Ikan IFB576 Manuale utente
IFB576
576 Featherweight Dual-Color LED Light QUICKSTART GUIDE
www.ikancorp.com
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period has expired.
Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.
3903 Stoney Brook Dr. Houston TX 77063
1.713.272.8822
© 2010 ikan Corporation. All right reserved
What’s included
Checked by
IFB576
AC Adapter + Power Cord
Remote Control
Yoke
Diffuser
Pro Battery Plate (Check one)
AB-Mount
V-Mount
IFB576
576 Featherweight Dual-Color LED Light QUICKSTART GUIDE
www.ikancorp.com
www.ikancorp.com
713-272-8822
Diffuser Lock
DC
12V
POWER
OFF
ON
10%Y100%
3200KY5600K
Yoke
Yoke
Adjustment
Knob
Pro Battery Plate
Color
Temperature
Knob
Brightness
Power
Switch
DC Power
Connection
LCD Touch
Screen
GETTING STARTED
1. Connect the included AC Adapter to power the IFB576 light.
2. Turn the light on / off with the Power Switch.
3. Control the amount of the light with the Dimmer knob. Adjust the intensity of the light by
turning the Dimmer Knob clock-wise to increase the intensity and counter clock-wise to reduce it.
4. The IFB576 can also be powered by pro battery.
IFB576
576 Featherweight Dual-Color LED Light QUICKSTART GUIDE
www.ikancorp.com 713-272-8822
Operation
Indicator
On/Off Remote Control Buttons
A. Power On/Off
Press and hold for 5 seconds to sync remote control to light.
B. Press button to adjust 4 levels of light intensity in increments of 25.
Press and hold for 5 seconds to enable/disable sound.
C. Hold down to increase light intensity
D. Hold down to decrease light intensity
SPECIFICATIONS
Brightness: 5600 lux/520.25 fc / 61cm/24.01in
Angle: 60
Color Temperature: 3200K - 5600K
Power Output: 35W
AC/DC Power Input: AC110V/AC220V, DC12V (AC Adapter 110V-240V)
External Battery Voltage: 14.8V (AB-Mount or V-Mount)
Dimension: 403(W) x 300(H) x 95(D) mm / 15.86(W) x 11.81(H) x 3.74(D) in
Weight: 1.9kg / 4.18 lbs
Optional Accessories
• IB-L130A AB Mount Professional Battery
• IB-L130S V Mount Professional Battery
• IB-LD160 A
• IB-LD160 S
• C-2KA-KIT
• C-2KS-KIT
(Battery Not Included)
A
B
C
D
°
