ICW UL90 Manuale utente
ICWUL90Installation
Wall Mount Desk Mount
Pole Mount Radius Mount
Locatethestudinthewallyouaremountingtoandmarkthetophole.
Drill11/64pilotholeandinserttheprovided#14wood screw,tightening
slightly. Usingalevel,markthelowerholeanddrillpilothole, insertthe
last#14screw and, with the unitlevel,tightenbothscrews.
Note:ICW supplies #14 woodscrews,ifinstallinginto metal studs
youwillneedtouse proper metal stud fasteners.
Ifyour monitorisover17” themountmaybe moreeffectiveifmounted
upsidedown.
WallMount
Nylock
Largewasher
Desk
Drilla3/8hole throughthehorizontalsurfaceyou intend
tomounttoand push the 3/8 stud on the deskmountthrough
the hole. Slip the largemountingwasheroverthestud from
underneathandsecure in place with the 3/8nylock.
Screwstudinto
deskmount.
Desk Mount
Pole Mount Usingthe 1/4” hexkey,
separatethetwohalvesof
yourpole mount as shown,
placearoundpole at the
desiredheight andreassemble.
Setscrews
Usinga 1/8” hex key,makesurethe set screws
inthe radiusmountarepulledoutenoughthat
themountwilleasilyslide downoverthe pole.
Thenretighten setscrews.
Pole
Radius Mount
2
MounttheVesaplateto the frictionmount
usingthe5/32”hex key and the 1/4-20flat-
headscrewsinyour hardware bag.
Attachyourmonitortotheul90using
the4mmscrewsinyourhardware bag.
Usethehandlestoadjust
thetiltofyourmonitor.
Thankyouforyourpurchase of anICWUL90monitor
mount.
Anyquestions please contact ICW at:1-800-558-4435
