. The diagram below is taken as an example to explain the

implementation principal of VRRP. VRRP combines a group of LAN switches (including

a Master and several Backups) into a virtual router.

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-2

Ethernet

Master

Host 1 Host 2 Host 3

10.100.10.7 10.100.10.8 10.100.10.9

Virtual IP address10.100.10.1

Network

Backup

Virtual IP address10.100.10.1

Actual IP address10.100.10.2 Actual IP address10.100.10.3

Figure 1-2 Network diagram for virtual router

This virtual router has its own IP address: 10.100.10.1 (which can be the interface

address of a switch within the virtual router). The switches within the virtual router have

their own IP addresses (such as 10.100.10.2 for the Master switch and 10.100.10.3 for

the Backup switch). The host on the LAN only knows the IPaddress of this virtual router

10.100.10.1 (usually calledas virtual IP address of virtual router), but not the specific IP

addresses 10.100.10.2 of the Master switch and 10.100.10.3 of the Backup switch.

They configure their own default routes as the IP address of this virtual router:

10.100.10.1. Therefore, hosts within the network will communicate with the external

network through this virtual router. If a Master switch in the virtual group breaks down,

another Backup switch will function as the new Master switch to continue serving the

host with routing to avoid interrupting the communication between the host and the

external networks.

1.2 Configuring VRRP

The following sections describe the VRRP configuration tasks:

zEnabling/Disabling the Function to Ping the Virtual IP Address

zEnabling/Disabling the Check of TTL Value of VRRP Packet

zSetting Correspondence between Virtual IP Address and MAC Address

zAdding/Deleting a Virtual IP Address

zConfiguring the Priority of Switches in the Virtual Router

zConfiguring Preemption and Delay for a Switch within a Virtual Router

zConfiguring Authentication Type and Authentication Key

zConfiguring Virtual Router Timer

zConfiguring Switch to Track a Specified Interface

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-3

1.2.1 Enabling/Disabling the Function to Ping the Virtual IP Address

This operation enables or disables the function to ping the virtual IP address of the

virtual router. The standard protocol of VRRP does not support the ping function, then

the user cannot judge with ping command whether an IP address is used by the virtual

router. If the user configure the IPaddress for the host same as the virtual IP address of

the virtual router, then all messages in this segment will be forwarded to the host.

So H3C S9500 Series Routing Switches (hereinafter referred to as S9500 series)

provide the ping function to ping the virtual IP address of the virtual router.

Perform the following configuration in system view.

Table 1-1 Enable/disable the ping function

Operation Command

Enable to ping the virtual IP address vrrp ping-enable

Disable to ping the virtual IP address undo vrrp ping-enable

By default, the function to ping the virtual IP address is disabled.

You should set the ping function before configuring the virtual router. If a virtual router is

already established on the switch, it is not allowed to use the vrrp ping-enable

command and the undo vrrp ping-enable command to modify the configuration any

more.

1.2.2 Enabling/Disabling the Check of TTL Value of VRRP Packet

This operation configures whether to check TTL value of VRRP packet on the Backup

switch. The TTL value must be 225. If the Backup switch find TTL is not 225 when

receiving VRRP packet, the packet will be discarded.

Perform the following configuration in VLAN interface view.

Table 1-2 Enable/disable the check of TTL value of VRRP packet

Operation Command

Disable the check of TTL value of VRRP packet vrrp un-check ttl

Enable the check of TTL value of VRRP packet undo vrrp un-check ttl

By default, the switch checks TTL value of VRRP packets.

1.2.3 Setting Correspondence between Virtual IP Address and MAC Address

This operation sets correspondence between the virtual lP address and the MAC

address. In the standard protocol of VRRP, the virtual IP address of the virtual router

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-4

corresponds to the virtual MAC address, to ensure correct data forwarding in the

sub-net.

Due to the chips installed, some switches support matching one IP address to multiple

MAC addresses.

S9500 series not only guarantee correct data forwarding in the sub-net, but also

support such function: the user can choose to match the virtual IP address with the real

MAC address or virtual MAC address of the routing interface.

The following commands can be used to set correspondence between the IP address

and the MAC address.

Perform the following configuration in system view.

Table 1-3 Set correspondence between virtual IP address and MAC address

Operation Command

Set correspondence between the virtual IP

address and the MAC address vrrp method { real-mac |

virtual-mac }

Set the correspondence to the default value undo vrrp method

By default, the virtual IP address of the virtual router corresponds to the virtual MAC

address.

You should set correspondence between the virtual IP address of the virtual router and

the MAC address before configuring the virtual router. Otherwise, you cannot configure

the correspondence.

If you set correspondence between the IP address of the virtual router and the real

MAC address, you can configure only one virtual router on VLAN interface.

1.2.4 Adding/Deleting a Virtual IP Address

The following command is used for assigning a virtual IP address of the local segment

to a virtual router or removing an assigned virtual IPaddress of a virtual router from the

virtual address list.

