NSC15 Network Camera
Motion-JPEG + MPEG4, Audio, 300k CMOS
Part No.: 524421
EAN-13: 0766623524421 | UPC: 766623524421
The INTELLINET NETWORK SOLUTIONS SOHO Network Camera, Model NSC15, is the
ideal camera for home-network-based video streaming. You can access the camera
remotely over the Internet, and you can save snapshots or record directly from your Web
browser to the local hard drive without installing any software or drivers.
Auto-Setup
No need to worry about complex network setup procedures. The installation wizard provides an easy setup that allows a
non-technical person to begin using the camera right away.
Simultaneous Viewing
Includes a Multi-Viewer software utility that allows you to monitor up to sixteen cameras at the same time. The advanced
video compression produces a high-quality, high-frame-rate, VGA, CIF video stream.
Dual Mode: Simultaneous MPEG4 + Motion-JPEG Streaming
The Pro Series Network Camera supports MPEG4 as well as Motion-JPEG video formats, providing superior quality and,
at the same time, continuing to support existing applications (the law in most countries only accepts JPEG video format
as evidence in court). MPEG4, on the other hand, allows you to transmit a larger amount of data over the same amount of
bandwidth while providing smooth and seamless viewing.
Remote Monitoring Utility
This application adds enhanced features and functionality while allowing up to five users to concurrently access the
Internet Camera from a remote site via a LAN or the Internet. Other features include image monitoring, recording images
to a hard drive, viewing up to sixteen cameras on one screen, and snapshots.
Web & Utility Configuration
Using an administrator utility or standard Web browser, IT administrators can also configure and manage the camera
remotely through the Internet or a LAN. The utility allows you to manually send captured images by e-mail.
Integrated DDNS Client
For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.
Utilize the free DYNDNS service (like DYNDNS.org) in order to connect to your camera, even if you do not have a static
IP address assigned by your ISP (Internet service provider). This feature lets you easily set up a URL that can be used to
access the camera through the Internet using any Web browser.
Professional functions in a SOHO product
The INTELLINET NETWORK SOLUTIONS SOHO Network Camera provides features that normally can only be found in
professional-grade products. SSL Encryption keeps the data connections secure, simultaneous MPEG4 + Motion-JPEG
Streaming for best compatibility, 3GPP mobile phone streaming for on-the-road connectivity, UPnP Port-Forwarding for
configuration-free router setup, full-duplex audio support, and an excellent image quality never thought possible for a
SOHO-type network camera.
Features:
Excellent image quality with 30 fps full-motion video in all resolutions
Progressive-scan image sensor with OmniPixel2 technology
Supports image resolutions up to 640 x 480 (VGA)
Audio support, full duplex, up to 8 kHz, with integrated microphone
Easy-to-use 16-channel camera viewing and recording utility included (not
compatible with NSC10 and NSC18 cameras)
Integrated multi-window motion detection
Selectable video buffer for smoother video streaming
Supports simultaneous MPEG4 and Motion-JPEG image compression
Mobile phone streaming live video through 3GPP / ISMA / RTSP
Mobile phone live image through 2.5 WAP
MPEG4 + Motion-JPEG + 3GPP mobile phone streaming, audio and 10x digital
zoom
Supports HTTPS encryption for enhanced security
Supports UPnP with UPnP port forwarding capability
Ultra-compact and easy to install
Three-Year Warranty
Specifications:
Standards
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3u (100Base-TX Fast Ethernet)
General
• 32-bit ARM9 RISC CPU
• 8 MByte flash memory
• 64 MByte SDRAM
• Supported image resolutions: 640 x 480 and 320 x 240
• Video frame rate: max. 30 fps
• Audio support:
- Full duplex
- Bandwidth: G.711 PCM, 8 kHz, 64 kbit/s
- Microphone: built-in
- Audio line out jack: 3.5 mm / 1.8"
For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.
• Protocols supported: TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP,
UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA RTSP
• Certifications: FCC Class B, RoHS
Image Sensor and Lens
• Omnivision 1/4" progressive-scan CMOS sensor with OmniPixel2 technology
• VGA resolution (664 H x 490 V)
• S/N ratio: 50 dB (max.)
• Pixel size: 6.0 µm x 6.0 µm
• Automatic Exposure Control (AEC), Automatic Gain Control (AGC), Automatic White
Balance (AWB), Automatic Band Filter (ABF) and Automatic Black-level Calibration (ABLC)
• Manual brightness, contrast, saturation, hue, sharpness control
• Minimum illumination: 0.5 lux at F2.0
• Focal length 4.0 mm, angular field of view 59?, object distance 0.2 m to infinity
LEDs
• Power
• Network connection
Environmental
• Dimensions: 98 (W) x 58 (L) x 31 (H) mm (3.8 x 2.3 x 1.2 in.)
• Weight: 0.6 kg (1.3 lbs.)
• Operating temperature: 0 – 45°C (32 – 113°F)
• Operating humidity: 20 – 80% RH, non-condensing
Power
• External power adapter: 5 V DC, 1.2 A
• Power consumption: 3.5 Watts (maximum)
System Requirements
• Windows 2000, XP, Vista, Windows 7, Linux, Mac OS X
• Computer with network connection
• Web browser support:
- MS Internet Explorer 6.0 or higher (ActiveX)
- Mozilla 1.x, Mozilla Firefox (Java)
- Netscape Navigator 6.0 or higher (Java)
- Opera (Java)
- Safari (Java)
- Konqueror (Java)
Package Contents
• NSC15 Network Camera
• Camera mounting bracket
• Quick installation guide
• External power adapter
• Software CD
