Maintenance

Cleaning the lens

1Apply a non-abrasive camera lens cleaner to a soft, dry cloth.

Avoid using an excessive amount of cleaner, and don’t apply the

cleaner directly to the lens. Abrasive cleaners, solvents or other harsh

chemicals might scratch the lens.

2Lightly wipe the cleaning cloth over the lens in a circular motion. If you

don’t intend to use the projector immediately, replace the lens cap.

Replacing the clock batteries

The projector has a lithium Hitachi Maxell battery (part number CR2032) on

the bottom that is used to power the clock used for networking applications.

Visit our website for complete details on using the networking functionality.

1Turn off the projector and unplug the power cable.

2Wait 45 minutes to allow the projector to cool thoroughly.

3Turn the projector upside down and use a coin to turn the battery cover

to the “Open” position.

4Remove the battery and dispose of in an environmentally proper man-

ner.

5Install a new battery with the “+” side facing up.

6Press the battery into place, then replace the battery cover.

NOTE: The clock time will need to be reset in the web browser application

after replacing the battery.

clean the lens

with a soft dry cloth

and non-abrasive

cleaner

turn off and unplug

the projector

wait 45 minutes

12'0

%.15'

open battery cover

close battery cover

install new battery,

+ side up

press battery into position

EDX Ref Guide.fm Page 33 Friday, June 30, 2006 10:48 AM

Cleaning the dust filter

1Turn off the projector and unplug the power cable.

2Wait 45 minutes to allow the projector to cool thoroughly.

WARNING: To avoid burns, allow the projector to cool for at least 45

minutes before you clean or replace the dust filter.

3Remove the dust filter cover on the side of the projector by pressing up

on the two tabs at the cover’s bottom.

4Pull the tab on the center of the black dust filter bracket and lift it off.

5Clean the filter, cover, and vent using a vacuum set on low power.

Replace the filter if it is damaged or too dirty to clean.

6Replace the dust filter and the bracket on the cover, then replace the dust

filter cover.

7Reset the filter hour timer by navigating to the Settings>Service menu

and selecting Reset Filter Hours.

Using the security lock

The projector has a security lock for use with a cable lock system. See the

Accessories catalog that came with the projector, or visit our website, for

ordering information. Refer to the information that came with the lock for

instructions on how to use it.

turn off and unplug

the projector

wait 45 minutes

tabs dust filter cover

reset filter hours in Service menu

security lock

EDX Ref Guide.fm Page 36 Friday, June 30, 2006 10:48 AM
