InFocus SP110 Guida

ScreenPlay 110 Maintenance

Replacing the lamp

1. Place the projector upside down on a soft surface.

2. To remove the lamp door, press the lip on the outside edge of the door until the door slides

inward. Then swing the door open.

3. Loosen the two captive screws that secure the lamp to the lamp housing.

4. Swing the bail on the top of the lamp module up from its storage postion, and then pull the

module out of the projector.

Assembly Notes

oThe lamp must be seated properly to fully ignite.

oMake sure the bail on the lamp module is folded down in storage position. It snaps into

position.

oYou must replace the lamp door for the projector to operate.

The door is completely shut when the caret on the edge of the lamp door points to the lock icon.

NOTE If the lamp door does not fit flush in the door opening, it is probably because the bail is

not completely folded down.

oIf you installed a new lamp module, follow the directions below to reset the lamp timer.

Plug the projector in and turn it on.

Press and hold down the Volume – button. While holding the Volume – down, press the

Source button. Hold both buttons down for five seconds.

To verify that the lamp timer is reset, press the Menu button and navigate to the Source

menu. The lamp timer is the first item on the list.
