RLB48-M2

Quick Start Guide

Oryon 18” Bi-Color 2700K-5600K Ring Light (Version 2)

What’s Included

1 x 18” Ring Light

1 x 18” Carry Bag

1 x Phone Mount

1 x Power Cord

1 x Remote Control

www.ikancorp.com | 1.713.272.8822 | [email protected]

Warning

Light Overview

- Do not expose the light to rain or extreme moisture conditions.

- The ring light does not have charging capabilities. Use a dedicated charger to charge batteries.

- Do NOT use both AC adapter and battery at the same time.

- Do not attempt to open or modify the ring light.

1. Shoe Mounts

2. Smartphone Holder

3. ¼”-20 Threads

4. Battery Slots

5. Light Angle Knob

6. Locking Knob

7. Brightness/Standby Knob

8. Color Temperature Knob

9. Power Switch

10. 18V DC Port

11. 5V 2A USB Power Output

12. Battery Level Indicator

13. Ring Light Mode

14. Brightness Display

15. Color Temperature Display

4 4

2

33

1

1

1

5

9

712

14

15

13

8

10 11

6

1

1

www.ikancorp.com | 1.713.272.8822 | [email protected]

Remote Control Operations

Basic Operation

The light can be powered with either the included power adapter or with L Series battery. For L series

battery use either the F750 or F970.

Press the switch to the on side to power the light on. You can put the light into a standby mode by

pressing the Brightness Knob. This will turn the LEDs off. While in standby mode the light can still be

controlled with the included remote control.

Use the Brightness Knob to adjust the brightness from 0% to 100%. Brightness increases and

decreases by values of 1%.

Use the Color Temperature Knob to adjust the color temperature from 2700K to 5600K. Color

temperature increases and decreases by values of 100K.

Standby On / Off Night Light Mode

Increase Brightness

Increase Color Temperature

5600K Max Brightness

4100K Max Brightness

5600K Half Brightness

2700K Half Brightness

Memory Save / Recall

Decrease Color Temperature

Decrease Brightness

2700K Max Brightness

4100K Half Brightness

www.ikancorp.com | 1.713.272.8822 | [email protected]

Speciﬁcations

Input Power 110V/240V 50Hz/60Hz

Output Power 90W

Brightness Range 0% - 100%

Color Temperature 2700K - 5600K

CRI 97

TLCI 98

Dimensions Internal Diameter - 12.4 in. / 31.5 cm

Outer Diameter - 18 in. / 45.5 cm

Thickness - 1.4 in. / 3.5 cm

Ring Light Modes

Ch.0 – Standby Mode

Ch.1 – Manual Control Mode

Ch.2 – 5600K @ 50% Brightness

Ch.3 – 4100K @ 50% Brightness

Ch.4 – 2700K @ 50% Brightness

Ch.5 – 4100K @ 100% Brightness

Ch.6 – 5600K @ 100% Brightness

Ch.7 – 2700K @ 100% Brightness

Ch.8 – 4100K @ 4% Brightness

www.ikancorp.com | 1.713.272.8822 | [email protected]

Learn More

More dynamic information at ofﬁcial website: www.ikancorp.com

Support

Contact email: [email protected]

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manu-

facturing errors.

• The components and maintenance service fee will be charged if the warranty period is

expired.

Free Service will not be Provided in the Following Situations:

(Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made

by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.

©2020 Ikan International. All rights reserved.
