Intertone Crisp Manuale utente

User Guide

Behind-The-Ear (BTE) Models:

Standard Tube

Thin Tube

Interton Crisp

Interton Share

Interton Step

Interton Gain

Hearing instrument model:

Left serial number:

Right serial number:

Receiver tube length:

Battery size: 13 orange 312 brown 675 blue

Open/standard ﬁtting: Small Medium Large St. dome Custom mould

Programme Beep Description of when to use

Delayed on-activation................14

Volume control.....................22

Push button.......................23

Wireless..............24, 25, 26, 42, 43

AutoPhone.....................29-33

Telecoil/Tele-loop system .............34

Direct Audio Input (DAI)...............35

Power device-exceeds 132 dB SPL .......

SPECIFIC FEATURES SUPPORTED BY YOUR HEARING SYSTEM:

Note: Your hearing system might not support all 4 environmental programmes. Ask your hearing care professional for details.

Ask your hearing care professional to marked options supported by your hearing system.

Standard ﬁtting

Ear hook

Open ﬁtting

Thin tube options

Becoming Accustomed to Ampliﬁcation

While purchasing a hearing system is a major step, it is only one step in a process toward more comfortable

hearing. Successfully adapting to the ampliﬁcation your hearing system provides takes time and consistent

use.

You will enjoy more beneﬁts from your Interton hearing system by taking the following actions:

• Wear the system regularly in order to get comfortable with using it.

• It takes time to get used to a hearing aid. It may help to begin by wearing your hearing aid for short

periods – even as little as 15 minutes – and then gradually building up your wearing time. In a way, it’s

no different than adjusting to contact lenses. Speak to you hearing care professional, who can design

a schedule tailored just for you.

• As you get more comfortable with the system, increase the wearing time and wear your hearing system

in multiple types of listening environments.

It may take as long as several months for your brain to get used to all the “new” sounds around you. Fol-

lowing these suggestions will give your brain time to learn how to interpret ampliﬁcation and increase the

beneﬁts you get from using an Interton hearing system.

Thank You

Thank you for selecting an Interton hearing system. We are proud of our hearing products and are conﬁ-

dent you have chosen one of the best products available.

Please familiarize yourself with the information in this guide. It contains important instructions for proper

use and care, technical performance information, and other general information about your hearing system.

Your hearing system has been adjusted to your particular hearing loss. Your hearing health care professional

will explain these adjustments and the special features of your particular model.

Hearing instrument type designations for models included in this user guide are: Model M70-80e,

FCC ID: X26M70-80e, IC: 6941C-M7080e, Model M70-80, FCC ID: X26M70-80, IC: 6941C-M7080 and

Model: M60, FCC ID X26M60, IC: 6941C-M60. Please see page 12 for list of models referring to all types.

Statement:

This device complies with Part 15 of the FCC Rules and IC rules.

Operation is subject to the following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including interference that may cause undesired

operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules and ICES-003 of the IC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the in-

structions, may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from the one in which the receiver is con-

nected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modiﬁcations can void the user´s authority to operate the equipment.

Intended use

Generic air-conduction hearing instruments are wearable sound-amplifying devices intended to compen-

sate for impaired hearing. The fundamental operating principle of hearing instruments is to receive, amplify,

and transfer sound to the ear drum of a hearing impaired person.

List of countries:

Products without wireless functionality are intended for worldwide sales.

In the EU, products with wireless functionality with wireless functionality are intended for sale in countries

within European Economic Area as well as Switzerland.

The products are in compliance with the following regulatory requirements:

• In EU: the device conforms to the Essential Requirements according to Annex I of Council Directive

93/42/EEC for medical devices (MDD) and essential requirements and other relevant provisions of Di-

rective 1999/5/EC (R&TTE).

• The declaration of conformity may be consulted at www.interton.com

• In US: FCC CFR 47 Part 15, subpart C.

• Other identiﬁed applicable international regulatory requirements in countries outside EU and US. Please

refer to local country requirements for these areas.

• In Canada: these hearing instruments are certiﬁed under the rules of IC.

• Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

• Japanese Radio Law and Japanese Telecommunications Business Law Compliance. This device is

granted pursuant to the Japanese Radio Law (電波法) and the Japanese telecommunications Business

Law (電気通信事業法) This device should not be modiﬁed (otherwise the granted designation number

will become invalid)

10 11

Hearing Instrument(s) model and

basic information ...................... 2, 3

Thank you .............................4

Becoming Accustomed to Ampliﬁcation .......5

Intended use ...........................8

List of countries . . . . . . . . . . . . . . . . . . . . . . . . . 8

Instruments component identiﬁcation ........ 13

On/Off function ........................ 14

Delayed activation (optional) ............... 14

Inserting/ Replacing the battery ............ 15

Low battery indicator .................... 17

Inserting/removing hearing instruments....... 18

Volume control (optional) .................22

Push button (optional) ...................23

Flight mode (wireless devices only)....... 25, 26

Telephone use ........................ 27

Listen to radio or TV ....................28

Cellular phones ........................28

AutoPhone (optional) ..................29-33

Telecoil (optional) ....................... 34

Tele-loop systems (optional) ...............34

Direct Audio input (optional) ...............35

Contents

Connecting/Disconnecting audio boots ......35

Care and maintenance...................36

Cleaning earmoulds .....................38

Cleaning thin tubes and domes ............39

How to apply domes .................... 40

Wireless warnings and precautions

(wireless devices only) ................... 42

General warnings.......................43

Troubleshooting guide ................... 46

Technical Data .........................54

Warranty and repairs .................... 57

Temperature test, transport and

storage information......................58

Hearing instrument expectations ...........59

Warning to Hearing Aid Dispensers (US only) ..59

Important Notice for Prospective

Hearing Aid Users (US only ...............60

Children with hearing loss (US only) ......... 62

High sound pressure levels ...............62

8/9

8/9 2

12 13

Hearing instruments of type

M70-80 are available in the

following variants:

CI370/80-DVIW

CI370/80-DVIW Open

CI270/80-DVIW

CI270/80-DVIW Open

ST680-DW

ST680-DW HP

ST480-DW

ST280-DW

ST670-DW

ST670-DW Open

ST470 -DW

ST270-DW

Non wireless hearing instru-

ments are available in the fol-

lowing variants:

SR1380-DVI

SR1370-DVI

SR1365-DI

SR1280-DVI

SR1270-DVI

SR118 0 -VI

SR1170 -VI

GAN390-DVI

GAN290-DVI

Hearing instruments of type

M60 are available in the fol-

lowing variants:

CI365-DIW Open

CI365-DIW

CI265-DIW Open

CI265-DIW

ST665-DW

ST665-DW Open

ST465-DW

ST265-DW

1. Push button

2. Battery compartment & On/Off switch

3. Sound outlet

4. Front microphone inlet

5. Back microphone Inlet (optional)

6. Volume control (optional)

7. Direct audio input

8. Left/Right indicator

(Left=Blue/Right=Red)

9. Battery lock (optional)

10. Model

11. Manufacturer

12. Serial number

13. Ear hook

14. Open ﬁtting thin tube Analogue VC Digital VC toggle

14 15

Getting started

On&Off function

1. When the battery door is closed, the hearing instrument turns

on, and the default program will be activated.

2. To turn off the hearing instrument, open the battery door. Many

individuals can use their ﬁngernail to pull it open.

iWhenever the hearing instruments are not in use, remember to turn them off

to avoid unnecessary battery consumption.

Delayed activation

Hearing instruments can be turned on once you have placed them on your ears. If you prefer to turn them

on just prior to placing them on your ear, your hearing care professional can activate a function called

Delayed on-activation. This function will delay the time in which the hearing instruments turn on by several

Off

seconds after the battery compartment is closed. With Delayed on-activation, a beep will be heard for each

second of the delay period.

Inserting/Replacing the battery

1. Open the battery door completely by using your ﬁngernail.

2. Remove the used battery if present. Insert the new battery with the positive side

in the correct position.

