Intermec 6640 Manuale di programmazione

NPN: 962-054-014

Revision A

September 1999

Model 6640

QUICK-START Instructions

You must charge the main battery and make all connections to the computĆ

er prior to firstĆtime use. These instructions include battery installation

and connector locations. See the Model 6640 User s Guide, P/N 961Ć054Ć018

for detailed instructions.

Battery Installation

1. Open the battery compartment door by pressing the latch tab

and pulling outward on it.

2. Align the battery pack to the opening with connectors facing into

the computer and the pull ring oriented as shown in the illustraĆ

tion below.

3. Slide the battery pack into the computer.

4. ress firmly INWARD and slightly down on the battery pack to

secure it in place.

5. Reinstall the battery compartment door.

6. Close battery door until latch tab clicks" into place.

BCAUTION: Fully charge the main battery before using the computer away from an

external power source.

BCAUTION: Close and secure compartment doors before using computer.

1. Pull ring

2. Main battery pack

3. Latch tab, battery compartment door

1

2

3

NPN: 962-054-014

Revision A

September 1999

*962054014*

1. Power On/Off switch

2. Suspend/Resume switch

3. Variety of connectors available.

2

1

1. DC Input connector

2. Pen connector

3. USB connector

1

2

3

3

Top View

(right) Side View

A variety of I/O connectors is available for the inset area shown below. Those

found on your computer may vary from this illustration. The docking connecĆ

tor is located on the back of the computer. Make all connections before powerĆ

ing the unit ON. The USB connector does permit hot swap" connections.

The On/Off switch is a true power switch and will reset the computer if a lockup occurs.

Always perform a proper Windows shutdown before powering the unit OFF.

You can press the Suspend/Resume switch for a full oneĆsecond to reduce power

consumption during idle periods. This will keep the application program live

and ready to Resume the next time you press the Suspend/Resume switch for

one full second.

Connectors
