HyperX CloudX Flight HX-HSCFX-BK/WW Manuale utente

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 1 of 11

HyperX CloudX Flight™

Part Numbers

HX-HSCFX-BK/WW

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 2 of 11

TABLE OF CONTENTS

Overview .................................................................................................................................... 3!

Specifications ........................................................................................................................... 4!

Usage ......................................................................................................................................... 5!

Using with Xbox One® ............................................................................................................................................ 5!

Headset Controls .................................................................................................................................................... 6!

Headset Status Beep Tone Indicators .................................................................................................................. 8!

Headset Charging ................................................................................................................................................... 9!

Manually Pairing Headset and Wireless Adapter ................................................................ 10!

Questions or Setup Issues? .................................................................................................. 11!

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 3 of 11

Overview

A. Game balance button

B. Chat balance button

C. Microphone mute button

D. Ear cup LED

E. USB charge port

F. Power button

G. Microphone port

H. Volume wheel

I. Detachable microphone

J. Microphone mute LED

K. Wireless adapter

L. Wireless status light

M. USB charge cable

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 4 of 11

Specifications

Headphone

Driver: Dynamic, 50mm with neodymium magnets

Type: Circumaural, Closed back

Frequency response: 20Hz–20,000Hz

Impedance: 32 Ω

Sound pressure level: 113dBSPL/mW at 1kHz

T.H.D.: < 2%

Weight: 288g

Weight with mic: 298g

Cable length and type: USB charge cable (1m)

Microphone

Element: Electret condenser microphone

Polar pattern: Bi-directional, Noise-cancelling

Frequency response: 100Hz-10,000 Hz

Sensitivity: -51dBV (0dB=1V/Pa,1kHz)

Battery life*

30 hours - LED off

18 hours - Breathing LED

13 hours - Solid LED

Wireless Range**

2.4 GHz

Up to 20 meters

*Tested at 50% headphone volume

**Wireless range may vary due to environmental conditions

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 5 of 11

Usage

Using with Xbox One®

1. Connect the wireless adapter to a USB port on the Xbox One® system.

2. Power on the headset.

3. When the wireless adapter status light is solid, the headset is now connected to the adapter.

4. If logged in with an account, the Xbox One® will assign the headset to that account and notify the

user.

Note: Connecting the headset to the Xbox One® system does not automatically mute or adjust the

sound from the TV.

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 6 of 11

Headset Controls

Power button

Hold the power button for 3 seconds to power on/off the headset.

With the headset powered on, short press the power button to cycle through the ear cup LED modes.

The supported LED modes are solid (default), breathing, and off.

Volume wheel

Rotate the volume wheel up or down to adjust the volume level.

Power button

Volume wheel

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 7 of 11

Game/Chat balance buttons

Press the game/chat balance buttons to adjust mix between game audio and chat audio.

The game/chat balance functionality operates independently from the overall headset audio volume.

Microphone mute button

Press the microphone mute button to toggle the microphone mute. The microphone mute LED will

indicate the current mute status.

Microphone Mute LED

Mic Status

Muted

Off

Active

Hold the microphone mute button for 3 seconds to turn mic monitoring on/off.

Microphone mute button

Microphone mute LED

Game balance button

Chat balance button

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 8 of 11

Headset Status Beep Tone Indicators

The headset will emit beep tones to indicate status for power, volume, game/chat balance, microphone

mute, mic monitoring, and battery charge.

Power Status

Beep Tone Indicator

Power on

One tone (high)

Power off

Two tones (high, low)

Volume Status

Beep Tone Indicator

Setting to 100% maximum volume

Three tones (high)

Setting to 0% minimum volume

Three tones (low)

Game/Chat Balance Status

Beep Tone Indicator

Setting to 50% Game / 50% Chat

One tone (mid)

Setting to 100% Game / 0% Chat

Two tones (low)

Setting to 0% Game / 100% Chat

Two tones (low)

Microphone Mute Status

Beep Tone Indicator

Microphone muted

Two tones (high)

Microphone active

One tone (high)

Mic Monitoring Status

Beep Tone Indicator

Mic Monitoring enabled

One tone (low)

Mic Monitoring disabled

One tone (low)

Battery Status

Beep Tone Indicator

25% battery remaining

Two tones (low)

10% battery remaining

Three tones (low)

5% battery remaining

Five tones (mid, low, mid, low, mid)

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 9 of 11

Headset Charging

When the headset is connected to a charger with the USB charge cable, the ear cup LEDs will indicate

the charge status.

Ear Cup LEDs

Charging Status

Breathing

Charging

Off

Charging complete

Document No. 480HX-HSCFX.A01

HyperX CloudX Flight®

Page 10 of 11

Manually Pairing Headset and Wireless Adapter

The headset and wireless adapter are already paired together for first time use. If manual pairing is

necessary, follow the steps below to pair the headset and wireless adapter together.

1. Make sure the headset is powered off.

2. Plug the USB wireless adapter into the Xbox One® system.

3. Use a small pin to press the small button on the back side of the USB wireless adapter for 3

seconds. The USB wireless adapter LED will be fast blinking.

4. With the headset turned off, press and hold the headset power button for 10 seconds to enter

pairing mode. The headset earcup LEDs will blink rapidly.

5. When the USB wireless adapter LED turns solid and the headset ear cup LEDs have returned

to their last used mode, the pairing process has been completed.