3. Gently close the battery door.

iAlways use new Zinc-Air batteries that have a minimum remaining shelf-life of 1 year.

16 17

Low battery indicator

Your hearing care professional can set your hearing instrument to give an acoustical indication when the bat-

tery is reaching its end of life. The hearing instrument will reduce ampliﬁcation and emit a melody if battery

power gets too low. This signal will recur every ﬁve minutes (15 minutes for GAN390-DVI and GAN290-DVI) un-

til the hearing instrument automatically switches off. It is recommended that you keep spare batteries on hand.

Low battery indicator (instruments paired with accessories only)

Active usage of the Interton wireless accessories (Remote Control, Phone Clip and TV Streamer) requires

more battery power from the hearing instruments than when these are working on their own. When the

battery in the hearing instrument has depleted to a level at which use of the Interton TV Streamer TV and

Phone Clip cannot be supported, the hearing instrument will play two sets of descending tones. After

this, your hearing instrument and Interton Remote Control will continue to work as usual, but you will not

be able to use your Interton TV Streamer and Phone Clip. At some point the battery level will not support

the remote control either and you will once again hear the descending tones. The hearing instruments will

continue to work as usual. Once a new battery is inserted, full operation of the accessories will resume.

iWARNING

1. Remove the batteries to prevent leakage when the hearing instruments are not in use for an extended

period of time.

2. Do not attempt to recharge batteries (Zinc Air) which are not speciﬁcally designated as rechargeable

because they may leak or explode.

3. Do not place batteries in your mouth. Consult a physician immediately if a battery has been swallowed,

as they can be harmful to your health.

4. Keep batteries away from pets, children and individuals who are mentally challenged.

5. Do not attempt to dispose of batteries by burning them. Used batteries are harmful to the environment.

Please dispose of them according to local regulations or return them to your hearing care practitioner.

18 19

Inserting/Removing hearing instruments

Insertion (custom earmoulds)

1. Hold the earmould between your thumb and index ﬁnger and position its sound outlet in your ear canal.

2. Slide the earmould all the way into your ear with a gentle, twisting movement.

3. Turn the top part of the earmould gently backwards and forwards so that it tucks behind the fold of skin

above your ear canal.

4. Move the earmould up and down and gently press to ensure it is positioned correctly in the ear. Opening

and closing your mouth can ease insertion.

5. Make sure the hearing instrument is seated behind the ear.

By experimenting, an easier method may be discovered. With proper insertion, hearing

instruments should ﬁt snugly but comfortably. If the hearing instruments cause irritation

of the ears, contact your hearing care professional.

iCAUTION

Never attempt to modify the shape of the hearing instrument, earmoulds, or tubing your-

self.

iIt may be helpful to pull your ear up and outward with your opposite hand during

insertion.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali intertone Apparecchio acustico

intertone

intertone A130 Manuale utente

Manuali Apparecchio acustico popolari di altre marche

Sonic

Sonic Bliss miniBTE Manuale utente

Lexie

Lexie B1 Manuale elenco delle parti

Widex

Widex FM+DEX Manuale utente

Siemens

Siemens Triano Manuale utente

Camplicomms

Camplicomms HC-200 Manuale utente

Widex

Widex SUPER 220 S2-VSD Manuale utente

Phonak

Phonak Q90 Manuale utente

Williams Sound

Williams Sound SoundPlus WIR 237 Guida

Oticon Medical

Oticon Medical Ponto SoundConnector Manuale utente

Siemens

Siemens Life micon Manuale utente

Starkey

Starkey Destiny Manuale utente

Audicus

Audicus The Icon Manuale utente

Advanced Bionics

Advanced Bionics Slim HP Standard Manuale utente

Widex

Widex DREAM440 THE DREAM SERIES Manuale utente

Phonak

Phonak myPilot Manuale utente

NIKEN

NIKEN NK-401 Manuale utente

ON Semiconductor

ON Semiconductor Ezairo 7111 Pre Suite Manuale utente

Sonetik

Sonetik GOHEAR Manuale utente

intertone Crisp Manuale utente

Manuali Apparecchio acustico popolari di altre marche
