Huawei S3700 Series Manuale utente

S3700&S5700&S6700 Series Ethernet Switches

V200R001C01

Quick Start

Issue 02

Date 2012-09-10

HUAWEI TECHNOLOGIES CO., LTD.

No part of this document may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and the

customer. All or part of the products, services and features described in this document may not be within the

purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,

and recommendations in this document are provided "AS IS" without warranties, guarantees or representations

of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: [email protected]

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

About This Document

Intended Audience

This document describes how to verify basic functions of the S3700, S5700 and S6700 during

the deployment to ensure stable and reliable running of the S3700, S5700 and S6700 on the

network.

This document is intended for:

lData configuration engineers

lCommissioning engineers

lNetwork monitoring engineers

lSystem maintenance engineers

Symbol Conventions

The symbols that may be found in this document are defined as follows.

Symbol Description

DANGER

Indicates a hazard with a high level of risk, which if not

avoided, will result in death or serious injury.

WARNING

Indicates a hazard with a medium or low level of risk, which

if not avoided, could result in minor or moderate injury.

CAUTION

Indicates a potentially hazardous situation, which if not

avoided, could result in equipment damage, data loss,

performance degradation, or unexpected results.

TIP

Indicates a tip that may help you solve a problem or save

time.

NOTE

Provides additional information to emphasize or supplement

important points of the main text.

S3700&S5700&S6700 Series Ethernet Switches

Quick Start About This Document

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

Command Conventions

The command conventions that may be found in this document are defined as follows.

Convention Description

Boldface The keywords of a command line are in boldface.

Italic Command arguments are in italics.

[ ] Items (keywords or arguments) in brackets [ ] are optional.

{ x | y | ... } Optional items are grouped in braces and separated by

vertical bars. One item is selected.

[ x | y | ... ] Optional items are grouped in brackets and separated by

vertical bars. One item is selected or no item is selected.

{ x | y | ... }*Optional items are grouped in braces and separated by

vertical bars. A minimum of one item or a maximum of all

items can be selected.

[ x | y | ... ]*Optional items are grouped in brackets and separated by

vertical bars. Several items or no item can be selected.

&<1-n> The parameter before the & sign can be repeated 1 to n times.

# A line starting with the # sign is comments.

Change History

Updates between document issues are cumulative. Therefore, the latest document issue contains

all changes made in previous issues.

Changes in Issue 02 (2012-09-10)

lSome contents are modified according to updates in the product such as features and

commands.

Changes in Issue 01 (2012-07-25)

Initial commercial release.

S3700&S5700&S6700 Series Ethernet Switches

Quick Start About This Document

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

iii

Contents

About This Document.....................................................................................................................ii

1 Overview.........................................................................................................................................1

2 Product Hardware Introduction..................................................................................................2

2.1 S3700 Introduction.............................................................................................................................................3

2.2 S5700 Introduction.............................................................................................................................................4

2.3 S6700 Introduction.............................................................................................................................................9

2.4 S3700 Indicator Description.............................................................................................................................10

2.5 S5700 Indicator Description.............................................................................................................................13

2.6 S6700 Indicator Description.............................................................................................................................42

3 Device Installation......................................................................................................................47

4 Powering on the Device.............................................................................................................48

4.1 Checking Before Power-on..............................................................................................................................49

4.2 Powering on the Device....................................................................................................................................53

4.3 Checking After Power-on.................................................................................................................................53

5 Logging in to the Device............................................................................................................54

5.1 Logging In to the Switch Through the Console Interface................................................................................55

5.2 Example for Configuring to Manage the SwitchThrough Telnet.....................................................................58

5.3 Logging In to the Web System Client..............................................................................................................61

6 Service Deployment....................................................................................................................63

7 Obtaining Documentation.........................................................................................................64

S3700&S5700&S6700 Series Ethernet Switches

Quick Start Contents

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

1 Overview

This section provides an overview of quick start.

This document helps you quickly learn how to use the S3700/S5700/S6700. Figure 1-1 shows

the quick start contents.

