6Intelligent Facility Solutions
Put your hand under the machine, it will work automatically, and stop
automatically when remove hand.When the induce time exceed 50s,then
hand dryer will stop automatically. If you need, Please induce it again.
Usage instruction
Put your hand under
the sensor area of hand
dryer, it will be started
automatically.
When remove hand from
the sensor area of hand
dryer, it will be stopped
automatically
Adjustment of sensing distance
Disassembling the cover, and
adjust the W1, turn clockwise
to increase the distance, and
counter clockwise to reduce
the distance.
W1
Sensor board
Lens
User can adjust warm or cool air
according to the request . When
turn on the heat switch, it will be
warm air .When close the heat
switch, i t w ill b e co o l air.
Temperature control
Heat switch
