Intellinet 520881 Manuale utente

Manageable Gigabit Switch

User’s Manual 1

Preface

This manual describes how to install and use the Manageable

Gigabit Switch. This switch introduced here is designed to deliver

full scalability with SNMP/RMON web-based management

functions by providing:

z24 x 10/100BaseTX fixed ports and optional 2 x

1000BaseT/SX/LX ports.

z16 x 10/100BaseTX fixed ports and optional 1 x 8-Port

10/100BaseTX/100BaseFX module, 2 x 1000BaseT/SX/LX

ports.

For the two Gigabit ports, it allows options of fiber type and

wavelength at user’s discretion. This switch brings a simple answer

to today’s complicated networking environments.

To get the most out of this manual, you should have an

understanding of Ethernet networking concepts.

In this manual, you will find:

•Features on the switch

•Illustrative LED functions

•Installation instructions

•Management Configuration

•SNMP, DHCP, IGMP…

•Specifications

Manageable Gigabit Switch

2 User’s Manual

Table of Contents

PREFACE 1

TABLE OF CONTENTS 2

PRODUCT OVERVIEW 5

MANAGEABLE 16/24 +2GIGABIT SWITCH 5

PACKAGE CONTENTS 5

PRODUCT HIGHLIGHTS 6

Basic Features 6

Management Support 6

FRONT PANEL DISPLAY 7

PHYSICAL PORTS 9

SWITCH MANAGEMENT 9

Administration console via RS-232 serial port 9

Web-based browser interface 9

External SNMP-based network management application 10

INSTALLATION 11

SELECTING A SITE FOR THE SWITCH 11

CONNECTING TO POWER 12

CONNECTING TO YOUR NETWORK 13

Cable Type & Length 13

Cabling 15

SWITCH MANAGEMENT 16

MANAGEMENT ACCESS OVERVIEW 16

ADMINISTRATION CONSOLE 17

Direct Access 17

Modem Access 18

WEB MANAGEMENT 18

SNMP-BASED NETWORK MANAGEMENT 18

PROTOCOLS 19

MANAGEMENT ARCHITECTURE 19

MENU-DRIVEN CONSOLE MANAGEMENT 20

LOGGING ON TO THE SWITCH 20

At the screen prompt 20

SWITCH MANAGEMENT SCREEN 21

Navigating Through the Console Interface 22

Manageable Gigabit Switch

User’s Manual 3

PERFORMING BASIC MANAGEMENT ACTIVITIES 22

Start with Selection Menu 23

General Management Configurations 24

LAN Port Configurations 25

Console Port Configurations 27

PERFORMING ADVANCED MANAGEMENT ACTIVITIES 28

Start with Selection Menu 29

L2 Switching DataBase 30

IP Networking 35

Bridging 43

Static Filtering 44

MAC Address In-Filters 45

Spanning Tree Functions 46

SNMP Functions 50

Other Protocols 52

Port Mirroring 53

QoS Setup 54

Sending and Receiving Files 59

LOGOUT 61

SAVE SETTINGS 61

RESTORE DEFAULT SETTINGS 61

REBOOT 61

WEB-BASED BROWSER MANAGEMENT 62

LOGGING ON TO THE SWITCH 62

UNDERSTANDING THE BROWSER INTERFACE 63

PERFORMING FILE ACTIVITIES 64

Start with Selection Menu 64

PERFORMING BASIC SETUP ACTIVITIES 66

Start with Selection Menu 66

LAN Port Configuration 68

Console Port Configuration 71

PERFORMING ADVANCED SETUP ACTIVITIES 73

Start with Selection Menu 73

MAC Address Management 74

IP Networking 78

Per Port Statistics 84

Bridging 84

Static MAC Filter 85

IP Multicast Group 88

VLAN Perspective 88

Spanning Tree Perspective 91

SNMP 93

Other Protocols 95

Port Mirroring 96

QoS 97

SNMP &RMON MANAGEMENT 106

OVERVIEW 106

SNMP AGENT AND MIB-2 (RFC 1213) 106

RMON MIB (RFC 1757) AND BRIDGE MIB (RFC 1493) 107

RMON Groups Supported 107

Bridge Groups Supported 108

Manageable Gigabit Switch

4 User’s Manual

SPECIFICATIONS 109

Manageable Gigabit Switch

User’s Manual 5

Product Overview

Manageable 16/24 + 2 Gigabit Switch

Front View

Package Contents

When you unpack the product package, you shall find the items

listed below. Please inspect the contents, and report any apparent

damage or missing items immediately to your authorized reseller.