Figure 1-1 Quick start contents

Start

Product Hardware

Introduction Describes switch models and Indicators on each model

Device Installation Provides reference for device installation

Powering on the

Device

Logging in to the

Device

Describes precautions to take before and after you power on a switch

Describes how to log in to a switch

Service

Deployment Provides reference for deploying services on a switch

Obtaining

Documentation

Helps you obtain product documentation quickly

S3700&S5700&S6700 Series Ethernet Switches

Quick Start 1 Overview

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

2 Product Hardware Introduction

About This Chapter

This section describes models and indicators of low-end switches.

2.1 S3700 Introduction

This section describes device models and naming rules of the S3700.

2.2 S5700 Introduction

This section describes device models and naming rules of the S5700.

2.3 S6700 Introduction

This section describes device models and naming rules of the S6700.

2.4 S3700 Indicator Description

This section describes the indicators on the S3700 front panel.

2.5 S5700 Indicator Description

This section describes the indicators on the S5700 front panel.

2.6 S6700 Indicator Description

This section describes the indicators on the S6700 front panel.

S3700&S5700&S6700 Series Ethernet Switches

Quick Start 2 Product Hardware Introduction

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

2.1 S3700 Introduction

This section describes device models and naming rules of the S3700.

Device Models

Currently, S3700 only has one model, as described in Table 2-1.

Table 2-1 Device models

Model Maximum Number of Interfaces

S3700-26C-HI 26

There are twenty-two 10/100BASE-T Ethernet interfaces,

two GE combo interfaces (10/100/1000BASE-T

+100/1000BASE-X), and two interfaces on the front

subcard.

Naming Rules

Figure 2-1 describes the naming rules of the S3700-26C-HI.

Figure 2-1 Naming rules

S3700-26C-HI

A B C D E

Ide

ntifi

Description

ASwitch.

BProduct series. "37" indicates the S3700 series.

CMaximum number of interfaces.

DUplink interface type:

lC: A device supports interface cards. There can be two uplink interfaces on an

interface subcard.

ESoftware version type:

lHI: advanced version, supporting high-performance Operation, Administration,

and Maintenance (OAM) and built-in real-time clock (RTC)

S3700&S5700&S6700 Series Ethernet Switches

Quick Start 2 Product Hardware Introduction

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

2.2 S5700 Introduction

This section describes device models and naming rules of the S5700.

Device Models

To meet diverse customer requirements, the S5700 provides a variety of models. Table 2-2 lists

these device models.

You can select a device model as required.

Table 2-2 Device models

Produ

Series

Model Maximum Number of Interfaces

S5700

S5700-28C-EI 28

There are twenty-four 10/100/1000BASE-T Ethernet

interfaces and four interfaces on the front subcard.

S5700-28C-EI-24S 28

There are twenty 100/1000BASE-X Ethernet optical

interfaces, four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X), and four

interfaces on the front subcard.

S5700-52C-EI 52

There are forty-eight 10/100/1000BASE-T Ethernet

interfaces and four interfaces on the front subcard.

S5700-28C-PWR-EI 28

There are twenty-four 10/100/1000BASE-T Ethernet

interfaces and four interfaces on the front subcard.

S5700-52C-PWR-EI 52

There are forty-eight 10/100/1000BASE-T Ethernet

interfaces and four interfaces on the front subcard.

S5700-28C-SI 28

There are twenty 10/100/1000BASE-T Ethernet

interfaces, four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X), and four

interfaces on the front subcard.

S5700-52C-SI 52

There are forty-eight 10/100/1000BASE-T Ethernet

interfaces and four interfaces on the front subcard.

S3700&S5700&S6700 Series Ethernet Switches

Quick Start 2 Product Hardware Introduction

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

Produ

Series

Model Maximum Number of Interfaces

S5700-28C-HI-24S 28

There are twenty-four 100/1000BASE-X Ethernet

optical interfaces and four interfaces on the front

subcard.

S5700-28C-HI 28

There are twenty-four 10/100/1000BASE-T Ethernet

interfaces and four interfaces on the front subcard.

