INSTEON 2441ZTH Manuale utente
INSTEON Wireless Thermostat
2441ZTH
Quick Start Guide
INSTEON Wireless Thermostat
SET
72
SET
SET
72
Mode
Set Button
Temperature Adjust
Status LED
72
72
SET
Battery Compartment
2 AA Batteries
Optional Connections for
5V Power and External
Temperature Sensor
SENSOR5V
SENSOR5V
For the complete Owner’s Manual and
more, visit: insteon.com/support
SET
SET
72
Using with a Wired Thermostat
1On the Wireless Thermostat, press
and hold the set button until the device
beeps.
72
2On the Wired Thermostat, press and
hold the set button until the Wired
Thermostat double beeps.
SET
SET
72
72
PROGRAM
PROGRAM
PROGRAM
PROGRAM
Wireless Thermostat setup complete.
Follow the instructions below to change the
temperature mode of your thermostat.
ºC
3x
ºF
Use ºF or ºC
PROGRAM
F
PROGRAM
C
PROGRAM
72
PROGRAM
22
PROGRAM
PROGRAM
MODE
You can control vintage millivolt heaters with
the INSTEON Wireless Thermostat if you
replace the mercury oat or battery-powered
thermostat with an IO Module*.
*Wireless Thermostat requires at least one
Dual-Band INSTEON device to communicate
with IO Module.
Controlling Millivolt Heaters
RAW-#### Rev 02.26.14
Protected under U.S. and foreign patents (see www.insteon.com/patents)
©2014 INSTEON
Controlling Line Voltage Heaters
You can control a line voltage heater with the
INSTEON Wireless Thermostat if you replace
the line voltage thermostat with an INSTEON
Micro Module.
