Ikelite 6210.61 Manuale del proprietario

Digital Housing

Supplemental Instructions

6210.61 Sony DSC-W610

Size and Weight

Width ......................6.2 in. (157mm) including controls

Height ....................4.4 in. (112mm) including controls

Depth ......................3.8 in. (97mm) including controls & lens port

Weight ....................1.2 lb (544g)

Buoyancy ................Slightly positive in fresh water

Parts of the Housing

Front View

Shutter

Button

On/Off Button

1. Zoom (wide)

2. Zoom (telephoto)

3. ode Switch

4. Playback

5. Display

6. Smile

7. Set

8. Flash

Lanyard

Tray ounts

6 7

ULTRAcompact

Made in USA

IKELITE

9. enu Button

10. Self-Timer

11. Delete

Back View

Latch

Lens Port

Initial Camera Settings

- Insert and Format an SD memory card.

- Set Date and Time.

- Set REC ode to “P” Program Auto.

- Set Still Image Size to “14 .”

- Set Burst Settings to “Single.”

- Set ISO to “80.”

- Set White Balance to “WB Auto.”

- Set Focus to “Center AF.”

- Set etering ode to “Center.”

- Set DRO to “DRO standard.”

- Set Flash to “On always use flash.”

- Set Red-Eye Reduction to “Off.”

NOTE: If overexposure occurs, use “-” exposure compensation and/or back

away from your subject and zoom in. When using an AF35 strobe or

manual controller, turn the power down.

External Accessory Lenses

- Attach 46mm threaded #6420.46 Ikelite W-20 Wide-Angle Lens or other

compatible lenses directly to the front of the port.

- Attach 67mm threaded #6420 Ikelite W-20, Inon Type II and Epoque

wide-angle lenses using the #9306.81 port adapter. This adapter may

also be used to attach other compatible 67mm threaded macro lenses.

- Attach bayonet style Inon macro or UWL-100 28AD, UWL-105AD and

UFL-165AD wide angle or macro lenses using the #9306.79 port adapter.

oderate to extreme vignetting (shading in the corners) will be present in

the widest setting when using an external accessory lens. This effect can

be eliminated by zooming in slightly.

www.ikelite.com

6210.61_Sony_W610_1-0312

Ikelite Underwater Systems

50 West 33rd Street

Indianapolis, IN 46208 USA

Ikelite Technical Support

Email: [email protected]

Phone 317.923.4523

Fax 317.924.7988

AF35 Stro e Package 4035

The AutoFlash AF35 kit is a great compliment, and

an effortless, affordable way to add a flash to your

new Ikelite point and shoot camera system.

Everything you need to get started is in the box.

Just attach it to the bottom of your housing and

start taking pictures!

AF35 AutoFlash kit includes:

AF35 strobe - Flex arm - AutoFlash sensor

Handle with rubber grip - Tray (single or dual)

ounting hardware.

ikelite

AUTOFLASH

A full range of accessories is available to support your housing. Please

visit http://www.ikelite.com to see the most current information about

recommended accessories for your housing.
