Quidway® S2000-HI Series Intelligent Access Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 1
Quidway® S2000-HI Series Intelligent Access
Switches Product Specification
Feature S2403H-HI S2016-HI S2008-HI
Fixed ports (1)24 10/100 BASE-TX
ports
(2) 1 console port
(1)16 10/100 BASE-TX
ports
(2) 1 console port
(1)8 10/100 BASE-TX
ports
(2) 1 console port
Extended Slot 2 2 1
Extended Module (1)1*10/100/1000BASE-T:max transmission distance: 100 m (328 ft)
(2)1*100BASE-SX: SC connector, 2 km (1.24 mi.)
(3)1*100BASE-LX: SC connector, 15 km (9.32 mi.)
(4)1*100BASE-LH40: SC connector, 40 km (24.86 mi.)
(5)1*1000BASE-SX: SC connector, 0.5km (0.31 mi.)
(6)1*1000BASE-LX: SC connector, 10 km (6.21 mi.)
(7)1*1000BASE-LH40: LC connector, 40 km (24.86 mi.)
(8)1*1000BASE-LH70: LC connector, 70 km (43.50 mi.)
(9)1*1000BASE-STACK (not supported by S2008-HI)
(10)1*100BASE-TX PD (Powered Device) (not supported by S2403-HI)
Performance
Switching
capacity 8.8 Gbps 7.2 Gbps 3.6 Gbps
Switching Fabric 19.2 Gbps 19.2 Gbps 19.2 Gbps
Throughput 6.55 Mpps 5.36 Mpps 2.68 Mpps
Stack(HGMP V2) Yes Yes No
Max stack
numbers 16 16 No
Stack bandwidth
(bps) 4G 4G No
POE (As PD) No Yes Yes
Latency <10µs
Layer 2 Switching
MAC Address Up to 8 K MAC addresses
1 K static MAC addresses
Adding of dynamic/static unicast MAC address, multicast MAC address, and
black hole MAC Address
Port Mirroring Many-to-one port mirroring (that is, multiple mirroring ports, and one monitor port)
Quidway® S2000-HI Series Intelligent Access Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 2
Feature S2403H-HI S2016-HI S2008-HI
Remote switched port analyzer (RSPAN)
Port Features Port isolation
Port self-loop detection
Port loopback (internal/external test)
VLAN 4k VLANs (IEEE 802.1Q)
GVRP (GARP VLAN Registration Protocol)
Port-based VLAN
VLAN Tag Frame Extension
Link Aggregation Up to 3 maximum aggregation groups (2 FE groups and 1 GE group), each
containing up to 8FE/2GE
Traffic control IEEE 802.3x full-duplex flow control
Back-pressure based flow control (half duplex)
STP/RSTP/MSTP IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
Multicast MVR(Multicast VLAN Registration)
256 Multicast groups
IGMP (Internet Group Management Protocol) snooping on Layer 2 interfaces
Network protocol DHCP Snooping (Dynamic Host Configuration Protocol Snooping)
Support NTP (Network Time Protocol)
ARP
Convergence
QoS(Quality of
Service) Four output queues on each port
Support flexible queue scheduling algorithms:
• WRR (Weighted Round Robin)
• HQ+WRR (High-Priority Queuing + WRR)
Support bi-directional port rate-limiting with the granularity of 64kbit/s
Port bandwidth percentage-based Broadcast storm suppression
Drop of unknown multicast packets
Security
Various Security SSHv2
Guest VLAN
MAC Black Hole
DHCP Snooping
Centralized MAC Address Authentication
Network Login Hierarchical user management and password protection
Port-based and MAC-based 802.1X authentication
Local authentication server
Quidway® S2000-HI Series Intelligent Access Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 3
Feature S2403H-HI S2016-HI S2008-HI
PEAP/TLS (Protected Extensible Authentication Protocol/Transport Layer
Security)
Management
System
Configuration and
Management
Support CLI (Command Line Interface) configuration mode
Support Configuration via the console port
Support Local/remote configuration via Telnet
Support System configuration with SNMP v1, 2, and 3
Support RMON (Remote Monitoring) v1 1, 2, 3 and 9 groups of MIB
Support Quidway and iManager N2000 network management system
Support WEB management system
Support Hierarchical alarms
Support System log
System
maintenance Debug information output
Ping, Traceroute, multicast Traceroute
Remote maintenance through Telnet
VCT (Virtual Cable Test)
Hardware configuration
Outline
dimensions (mm)
（H×W×D）
42 × 436 × 240 mm
(1.7 x 17.2 x 9.5 in) 42 × 436 × 200 mm
(1.7 x 17.2 x 7.9 in) 42 × 326 × 200 mm
(1.7 x 12.8 x 7.9 in)
Weight < 3kg (6.6 lb)
Fan No Fan
Maximum system
power
consumption 20 W 12 W 10 W
Input voltage Two models of switches are available, one supports AC input and the other
supports DC input
AC input:
Rated voltage range: 100V~240V, 50/60 Hz
Max voltage range: 90V~264V, 47~63 Hz
DC input:
Rated voltage range: –48V ~ –60V
Max voltage range: –36V ~–72 V
MTBF S2008-HI: 59.25 years( 519,030hours)
S2016-HI: 50.91 years (445,971hours)
S2403H-HI: 41.45 years (363,102hours)
Environment Working temperature: 0~45℃(32°F ~ 113°F)
Storage temperature: -40 ~ 70℃(-40°F to 158°F)
Relative humidity: 10%~90%, non-condensing
Quidway® S2000-HI Series Intelligent Access Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 4
Feature S2403H-HI S2016-HI S2008-HI
Operating temperature: 0°C to 45°C (32°F to 113°F)