Perform the following configuration in VLAN interface view.

Table 1-4 Add/delete a virtual IP address

Operation Command

Add a virtual IP address vrrp vrid virtual-router-ID virtual-ip virtual-address

Delete a virtual IP address undo vrrp vrid virtual-router-ID [ virtual-ip

virtual-address ]

The virtual-router-ID covers the range from 1 to 255.

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-5

The virtual-address can be an unused address in the network segment where the

virtual router resides, or the IP address of an interface in the virtual router. If the IP

address is of the switch in the virtual router, it can also be configured as virtual-address.

In this case, the switch will be called an IP Address Owner. When adding the first IP

address to a virtual router, the system will create a new virtualrouter accordingly. When

adding a new address to this virtual router thereafter, the system will directly add it into

the virtual IP address list.

After the last virtual IP address is removed from the virtual router, the whole virtual

router will also be removed. That is, there is no more virtual router on the interface any

more and any configuration of it is invalid accordingly.

1.2.5 Configuring the Priority of Switches in the Virtual Router

The status of each switch in the virtual router will be determined by its priority in VRRP.

The switch with the highest priority will become the Master.

Perform the following configuration in VLAN interface view.

Table 1-5 Configure the priority of switches in the virtual router.

Operation Command

Configure the priority of switches in the

virtual router.

vrrp vrid virtual-router-ID priority

priority

Clear the priority of switches in the

virtual router. undo vrrp vrid virtual-router-ID priority

The priority ranges from 0 to 255. The greater the number, the higher the priority.

However the value can only be taken from 1 to 254. The priority 0 is reserved for special

use and 255 is reserved for the IP address owner by the system.

By default, the priority is 100.

Note:

The priority for IP address owner is always 255, which cannot be configured otherwise.

1.2.6 Configuring Preemption and Delay for a Switch within a Virtual Router

Once a switch in the virtual router becomes the Master switch, so long as it still

functions properly, other switches, even configured with a higher priority later, cannot

become the Master switch unless they are configured to work in preemption mode. The

switch in preemption mode will become the Master switch, when it finds its own priority

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-6

is higher than that of the current Master switch. Accordingly, the former Master switch

will become the Backup switch.

Together with preemption settings, a delay can also be set. In this way, a Backup will

wait for a period of time before becoming a Master. In an unstable network if the Backup

switch has not received the packets from the Master switch punctually, it will become

the Master switch. However, the failure of Backup to receive the packets may be due to

network congestion, instead of the malfunction of the Master switch. In this case, the

Backup will receive the packet after a while. The delay settings can thereby avoid the

frequent status changing.

Perform the following configuration in VLAN interface view.

Table 1-6 Configure preemption and delay for a switch within a virtual router

Operation Command

Enable the preemption mode and

configure a period of delay.

vrrp vrid virtual-router-ID preempt-mode

[ timer delay delay-value ]

Disable the preemption mode. undo vrrp vrid virtual-router-ID

preempt-mode

The delay ranges from 0 to 255, measured in seconds. By default, the preemption

mode is preemption with a delay of 0 second.

Note:

If preemption mode is cancelled, the delay time will automatically become 0 second.

1.2.7 Configuring Authentication Type and Authentication Key

VRRP provides following authentication types:

zsimple: Simple character authentication

zmd5: MD5 authentication

In a network under possible security threat, the authentication type can be set to

simple. Then the switch will add the authentication key into the VRRP packets before

transmitting it. The receiver will compare the authentication key of the packet with the

locally configured one. If they are the same, the packet will be taken as a true and legal

one. Otherwise it will be regarded as an illegal packet to be discarded. In this case, an

authentication key not exceeding 8 characters should be configured.

In a totally unsafe network, the authentication type can be set to md5. The switch will

use the authentication type and MD5 algorithm provided by the Authentication Header

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-7

to authenticate the VRRP packets. In this case an authentication key not exceeding 8

characters should be configured.

Those packets failing to pass the authentication will be discarded and a trap packet will

be sent to the network management system.

Perform the following configuration in VLAN interface view.

Table 1-7 Configure authentication type and authentication key

Operation Command

Configure authentication type and

authentication key

vrrp authentication-mode

authentication-type authentication-key

Remove authentication type and

authentication key undo vrrp authentication-mode

The authentication key is case sensitive.

Note:

The same authentication type and authentication keyshould be configured for all VLAN

interfaces that belong to the virtual router.

1.2.8 Configuring Virtual Router Timer

The Master switch advertises its normal operation state to the switches within the

VRRP virtual router by sending them VRRP packets regularly (at adver-interval). And

the backup switch only receives VRRP packets. If the Backup has not received any

VRRPpacket from the Master after a period of time (specified by master-down-interval),

it will consider the Master as down, and then take its place and become the Master.

