INNOSILICON A5 DashMaster Manuale utente

A5 DashMaster

USER MANUAL

INNOSILICON CONFIDENTIAL

Table of Contents

1. OVERVIEW 1

2. MINER ASSEMBLE 2

2.1 Check the miner before power on 2

2.2 Connect the PSU 3

2.3 Connect the Ethernet Cable 3

3. ENTER THE MINER CONSOLE 3

4. CONFIG THE MINER 6

5. APPENDIX 10

5.1 Modify the login password 10

5.2 Upgrade the firmware 10

INNOSILICON CONFIDENTIAL

INNOSILICON A5 DashMaster

High Efficient LTCMaster

INNOSILICON CONFIDENTIAL

1. OVERVIEW

INNOSILICON CONFIDENTIAL

A5 DashMaster

Chip Type A5 DashMaster ASIC

Hash Rate 32.5GH/s(+/-8%)

Power 750W +/-8%

Size (L×W×H) 400mm×135mm×158mm

Net Weight 4.0KG(without PSU)

Operating Temperature 0-40 ℃

Network Connection Ethernet

INNOSILICON CONFIDENTIAL

2. CABLE CONNECTION

2.1 CHECK THE MINER BEFORE POWER ON

·Check the warranty sticker is well or not, especially the hashboards PSU port side. If the warranty sticker

is damaged when you received the miner, please contact our After-sales.

·Before you power on the miner, shake the miner softly, if you can hear the sound of metal banging on

metal, please contact our After-sales.

·Check if the fan work well, if you find the fans broken please contact our After-sales.

·Check the cable connection, if it is different from below picture, please connect the cables as below.

INNOSILICON CONFIDENTIAL

A5 DashMaster

INNOSILICON CONFIDENTIAL

2.2 CONNECT THE PSU

Every hashboard needs to be inserted with 2 PSU cables according to the following image (Image 3). They

as listed as slots 1, 2, 3, 4, 5, and 6 in the image. Controller only needs 1 PSU cable. It should be inserted

in slot labeled 7 (Image 1.3).

INNOSILICON CONFIDENTIAL

A5 DashMaster

INNOSILICON CONFIDENTIAL

2.3 CONNECT THE ETHERNET CABLE

Insert one end of the Ethernet cable into the router and the other end into the slot shown in the following

image, you should plug in the miner one by one, only when you have accomplished IP Setting of the

previous one you can plug in another miner .

IP SET button: Press it more than 5 seconds to recover the IP to 192.168.1.254.

RESET button: Your miner will restart if you press it. It wont recover your settings to the default.

INNOSILICON CONFIDENTIAL

A5 DashMaster

INNOSILICON CONFIDENTIAL

3. ENTER THE MINER CONSOLE

By default, the miner uses Static IP to access the control webpage of the miner.

Input 192.168.1.254 into the browser, then click ‘Enter’ to enter the miner’s control webpage (Chrome is

the suggested browser).

Cant access the miner console?

Maybe it is because miner IP and the router IP have a different network segment, two ways to solve it:

·Modify the router IP to 192.168.1.1,then try again.

·Don’t want to change the network segment of the router? Do it as below:

Connect the miner and computer with a network cable. Open the windows system control panel, go to

Network and Internet — Network and share center – change the adapter settings, the mouse cursor to

the “Local Area Connection” click the right mouse button to view properties.

INNOSILICON CONFIDENTIAL

A5 DashMaster

INNOSILICON CONFIDENTIAL

·In the properties panel, double click the “Internet protocol version 4(TCP/IP)” . Then select the “Use the

following IP address”, fill in the IP address and Subnet mask as the right image.

INNOSILICON CONFIDENTIAL

A5 DashMaster

INNOSILICON CONFIDENTIAL

·Press the OK button twice to confirm the changes.Then modify the IP address of the miner (Do it as the

follow step 4.4) to guarantee the miner and the router have the same network segment.Then connect

the miner with the router,connect the PC with the router and select the “Obtain the IP address

automatically”.Now you can enter the IP through the browser into the control interface

4. CONFIG THE MINER

4.1 Enter ‘Miner Configuration’ page, select ‘General Settings’. Click the lower right corner to

enter log in page.

4.2 Enter the default password“12345678”, then click lower right corner to enter

configuration page.

INNOSILICON CONFIDENTIAL

A5 DashMaster

INNOSILICON CONFIDENTIAL

Password is wrong/error?—Please contact our support team

4.3 Enter the mining pool’s URL, Worker, password according to the following image, then click

.The miner will start mining, and the page will return to the ‘Miner Configuration’ page. It will show

the user’s modified setting.

Note: As the factory reset will not reset the password to "12345678", you need to remember what

you have modified your password to. Should you forget the password, it can only recovered through

our paid support. (Very IMPORTANT!!!)

INNOSILICON CONFIDENTIAL

A5 DashMaster

INNOSILICON CONFIDENTIAL

Note, over clock is at your own risk and vary in

performance from miner to miner. It may damage the

miner in overclock condition

Please click the Auto Search after you select the

frequency, then it will adjust to the best VID

automatically.
