InfiRay IRS-FB4 Series Manuale utente
Dual-spectrum Network
Bullet Camera
User Manual
V1.0.2
IRay Technology Co., Ltd.
I
Important Safety Instructions
In order to avoid danger or property damage, the following right usage rules are for
you to follow.
Please read the instructions carefully and rigorously follow the instructions before
usage. The User Manual should be carefully kept after being read.
It indicates that low or medium potential risk is existing. The ignore
of the instructions may lead to light or medium damage for people.
It indicates that potential risk is existing. The ignore of the
instruction may lead to device damage, data loss, device
performance degradation or other unpredictable results.
It indicates that this is the additional information which can
emphasize and implement the main text content.
⚫The local electrical safety standards should be rigorously followed in the
process of installation and usage.
⚫Please use power adapter which is produced by regular companies. Please
check whether the power is normal or not before the device is operated. (Power
supply requirements should comply with those on the device labels.)
Dual-spectrum Network Bullet Camera User Manual
II
⚫In order to make emergency power off when necessary, please install
power-off equipment which is easy to use when installing the wires.
⚫Please protect power lines from being treaded or pressed, especially the
connecting points which are led from the plug, power socket or other unit.
⚫Please make sure the camera is fixed firmly if it’s being installed on walls or
ceilings.
⚫If the camera does not work normally, please contact shops or factories. Do not
disassemble or revise the product in any way (Our company is not responsible
for the problems which are caused by unauthorized modification or
maintenance.)
⚫Please do not place the device in damp, dusty, extremely hot, extremely cold
places or places with corrosive gas or unstable light.
⚫The camera should be transported, used and stored in allowable humidity and
temperature range.
⚫Avoid making the lens aiming at strong light (e.g. sun or laser), or else the
image sensor would be damaged.
⚫Please do not block the vents near the camera in case of heat accumulated.
⚫Please transport the devices with the factory packaging or the packaging
Dual-spectrum Network Bullet Camera User Manual
III
materials of the same quality.
⚫Please do not press, vibrate violently or soak the camera during transportation,
storage or installation.
⚫It is advised to use the camera with lighting protector.
⚫Soft dry cloth can be used to clean the device. For the dirt difficult to clean,
please use soft cloth with little neutral detergent and then wipe dry. Do not use
volatile detergent like alcohol, benzene or diluent, or strong and abrasive
detergent, or else the camera coating would be damaged and also the camera
performance could be reduced.
⚫The lens cover is optical device, so please do not touch directly or wipe the
cover. Soft brush or hairdryer can be used to blow the dust away. For the
grease or fingerprint, soft cloth can be used to wipe it away. Cotton cloth or
lens cleaning paper with cleaning solution can be used to wipe repeatedly until
it’s clean.
⚫Please revise the password promptly after logging in in case of being
embezzled.
⚫Please use the accessories or parts which are confirmed by manufacturers and
installed or maintained by the service professionals.
Dual-spectrum Network Bullet Camera User Manual
IV
Table of Contents
Important Safety Instructions ..............................................................I
1. Product Introduction .........................................................................1
1.1 Product Description ...........................................................................1
1.2 Product Feature ..................................................................................1
2. Operation Guide ..................................................................................2
2.1 Preparations........................................................................................2
2.2 Brief Introduction of Interface...........................................................3
2.2.1 Log in ........................................................................................3
2.2.2 Brief Introduction of Preview Interface ...................................4
2.2.3 Introduction of Playback Interface ...........................................7
2.2.4 Introduction of Settings Interface .............................................8
2.3 Settings ...........................................................................................8
2.3.1 Basic setting..............................................................................8
2.3.2 Network Set ............................................................................13
2.3.3 Channels Parameter Set ..........................................................16
2.3.4 Infrared Parameters Setting ....................................................21
2.3.5 Alarm Set ................................................................................28
2.3.6 Storage Set ..............................................................................36
1
1. Product Introduction
1.1 Product Description
Dual-spectrum Bullet Camera is a new-type thermal imaging net camera
integrated with the functions of Internet remote monitoring, video server and high
definition camera. The high- definition optical camera and advanced IR thermal
imaging detectors are installed in this product, so it can realize the function of
dual-spectrum shooting, and at the same time comprehensively collect the
characteristic information of the monitoring scenes. It can also be widely used in
the intelligent safety surveillance fields of indoor and outdoor environmental
monitoring, perimeter prevention, industrial temperature measuring and fire
alarm.