You can use the following command to set a timer and adjust the interval, adver-interval,

between Master transmits VRRP packets. The master-down-interval of the Backup

switch is three times that of the adver-interval. The excessive network traffic or the

differences between different switch timers will result in master-down-interval timing out

and state changing abnormally. Such problems can be solved through prolonging the

adver-interval and setting delay time. adver-interval is measured in seconds.

Perform the following configuration in VLAN interface view.

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-8

Table 1-8 Configure virtual router timer

Operation Command

Configure virtual router timer vrrp vrid virtual-router-ID timer advertise

adver-interval

Clear virtual router timer undo vrrp vrid virtual-router-ID timer advertise

By default, adver-interval is configured to be 1.

1.2.9 Configuring Switch to Track a Specified Interface

VRRP interface track function has expanded the backup function. Backup is provided

not only to the interface where the virtual router resides, but also to some other

malfunctioning switch interface. By implementing the following command you can track

some interface.

If the interface which is tracked is Down,the priority of the switch including the interface

will reduce automatically by the value specified by value-reduced, thus resulting in

comparatively higher priorities of other switches within the virtual router, one of which

will turn to Master switch so as to track this interface.

Perform the following configuration in VLAN interface view.

Table 1-9 Configure switch to track a specified interface

Operation Command

Configure the switch to

track a specified interface vrrp vrid virtual-router-ID track vlan-interface

interface-number [ reduced value-reduced ]

Stop tracking the specified

interface

undo vrrp vrid virtual-router-ID track [ vlan-interface

interface-number ]

By default, value-reduced is taken 10.

Note:

zWhen the switch is an IP address owner, its interfaces cannot be tracked.

zIf the interface tracked is up again, the corresponding priority of the switch, including

the interface, will be restored automatically

zYou can only track up to eight interfaces in one virtual router.

Operation Manual – Reliability

H3C S9500 Series Routing Switches Chapter 1 VRRP Configuration

1-9

1.3 Displaying and debugging VRRP

After the above configuration, execute display command in any view to display the

running of the VRRPconfiguration, and to verify the configuration. Execute debugging

command in user view to debug VRRP configuration.

Table 1-10 Display and debug VRRP

Operation Command

Display VRRP state information display vrrp [ interface vlan-interface

interface-number [ virtual-router-ID ] ]

Display VRRP statistics

information display vrrp statistics [vlan-interface

interface-number [ virtual-router-ID ]

Display VRRP summary

information display vrrp summary

Clear the statistics information

about VRRP reset vrrp statistics [vlan-interface

interface-number [ virtual-router-ID ] ]

Enable VRRP debugging. debugging vrrp { state |packet |error }

Disable VRRP debugging. undo debugging vrrp { state |packet |error }

You can enable VRRP debugging to check its running. You may choose to enable

VRRP packet debugging (option as packet), VRRP state debugging (option as state),

and/or VRRP error debugging (option as error). By default, VRRP debugging is

disabled.

1.4 VRRP Configuration Example

1.4.1 VRRP Single Virtual Router Example

I. Networking requirements

Host A uses the VRRP virtual router which combines switch A and switch B as its

default gateway to access host B on the Internet.

VRRP virtual router information includes: virtual router ID1, virtual IP address

202.38.160.111, switch A as the Master and switch B as the Backup allowed

preemption.

Indice

Altri manuali HPE Interruttore

HPE

HPE OfficeConnect 1920S Series Manuale utente

HPE

HPE FlexFabric 5800 Series Manuale utente

HPE

HPE FlexFabric 12900E Manuale di installazione

HPE

HPE JL324A Istruzioni per il montaggio

HPE

HPE OfficeConnect 1950 Series Manuale utente

HPE

HPE FlexNetwork 10500 SERIES Manuale utente

HPE

HPE Aruba Instant On 1960 24G 20p Class4 4p Class6 PoE 2XGT 2SFP+ 370W... Istruzioni per il montaggio

HPE

HPE OfficeConnect 1950 12XGT 4SFP+ Manuale utente

HPE

HPE FlexNetwork 10500 SERIES Manuale utente

HPE

HPE FlexNetwork 5130 HI SERIES Manuale utente

HPE

HPE FlexFabric 5940 SERIES Manuale di installazione

HPE

HPE FlexFabric 5700 Series Manuale utente

HPE

HPE JH390A Manuale utente

HPE

HPE FlexFabric 5940 SERIES Manuale di installazione

HPE

HPE OfficeConnect 1910 Series Guida di sicurezza

HPE

HPE FlexNetwork 10500 SERIES Manuale utente

HPE

HPE Altoline 6940 32QSFP+ Istruzioni per il montaggio

HPE

HPE OfficeConnect 1405 v3 Series Manuale di istruzioni

HPE

HPE OfficeConnect 1420 Series Manuale utente

HPE

HPE FlexFabric 5710 Series Manuale utente

HPE

HPE Aruba Networking 2930M Manuale di istruzioni

HPE

HPE 5945 Istruzioni per l'installazione

HPE

HPE FlexNetwork 5510 HI Series Manuale utente

HPE

HPE FlexFabric 5700 Series Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
