Infineon iMOTION2go Manuale utente
Please read the Important Notice and Warnings at the end of this document
www.infineon.com page 1 of 15
AN2019-11 iMOTION2go User Manual
iMOTION2go User Manual
iMOTION™ starter kit for iMOTIONTM design platform
About this document
Scope and purpose
This application note provides an overview of the evaluation board iMOTION2go including its main features,
key technical data, pin assignments and mechanical dimensions.
iMOTION2go is a full motor-control system starter kit including an IMC101T-T038 controller, an inverter IPM and
a brushless direct current (BLDC) motor load, which provides a ready-to-use hardware setup for using the
iMOTIONTM design platform, MCEDesigner and MCEWizard. It also comprises other necessary
software/parameter configurations required for directly running a motor with the iMOTIONTM motor-tuning
tool, MCEDesigner, to evaluate all the features of the iMOTIONTM design ecosystem.
The IMOTION2go starter kit was developed to support customers during their first steps designing applications
with the iMOTIONTM design ecosystem. It also can be used by engineers to debug their script code.
The starter kit iMOTION2go is not intended to be used for real motor-control application designs such as
a home appliance and/or light industrial application field.
Intended audience
This application note is intended for all electrical engineers who are interested in evaluating Infineon iMOTION
motor-control products, in particular iMOTION tools and software. The iMOTION2go evaluation board is
intended to be used with a PC (plugged into the USB port of a PC) under no-load motor conditions.
TM
2 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
Safety precautions
Table of contents
About this document....................................................................................................................... 1
Table of contents............................................................................................................................ 2
1Safety precautions ................................................................................................................. 3
2Introduction .......................................................................................................................... 4
3Main features......................................................................................................................... 5
4LED, connector and tuner........................................................................................................ 7
5Schematics and layout............................................................................................................ 8
6Getting started with iMOTION2go ...........................................................................................11
7Reference.............................................................................................................................13
Revision history.............................................................................................................................14
TM
3 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
Safety precautions
1Safety precautions
Please note the following warnings regarding hazards associated with development systems.
Table 1 Precautions
Caution: The iMOTION2GO system contains parts and assemblies sensitive to
electrostatic discharge (ESD). Electrostatic control precautions are required when
installing, testing, servicing or repairing the assembly. Component damage may result
if ESD control procedures are not followed. If you are not familiar with electrostatic
control procedures, refer to the applicable ESD protection handbooks and guidelines.
Caution: Bad handling or application errors such as touching the motor winding wire,
clamping the motor, bending the board, supplying an incorrect or inadequate DC
supply, or excessive ambient temperatures may result in system malfunction.
Caution: The iMOTION2GO system is designed for software tools learning and
practicing. It is not a hardware design reference for a power load. Operating with any
additional load may cause board malfunction or damage.
TM
4 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
Introduction
2Introduction
The iMOTION2go starter kit is designed to present an easy-to-use motor drive solution based on Infineon's
iMOTIONTM controller and design platform. The board contains a USB interface, a DC/DC converter, an IMC
controller, an IPM, and a 3-phase BLDC motor.
The features of this board are described in the design feature chapter of this document, whereas the remaining
paragraphs provide information to help users to copy, modify and qualify the design for production according to
their own specific requirements.
The boards provided by Infineon are only subject to MCEDesigner & MCEWizard functional testing.
This board is intended to be used under no load conditions and only for purpose of evaluating iMOTION motor
control software and tools.
The block diagram of the iMOTION2go is depicted in Figure 1.
Figure 1 iMOTION2go block diagram
TM
5 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
Main features
3Main features
iMOTION2go starter kits are intended for learning and practicing the iMOTIONTM design platform, MCEDesigner
and MCEWizard. The main features of MCEWizard include:
Creation of parameter sets for full motor control system
Design of a script code for application adaption
Configuration for individual digital pins and analog pins
The main features of MCEDesigner include:
Programming and updating of code/parameters to controller IC
Controlling, monitoring and tuning of the motor drive system
Setup of a function that commands speed profiles for testing of specific application
The main characteristics of the demo board include:
Entire motor control system
Powered by PCB USB output
No hardware setup needed
Algorithm integrated in IMC101 iMOTION motor controller
System parameters pre-configured for instantaneous start of the motor
Pre-loaded with script that runs the varying speed demo
Free software tools for system monitoring and tuning
On-board-debugger chip for communication and programming of IMC101T chip
Table 1 lists all the important specifications of the evaluation board IMOTION2go.
Table 1 iMOTION2go specifications
Parameters
Values
Conditions
Input voltage
5 Vrms
USB socket
Motor phase current
50 mArms
Maximum DC bus voltage
16 V
generated on board
Minimum DC bus voltage
14 V
Shunt resistor RS1
1000 mΩ
Single shunt configuration
IPM power supply
15V±5%, max. 50 mA
For inverter IPM
Controller power supply
3.3V±2%, max. 20 mA
For IMC101T
PCB material
FR4, 2 layers, 2 oz
copper
PCB dimensions
62 mm x 22 mm
Ambient temperature
From 0 to 60°C
TM
6 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
Main features
Figure 2 points out the functional parts of the iMOTION2go demo board.
Figure 2 Functional part of the iMOTION2go
3
1
2
4
1. USB interface
2. IMC101T controller
3. IRSM836-015 3-phase
inverter IPM
4. BLDC motor
TM
7 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
LED, connector and tuner
4LED, connector and tuner
Table 2 Description of on-board LED, connector and tuner
Name
Description
LED1
System status
LED2
Script running status
LED3
Power supply monitor
RP1
Motor speed reference(tuned by a screwdriver)
X1
Programming port
Figure 3 LED, connecter and tuner
Screwdriver for speed tuning
LED3
RP1
LED2
X1
LED1
TM
8 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
Schematics and layout
5Schematics and layout
Given its pure demonstration purpose, with focus on tools, this board is not intended to be used as a reference
for hardware design, the schematics and layout are included in this chapter for better understanding system. In
Figure 4, Figure 5, Figure 6 and Figure 7, an overview of the different parts of the iMOTION2go are presented.
Figure 4 On-board debugger
TM
9 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
Schematics and layout
Figure 5 Controller
Figure 6 Power supplies
TM
10 of 15
iMOTION2go
Starter kit for iMOTIONTM ecosystem application note
Schematics and layout
Figure 7 Power inverter
Figure 8 Top assembly print of the iMOTION2go evaluation board
