2 Data sheet „Honeycomb Nest“ Easy- Swing, part no. 4591-50-3
1. Space required: 2.55 m x 1.00 m
Safety zone: 2.25 m x 6.90 m
Total height: 2.45 m
Height of fall: 1.35 m
Fall of protection area: 15.5 m²
2. Specified ground surface:
Minimum thick-
ness of layer
mm
Maximum
height of fall in
mm
Other ground surface
material
Like tested according to
HIC
* In Germany, lawn is a sufficient ground surface in the safety zone for heights of up to
1,50 m .
3. Name and complete dimensions of the largest part of the equipment:
2 steel posts Ø 102 mm - 3,40 m long
4. Allowed age group: 4 years and up
5. Attention! Unit to be embedded in concrete
Concrete: C20/25 (B25)
Concrete requirement: ~ 0,77 m³
Size of excavation:
2x0,80 m long x 0,80 m wide, total depth 1,10 m including 10 cm percolation layer.
Size of foundation:2 x 0,80 m long x 0,80 m wide, height 0,60 m
6.
Upper edges of concrete are rounded! Foundation sizes apply for regular
soil classification 4-5 (grown surface).
Soil classification 4: Light up to medium plasticity, interlaced, with little
sediment (proportion < 30 % larger than 63 mm grain size in diameter)
Soil classification 5: Grounds of soil classification 3 and 4 with more
sediment (proportion > 30 % larger than 63 mm grain size in diameter)
For safety reasons, foundations of sandy, soft grounds should be lay-
ered with a larger surface of at least 50%.
7. Assembly time once steel masts are embedded in concrete:
Approximately 45 minutes. Number of persons required: 2
8. Any spare parts that may be required can be directly obtained by your supplier or Huck Seil-
technik GmbH