3This Manageable Switch

3User’s Manual

3AC power cord

3RS232 cable

3Rackmount brackets with screws

Manageable Gigabit Switch

6 User’s Manual

Product Highlights

Basic Features

♦24 x 10/100BaseTX ports with RJ-45 connectors, plus

options of 2 x 1000BaseT/SX/LX ports, auto-MDIX on port

17 ~ port 24

♦16 x 10/100BaseTX ports with RJ-45 connectors, plus

options of 1 x 8-Port 10/100BaseTX/100BaseFX module

(auto-MDIX on TX ports of 8-Port module), 2 x

1000BaseT/SX/LX ports

♦Auto-negotiation for speed and duplexity on all

10/100BaseTX ports

♦Full wire-speed forwarding rate

♦Store-and-forward mechanism

♦Back-pressure and IEEE 802.3x compliant flow control

♦Supports 32K MAC addresses

♦Provides 2MBytes memory buffer

♦Front panel reset button

♦Front panel port status LEDs

♦Standard 19” rackmount size, one-unit-height

Management Support

VLAN

♦Port-based VLAN

♦802.1Q tagged VLAN

PORT-SECURITY

♦Limit number of MAC addresses learned per port

♦Static MAC addresses stay in the filtering table

PORT-MIRRORING

♦Port-mirroring provided through dedicated ports

COS (IEEE802.1p Classification of Service)

♦4-level transmission priorities: 4 queues per output port

♦Packet transmission scheduled using Weighted Round

Robin (WRR)

♦User-defined weights

Manageable Gigabit Switch

User’s Manual 7

♦Classification of packet priority can be based on either a

VLAN tag on packet or a user-definable port priority

INTERNETWORKING PROTOCOLS

♦Bridging:

802.1D Spanning Tree

802.1p/Q – GARP/GVRP

♦Routing:

RIP

RIP-2

DHCP-Relay

ICMP Router Discovery Message

♦IP Multicast:

IGMP Snooping

Maximum of 128 VLANs and IP multicast

sessions

♦Bandwidth Control

NETWORK MANAGEMENT METHODS

♦Console port access via RS-232 cable

♦Telnet remote access

♦SNMP agent:

MIB-2 (RFC1213)

Bridge MIB (RFC1493)

RMON MIB (RFC1757) – statistics, history, alarm and

events

VLAN MIB (802.1Q/RFC2674)

Private MIB

♦Java applet-based MIB browser

♦Web browser support based on HTTP server and CGI

parser

♦Kermit/TFTP software-upgrade capability

Front Panel Display

Manageable Gigabit Switch

8 User’s Manual

cPOWER

This LED comes on when the switch is properly connected to power and

turned on.

dPort Status LEDs

The LEDs are located at the left side of each section, displaying status for

each respective port. Please refer to the following table for more details.

LED State Indication

On A valid network connection established.

LNK stands for LINK.

LNK/ACT

Flashing Transmitting or receiving data.

ACT stands for ACTIVITY.

On Connection in full duplex mode.

FDX stands for FULL-DUPLEX.

Flashing Collision occurred.

COL stands for COLLISION.

FDX/COL

Off Connection in half-duplex mode.

eGigabit Port Status LEDs

The LEDs are located at the left side of each Gigabit module, displaying

status for each respective port. Please refer to the following table for more

details.

LED State Indication

Flashing Transmitting or receiving data.

ACT stands for ACTIVITY.

ACT

Off

No activity.

On A valid network connection established.

LNK stands for LINK.

LNK

Off No connection.

Manageable Gigabit Switch

User’s Manual 9

Physical Ports

The Manageable Gigabit Switch provides:

z24 x 10/100TX fixed ports and options of 2 x 1000T/SX/LX

ports.

z16 x 10/100TX fixed ports and options of 1 x 8-Port

10/100TX/100FX module, 2 x 1000T/SX/LX ports.

CONNECTIVITY

zSC connectors on Gigabit ports

zST, SC, VF-45, MT-RJ connectors on 100FX ports

zRJ-45 connectors on TX ports

MODE SELECTION

• 10BaseT full-duplex mode

• 10BaseT half-duplex mode

• 100BaseTX/FX full-duplex mode

• 100BaseTX/FX half-duplex mode

• 1000BaseT/SX/LX full-duplex mode

• Auto-negotiating mode

Switch Management

Administration console via RS-232 serial port

The switch provides an onboard serial port, which allows the switch to

be configured via a directly connected terminal or a Telnet session.

Web-based browser interface

The switch also boasts a point-and-click browser-based interface that

lets users access full switch configuration and functionality from a

Netscape or Internet Explorer browser.

Manageable Gigabit Switch

10 User’s Manual

External SNMP-based network management application

The switch can also be configured via SNMP.
