Ikan ID 500 Manuale utente

ID 500-KIT

ID 500 Three Point Light Kit QUICKSTART GUIDE

www.ikancorp.com

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period has expired.

Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.

3903 Stoney Brook Dr. Houston TX 77063

1.713.272.8822

[email protected]

What’s included

Checked by

 3 x ID 500 Light

 3 x AC Adapter + Power Cord

 3 x Remote Control

 3 x Light Stand

 1 x Light Carrying Bag

 1 x Light Stand Carrying Bag

ID 500-KIT

ID 500 Three Point Light Kit QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

GETTING STARTED

1. Connect the included AC Adapter to power the ID 500 light.

2. Turn the light on / off with the Power Switch.

3. Control the amount of the light with the Dimmer knob. Adjust the intensity of the light by

turning the Dimmer Knob clock-wise to increase the intensity and counter clock-wise to reduce it.

4. The ID 500 can also be powered by pro battery (optional accessories).

FUSE

Power Switch

Fuse

Vents

Mounting

Pro Battery

Option

Back View

Dimmer knob

DC Power Connection

Handle

(The handle can easily be mounted on any side of the fixture

- left, right, top or bottom. Simply slide it into one of the four

grooves, position it and tighten down into place.)

Bank Switches

Put it Where You Want It

The ID 500 comes with a movable and detachable

Light Stand Adapter allowing you to mount your light

either horizontally or vertically.

ID 500-KIT

ID 500 Three Point Light Kit QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Operation

Indicator

On/Off Remote Control Buttons

A. Power On/Off

Press and hold for 5 seconds to sync remote control to light.

B. Press button to adjust 4 levels of light intensity.

Press and hold for 5 seconds to enable/disable sound.

C. Hold down to increase light intensity

D. Hold down to decrease light intensity

SPECIFICATIONS

Operating Volts: 12v - 14.4v

Wattage: 30w

Brightness: 2.55Klux/50cm

Color Temperature: 5600K

Dimension: 13.8” x 7.5” x 2.7”

Weight (lbs): 5.8

• Pro Battery Option

Optional Accessories

• V17PBK-S Pro Battery Kit $149.00

• V17PBK-A Pro Battery Kit $149.00

• IB-L130A AB Mount Professional Battery $375.00

• IB-L130S V Mount Professional Battery $375.00

ID 500-KIT

ID 500 Three Point Light Kit QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

ID 500 LUX Drop Off
