Husky HOWT72XDB12/22 Manuale utente

Item # 1001513026

Model # HOWT72XDB12/22

USE AND CARE GUIDE

72 IN. WORKBENCH

Questions, problems, missing parts?

Before returning to the store, call

Husky Customer Service

8 a.m. - 7 p.m., EST, Monday-Friday

9 a.m.- 6 p.m., EST, Saturday

1-888-HD-HUSKY

HUSKYTOOLS.COM

Item # 1005430634

Keep the product on level surfaces. The product can

become unstable on uneven surfaces. The workbench may

tip over if stored or moved on an uneven surface. This may

cause personal injury, death, or product damage.

This full warranty gives you specic rights, and you may also have other rights, which vary from state to state.

Contact the customer service team at 1-888-HD-HUSKY or visit www.huskytools.com.

There is a one-year limited warranty for the solid wood top. This warranty excludes incidental/inconsequential damages and

failures due to misuse, abuse or normal wear and tear.

3000 lbs / 1360.5 kg

Part Part Code Description Quantity

AA L03457416 M6 x 16 hex socket head screw 38

BB L0408057 M8 washer 16

CC L0208405 M8 hex nut 8

DD L03081585 M8 x 85L hex bolt 8

EE K3145001 M12 x 50L Adjusttable foot 4

3WWW.HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

Open End Wrench (13 mm)

(not included)

Two open end wrenches (13 mm) are recommended. One to

screw the bolt, and another one to hold the nut while screwing

the bolt.

Husky 28" base cabinets with feet can be put under the

workbench. The workbench should be at a height where at least

10 holes in each bottom supporting frame post are visible.

Husky 28" base cabinets with casters can be put under the

workbench. The workbench should be at a height where 13 holes

in each bottom supporting frame post are visible.

To t base cabinet with feet, 10 holes visible.

To t base cabinet with casters, 13 holes visible.

5WWW.HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

Attach the Solid Wood Top and Upper Supporting Frames

After assembly, ensure that the back of the upper supporting

frames are flush with the solid wood top’s back.

Attach the upper and bottom supporting frames (C & D) together with

eight M8 x 85 hex boles (DD) and washers (BB) in the holes of the

supporting frames (C & D). Insert a washer (BB) and an M8 hex nut (CC)

onto the end of each M7 x 85 hex bold (DD). Tighten securely.

Attach the Bottom Supporting Frames

Attach the Front Stiffener

Attach the Back Stiffeners

7WWW.HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

Install the Adjustable Feet

Stand the Workbench Up

Stand the workbench up and place it on the desired level floor. Adjust the feet if necessary to make the workbench stable.

Part Part Code Description Quantity

A K2532091 Solid wood top 1

B B30150WT72E2487A Back stiffener 2

C DWT540011 Upper supporting frame 2

D DWT540021 Bottom supporting frame 2

E DWT540031 Front stiffener 1

AA L03457416 M6 x 16 hex socket head screw 38

BB L0408057 M8 washer 16

CC L0208405 M8 hex nut 8

DD L03081585 M8 x 85L hex bolt 8

EE K3145001 M12 x 50L Adjusttable foot 4

Questions, problems, missing parts? Before returning to the store,

call Husky Customer Service

8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m. EST Saturday

1-888-HD-HUSKY

HUSKYTOOLS.COM

Retain this manual for future use.

Artículo # 1001513026

Modelo HOWT72XDB12/22

GUÍA DE USO Y CUIDADO

72 plg (183 cm) BANCO DE TRABAJO

¿Preguntas, problemas, piezas faltantes?

Antes de regresar a la tienda, llama al Servicio al Cliente

de Husky, entre 8:00 a.m. y 7:00 p.m. (hora del Este), de

lunes a viernes, y los sábados entre 9:00 a.m. y 6:00 p.m.

(hora del Este).

1-888-HD-HUSKY

HUSKYTOOLS.COM

GRACIAS

Debido a mejoras continuas, el producto

real pudiera ser ligeramente diferente al

producto aquí descrito.

Apreciamos la plena confianza que has depositado en Husky al comprar este banco de trabajo. Nos esforzamos en crear continuamente

productos de calidad diseñados para mejoras del hogar. Visítanos por Internet para ver nuestra línea completa de productos disponibles

a fin de satisfacer la necesidades de mejoras de tu hogar. ¡Gracias por elegir Husky!

Artículo # 1005430634