1.2 Product Feature
⚫The latest InfiRay® 12μm IR thermal imaging detector, advanced IR vision
algorithm, more distant and clearer image.
⚫Function of front-end independent temperature measuring; installed with
professional temperature measuring analysis tools and multiple linkage alarm
rules; function of fire point detecting alarm.
Dual-spectrum Network Bullet Camera User Manual
2
⚫Function of intelligent behavior analysis, such as regional invasion detecting,
boundary violation detecting, entering and leaving area detecting and left items
detecting, etc.
⚫One-piece shell, with outdoor protection class IP66.
⚫ONVIF standard interface protocol supported, available SDK, secondary
development and third-party platform connection supported.
2. Operation Guide
2.1 Preparations
1) The factory default IP address is：192.168.1.19.
2)The subnet mask is 255.255.255.0.The IP address can be changed, for example,
you can change the IP address into 192.168.1.194;the IP address of your
computer should be in the same network segment with your network video
server, and the subnet mask should also be the same, for example, the IP
address can be set as 192.168.1.120.
3)To test the whether the device is started normally or not. Following the
operation of <Start→run→cmd> on Windows. Open command line window in
which you can input Ping 192.168.1.19. If “Request time out” is not displayed,
then it indicates a normal start.
4)The OCX files must be installed when visiting the video server for the first
time with Internet Explore.
Dual-spectrum Network Bullet Camera User Manual
3
5)Install the plug-in after quitting the antivirus software such as 360.
2.2 Brief Introduction of Interface
2.2.1 Log in
1）Input http://192.168.1.19 into the address bar of the IE browser, the login
interface is shown in the following figure:
Figure 2.1 Login Page
2）Read carefully about the web prompt. Please click the button of “please
click this link to download and complete the installation of the OCX file” if
needed, then you can finish installing according to the prompt.
3）If the IE browser version is below 6.0, please update it into IE6.0 or above
version browsers.
Dual-spectrum Network Bullet Camera User Manual
4
4）Input Username:888888(factory default, administrator) or 1(normal user);
5）Input password: 888888(factory default, administrator) or 1(normal user)
6）Click “OK” to enter the preview of the video server. As is shown in the
following figure:
Figure 2.2 Preview Page
2.2.2 Brief Introduction of Preview Interface
Real-time Preview Option:
【Network Mode】：TCP and MultiCast, you can choose unicast preview or
multicast preview as you need.
【Live Video Play】：click to play live videos of both channels in
the preview window.
Tick 1 or 2 to broadcast the live video of channel 1 or channel 2.
【Stop Video Broadcast】：click to stop broadcasting live videos of
both channels in the preview window.
Cancel the tick to stop broadcasting the live video of channel 1 or
Dual-spectrum Network Bullet Camera User Manual
5
channel 2.
【Alarm Output Control】：click ,the icon turns red, then you can
manually control the alarm output of certain channel.
click again, then you can manually stop the alarm output of certain
channel.
【Palette】：choose palette pull-down menu, the device supports 18 kinds of
palette, you can choose to switch.
【FFC】：click to make FFC correction to thermal images.
【Audio】：click , the icon turns orange. Mic in：connect the Mic in of
the video server with the microphone and speak, then visit the device and start
the audio function and you can hear the voice. The audio type should be set as
“Mic in”, the audio sound will be amplified when starting Mic Boost.
【Talkback】：click ，the button turns orange.
Talkback: connect the Mic in of PC with microphone, and the audio output
interface(Aout and BNC) with sound equipment, talk to microphone and the
sound equipment will talk back; connect the line input interface of PC with
output interface, if the computer plays music, the sound equipment will also
play music. There is sound in all channels when “talkback” is chosen. The
output audio volume can be set (0-100) in audio parameters.
