Ikegami ULE-185U Manuale utente
Installation and User's Guide
All contents of this document may change without prior notice, and actual product appearance may differ from that depicted herein
BROADCAST/SURVEILLANCE APPLICATIONS
ULE-185U REV.F
Installation and User's Guide
2
<TABLE OF CONTENTS>
1 SAFETY INSTRUCTION 3
2 FCC RF INTERFERENCE STATEMENT 7
3 INSTALLATION 8
4 OSD MENU SETTING 12
5 FEATURE 18
6 TROUBLESHOOTING 19
Installation and User's Guide
3
•Follow this safety instruction to use the monitor properly and prevent the damage.
•Keep this user’s guide book for later use.
1. SAFETY INSTRUCTION
* This safety instruction has “Warning” & “Caution” as below
Warning - If the user does not follow this instruction,
it may cause the serious damage to the user.
Caution - If the user does not follow this instruction, it may cause the slight
damage to the user or cause some damages to the monitor.
Warning
Never remove the back cover and touch
the inside of the monitor.
If you need a service, please contact the
service center.
Keep away the monitor from the
direct sunlight and a heating appliance.
Never put objects of any kind into this
product as they may result in a risk of fire
or electric shock.
Connect the power cord to the wall
outlet tightly. If the power cord or plug are
defective and the wall outlet is not
tight, please do not use them.
Installation and User's Guide
4
Warning
Do not install this monitor on the outside
and near water. It may cause damage to
the product, electric shock and fire.
When lightning and thundering, unplug
the monitor from the wall outlet and
never touch it.
Unplug this product from the wall outlet,
when it does not operate for a long time.
When smoking and noising from the
monitor, unplug the product from the wall
outlet and contact a service center.
WARNING: How to fix
Do not open this product as it contains high voltage inside.
It may create an electric shock.
If the user disassembles and remove the back cover, it does not make sure
to make up for the damage and do a service and exchange the monitor.
For cleaning do not use liquid cleaners.
Never touch the power plug with wet-
hands.
Installation and User's Guide
5
Cautions
Install this monitor some distance
from the wall and do not install unless
proper ventilation is provided.
Place this product on a stable place.
If not, it may fall, causing serious
damages to the monitor and people.
The openings must not be blocked by
curtain, rug or other similar surface.
Before carrying the monitor, turn it off and
unplug the signal cables and the power
cord from the wall outlet.
When carrying this monitor, be careful
not to damage the panel and drop it
It may cause some trouble.
Take the power plug out from the wall
outlet.
Do not pull the cable. It may snap the
inner-wires and cause overheating and fire.
Installation and User's Guide
6
Cautions
Install this monitor about 50cm far from
the eyes and an angle of 0~15 degrees
below eyes. Too close installation may
cause having weak sight.
Do not press the LCD panel with hands or
the sharpened material hardly.
For cleaning, unplug the monitor from the
wall outlet. Do net use the liquid cloth.
Use the soft cloth.
Do not use the chemical liquid for cleaning.
It may cause fading and breakage.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR WATER.
Instructions for Disposal of Electrical and Electronic Equipment in Private Households
Disposal of used Electrical and Electronic Equipment
(Applicable in the European Union and other European countries with garbage separate
disposal and collection methods)
This symbol on the product, or in the related documents in the package, indicates that this
product shall not be treated as normal household waste. Instead, it should be taken to a proper
applicable collection point or depot for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent possible negative consequences for
the environment and human health, which could otherwise be caused by inappropriate waste handling of
this product. The recycling of materials will help to conserve natural resources.
For more detailed information about recycling of this product, please contact your local city authority,
your household waste disposal service or the place where you purchased the product.
Installation and User's Guide
7
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio, TV technician for help.
- Only shielded interface cable should be used.
Finally, any changes or modifications to the equipment by the user not expressly approved by the grantee or
manufacturer could void the users authority to operate such equipment.
DOC COMPLIANCE NOTICE
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out
in the radio interference regulation of Canadian Department of communications.
2. FCC RF INTERFERENCE STATEMENT
3. INSTALLATION
User Manual
Adapter
Trigger Cable
LCD Monitor
Remote Controller
Power Cable
Battery
3-1 Parts
VGA Cable
Installation and User's Guide
8
3-2 How to Install
1) KEY BUTTON
SHORT KEY FUNCTION
OSD Key Function
MENU Activate the menu function / Exit from the menu
SOURCE / ▼Input source menu / Source selection(move down from OSD menu)
AUTO / ▲Auto-fit screen with PC-RGB input / move up from OSD menu
◀(VOL) Decrease the level of volume and move the previous menu
(VOL)▶Increase the level of volume and select the OSD menu
Power On / Off
LED
Red : Power Off state
Green : Power On and available input signal state
Orange : When DPMS "ON" state, no input signal
▲+◀Press “▲ , ◀” Key 10 seconds simultaneously to lock /
unlock OSD Key
Installation and User's Guide
9
① ② ③ ④ ⑤ ⑥
⑦
⑧
⑨
⑩
⑪
①DC 12V DC adapter input
②AUDIO(VIDEO-1) Stereo audio input for VIDEO-1
③AUDIO(VIDEO-2) Stereo audio input for VIDEO-2
④VIDEO-1 IN/OUT VIDEO-1 signal input/output
⑤VIDEO-2 IN/OUT VIDEO-2 signal input/output
⑥TRIGGER TRIGGER signal input
⑦HDMI HDMI signal input
⑧VGA VGA(PC RGB) signal input
⑨AUDIO(PC) Stereo audio input for VGA
⑩For FW Update
⑪SDI IN/OUT SDI signal input/looping out
2) CONNECTION
Installation and User's Guide
10
