Plantronics VOYAGER 520 Manuale utente

BLUETOOTH®HEADSET

User Guide

사용 설명서

用户指南

使用者指南

2Plantronics Voyager 520

UK ENGLISH

TABLE OF CONTENTS

Welcome 3

What is Bluetooth? 3

Package Contents & Features 4

Charging 5

Pairing 6

Proper Fit 8

Headset Controls 9

Indicators 11

Range 11

Hands-Free Features 12

Multipoint 13

Accessories Available for purchase 14

Troubleshooting 15

Product Specifications 16

Technical Assistance 16

Plantronics Voyager 520

UK ENGLISH

WELCOME

Thank you for choosing the Plantronics Voyager™ 520 headset. To get the

most from your new headset, we recommend that you take the following

steps:

Please refer to the separate Safety Instructions booklet for important product

safety information prior to installation or use.

If you need assistance, please do the following:

Follow the steps in the “Troubleshooting” section on page 15.

Contact the Plantronics Technical Assistance Center at

www.plantronics.com/support.

Visit www.plantronics.com/productregistration to register your headset online

so we can provide you with the best possible service and technical support.

NOTE: If you are considering returning the product, please contact the Technical

Assistance Center ﬁrst.

•

WHAT IS Bluetooth?

Bluetooth wireless technology provides a way for devices to communicate

with each other using short-range radio frequency instead of wires.

Any two Bluetooth devices can communicate as long as they both have

Bluetooth turned on, they are within range and they have been paired–a

quick “handshake” process that connects the two devices.

Bluetooth range is up to 33 feet (10 metres). Obstructions, such as walls

or other electronic devices, can cause interference or shorten the effective

range. For optimal performance, place your headset and phone on the

same side of your body.

4Plantronics Voyager 520

UK ENGLISH

PACKAGE CONTENTS & FEATURES

Call control button

Wind screen

Adjustable ear loop

Ear tip

Charging jack

Noise cancelling

microphone

AC charger 100 – 240V

Desktop charging cradle

Plantronics Voyager 520

UK ENGLISH

CHARGING

Before you use your headset for the ﬁrst time, charge it for at least 1 hour.

It takes approximately 2 hours to fully charge your headset.

While your headset is charging the indicator glows red. When your

headset is fully charged, the indicator turns off.

There are two ways to charge the headset:

Use the AC charger to connect directly to a

power outlet.

Use the desktop charging cradle with the AC

charger.

Turn the charging cradle upside down and

slide off the cover.

Insert the AC charger cable into the charging

cradle.

Slide the charging cradle cover back into place.

Plug the AC charger into a power outlet.

Insert the headset into the charging cradle.

•

Red Flashes Battery Level

1 Less than 1/3 full

2 1/3 to 2/3 full

3 More than 2/3 full

WARNING: Do not use your headset while it is connected to the charger.

CHECK THE CHARGE LEVEL

When you turn on the headset, the indicator ﬂashes red to show the charge level.

6Plantronics Voyager 520

UK ENGLISH

PAIRING

Pairing is the process of introducing your headset to your phone.

Before using your headset for the ﬁrst time, you must pair it with your

Bluetooth phone. Normally you only need to pair your headset with

your phone once. To see a demo of the pairing process, visit

www.plantronics.com/EasyToPair.

QUICKPAIR™ TECHNOLOGY

Your new headset includes Plantronics QuickPair technology to simplify

the Bluetooth setup process. The ﬁrst time you turn your headset on, your

headset automatically enters pairing mode for 10 minutes. Once paired

successfully, your headset stays on for instant use.

If not successfully paired after 10 minutes, your headset automatically

powers off. When you turn the headset on again, it automatically goes into

pairing mode until successfully paired with a Bluetooth phone.

To pair your headset for the ﬁrst time:

Turn ON the Bluetooth feature on your phone.

TIP: For most phones, select Settings/Tools > Connections > Bluetooth > On.

See your phone’s user guide for more information.

Press and hold the call control button to turn on your headset. (The indicator

flashes red/blue to show that the headset is on and in pairing mode.)

TIP: If you don’t see the red/blue flash, press and hold the call control

button to turn your headset off, and then press and hold the call control button

again until you see the red/blue flash.

Use the commands on your phone to locate your headset.

TIP: For most phones, select Settings/Tools > Connections > Bluetooth

> Search > 520Plantronics. See your phone’s user guide for more information.

When prompted for the password, enter 0000.

When pairing is successful, the indicator on your headset flashes blue.

Your headset is now connected and ready to use.

Plantronics Voyager 520

UK ENGLISH

SUBSEQUENT PAIRING

If you’ve already paired your headset with another device, or you have

trouble pairing your headset, follow these steps:

Turn ON the Bluetooth feature on your phone.

TIP: For most phones, select Settings/Tools >Connections > Bluetooth >

On. See your phone’s user guide for more information.

Turn the headset off by pressing and holding the call control button until the

indicator turns red and then turns off.

Turn the headset back on by pressing and holding the call control button until the

indicator flashes red/blue. The headset is now in pairing mode.

Use the commands on your phone to locate your headset.

TIP: For most phones, select Settings/Tools > Connections > Bluetooth >

Search > 520Plantronics. See your phone’s user guide for more information.

When prompted for the password, enter 0000.

When pairing is successful, the indicator on your headset flashes blue. Your

headset is now connected and ready to use.

8Plantronics Voyager 520

UK ENGLISH

PROPER FIT

Lift the ear loop.

Swivel the ear loop to the right to wear it on your left ear, or swivel it to the left

to wear it on your right ear.

Place the ear loop behind your ear.

Rotate the headset so that the speaker rests comfortably in your ear.

Align the microphone with the corner of your mouth.

TIP: Callers can hear you best when you point the microphone towards the corner

of your mouth.

Right Left

Plantronics Voyager 520

UK ENGLISH

HEADSET CONTROLS

Action Steps

Turn on the

headset

Press and hold the call control button until the indicator

glows blue. The indicator then ﬂashes red up to three

times to show you the battery charge level.

See “Check the charge level” on page 5 for details.

Turn off the

headset

Press and hold the call control button until the indicator

glows red. When the power is off, the indicator stays off.

Answer a call Brieﬂy press the call control button.

Reject a call Press the call control button for 2 seconds to reject the call.

End a call Brieﬂy press the call control button.

Make a call The call automatically transfers to your headset after you

enter the number on your phone and press send.

Adjust volume Push the call control button up to increase the listening

volume or down to decrease the volume.

WARNING: Do not use headphones/headsets at high volumes

for an extended period of time. Doing so can cause hearing loss.

Always listen at moderate levels. See www.plantronics.com/

healthandsafety for more information on headsets and hearing.

Transfer a call

from the headset

to the phone

Press and hold the call control button until you hear a

long low tone.

Transfer a call

from the phone

to the headset

Brieﬂy press the call control button.

10 Plantronics Voyager 520

UK ENGLISH

TIPS

If you’re wearing the headset, you hear ascending tones when the power turns

on and descending tones when the power turns off.

When you receive a call, your phone may ring before your headset rings. Wait

until you hear the ring in your headset before you press the call control button

to answer the call.

For best performance, position your phone on the same side of your body as

your headset.

To quickly re-connect to your recently used device that is within range, briefly

press the call control button.

To cancel an outgoing call, briefly press the call control button.

If your phone supports voice dialling see Hands-Free Features on page 12 for

instructions.

•