S5700-28C-PWR-SI 28

There are twenty 10/100/1000BASE-T Ethernet

interfaces, four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X), and four

interfaces on the front subcard.

S5700-52C-PWR-SI 52

There are forty-eight 10/100/1000BASE-T Ethernet

interfaces and four interfaces on the front subcard.

S5700T

S5700-24TP-SI-AC 24

There are twenty 10/100/1000BASE-T Ethernet

interfaces and four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X).

S5700-24TP-SI-DC 24

There are twenty 10/100/1000BASE-T Ethernet

interfaces and four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X).

S5700-48TP-SI-AC 48

There are forty-four 10/100/1000BASE-T Ethernet

interfaces and four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X).

S5700-48TP-SI-DC 48

There are forty-four 10/100/1000BASE-T Ethernet

interfaces and four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X).

S5700-24TP-PWR-SI 24

There are twenty 10/100/1000BASE-T Ethernet

interfaces and four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X).

S5700-48TP-PWR-SI 48

There are forty-four 10/100/1000BASE-T Ethernet

interfaces and four GE combo interfaces

(10/100/1000BASE-T+100/1000BASE-X).

S3700&S5700&S6700 Series Ethernet Switches

Quick Start 2 Product Hardware Introduction

Issue 02 (2012-09-10) Huawei Proprietary and Confidential

Altri manuali per S3700 Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Huawei Router di rete

Huawei

Huawei 3 Prime Manuale utente

Huawei

Huawei LTE CPE B593 Manuale utente

Huawei

Huawei LTE CPE B593 Manuale utente

Huawei

Huawei EG8147X6 Manuale utente

Huawei

Huawei HG531s Manuale utente

Huawei

Huawei AR1200 Series Manuale utente

Huawei

Huawei B593 Scheda tecnica

Huawei

Huawei B2368 Manuale utente

Huawei

Huawei HW-02G Manuale utente

Huawei

Huawei Vodafone AR1220 Manuale utente

Huawei

Huawei WiFi Q2 Manuale utente

Huawei

Huawei B2368 Manuale utente

Huawei

Huawei B593 Scheda informativa del prodotto

Huawei

Huawei WS5200 Manuale utente

Huawei

Huawei B593 Manuale utente

Huawei

Huawei NetEngine 8000 F Istruzioni per l'installazione

Huawei

Huawei Mobile WiFi E5878 Istruzioni operative e di manutenzione

Huawei

Huawei Quidway S6500 Series Istruzioni per l'installazione

Huawei

Huawei AR2200 Series Manuale utente

Huawei

Huawei AR2200 Series Manuale utente

Huawei

Huawei SUN2000-M5 Series Manuale utente

Huawei

Huawei Flybox 4G Manuale utente

Huawei

Huawei B593s-931 Specifiche tecniche

Huawei

Huawei SmartAX MT880 Manuale utente

Manuali Router di rete popolari di altre marche

Allnet

Allnet ALL0333AU Manuale utente

HomeSeer

HomeSeer HT-SEL Manuale utente

Sercomm

Sercomm Genesis OC3505D Manuale utente

Billion

Billion BIPAC 5102 Series Manuale utente

TP-Link

TP-Link TD-8817 Manuale utente

Motorola

Motorola MR1900 Manuale utente

Digi

Digi IX14 Manuale utente

Cisco

Cisco NCS 540 Manuale

XAVi

XAVi X8821e Manuale utente

BEC

BEC 6200WZL Manuale utente

MikroTik

MikroTik hAP ac3 Series Manuale utente

Korenix

Korenix JetNet 5428G Series Manuale utente

NETGEAR

NETGEAR FS526T - Switch Manuale utente

Korenix

Korenix JetNet 5710G Series Manuale utente

Automated Logic

Automated Logic ZN551 Manuale del proprietario

Cisco

Cisco ASR 1000 Series Manuale dell'operatore

EnGenius

EnGenius ESR-9710 Manuale utente

Cisco

Cisco 805 Series Istruzioni operative e di sicurezza
