Ikan IFB1024 Manuale utente

IFB1024

1024 Featherweight Dual-Color LED Light QUICKSTART GUIDE

www.ikancorp.com

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period has expired.

Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.

3903 Stoney Brook Dr. Houston TX 77063

1.713.272.8822

[email protected]

© 2010 ikan Corporation. All right reserved

What’s included

Checked by

 IFB1024

 AC Adapter + Power Cord

 Remote Control

Yoke

 Diffuser

 Pro Battery Plate (Check one)

 AB-Mount

 V-Mount

IFB1024

1024 Featherweight Dual-Color LED Light QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Diffuser Lock

GETTING STARTED

1. Connect the included AC Adapter to power the IFB1024 light.

2. Turn the light on / off with the Power Switch.

3. Control the amount of the light with the Dimmer knob. Adjust the intensity of the light by

turning the Dimmer Knob clock-wise to increase the intensity and counter clock-wise to reduce it.

4. The IFB1024 can also be powered by pro battery.

www.ikancorp.com

MADE IN CHINA

IFB1024

Model: LED1024ASL

Operating Volts: DC 12V - 14.8 V

Pin number Signal

1

2,3

4

GND

-

+12V

Do not block the vents or look directly

at the LED lights while its on.

1

23

4

3200K 5600K 10% 100%

ON

OFF

POWER

DC

12V

~

~

Yoke

Pro Battery Plate

Color

Temperature

Knob

Brightness

Power Switch

DC Power

Connection

LCD Touch

Screen

Yoke

Adjustment

Knob

IFB1024

1024 Featherweight Dual-Color LED Light QUICKSTART GUIDE

www.ikancorp.com 713-272-8822

Operation

Indicator

On/Off Remote Control Buttons

A. Power On/Off

Press and hold for 5 seconds to sync remote control to light.

B. Press button to adjust 4 levels of light intensity in increments of 25.

Press and hold for 5 seconds to enable/disable sound.

C. Hold down to increase light intensity

D. Hold down to decrease light intensity

SPECIFICATIONS

Brightness: 10020 Lux/930.88 fc / 61cm/24.01in

Angle: 60

Color Temperature: 3200K - 5600K

Power Output: 35W

AC/DC Power Input: AC110V/AC220V, DC12V (AC Adapter 110V-240V)

External Battery Voltage: 14.8V (AB-Mount or V-Mount)

Dimension: 403(W) x 450(H) x 95(D) mm / 15.86(W) x 17.71(H) x 3.74(D) in

Weight: 2.7kg / 5.95 lbs

Optional Accessories

• IB-L130A AB Mount Professional Battery

• IB-L130S V Mount Professional Battery

• IB-LD160 A

• IB-LD160 S

• C-2KA-KIT

• C-2KS-KIT

(Battery Not Included)

A

B

C

D

°
