Intex AP638 Manuale utente

168

(168PO) AP638 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 05/06/2021

SAVE THESE INSTRUCTIONS

Page 1

READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT

INTEX®OWNER'S MANUAL

Quick-Fill™ Electric Air Pump

Model AP638 6C Cell Size Batteries 4.5V

PARTS DESCRIPTION:

1. PUMP

2. SWITCH

3. BATTERY COMPARTMENT

COVER

4. TRIGGER AND CLIP

5. INFLATION CONNECTOR

6. DEFLATION CONNECTOR

7. NOZZLES

INSTRUCTIONS

General

• For maximum power use alkaline batteries. Remove batteries from equipment which is not to be used for an

extended period of time.

• Do not mix old and new batteries. Do not mix alkaline, standard (Carbon - Zinc), or rechargeable (Nickel

- Cadmium) batteries.

• Remove used batteries promptly.

• Do not dispose of airpump and its batteries in a fire. Check your local regulations for proper disposal instructions.

• Keep away from heat or direct sunlight.

• Return pump and nozzles to package when not in use.

• No specific air pump maintenance is required.

• Always purchase the correct size and grade of battery most suitable for the intended use.

• Replace all batteries of a set at the same time.

•Clean the battery contacts and also those of the device prior to battery installation.

•Ensure batteries are installed correctly with regard to polarity (+ and -).

NAMES OF PARTS

168-*PO-R0-2205

• Adult use only.

• Do not drop unit into water or expose unit to rain or water.

• Do not direct air stream at face or body.

• Do not obstruct vent holes or open source.

• Do not insert objects into the inflation or deflation connector.

•Do not operate air pump for more than 10 minutes at a time. Let pump cool at least 5 minutes between use.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID PROPERTY DAMAGE, ELECTRIC SHOCK,

BURNS OR OTHER INJURY.

WARNING

NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

INFLATION

1. Attach nozzle to the inflation connector if necessary and hold pump against inflation valve on item to be inflated.

See Fig (4).

NOTE:

On large items like inflatable boats and large air mattresses, the pump will fit directly into the inflation valves and

provide faster inflation times. Use the appropriate nozzle on small inflation valves as on small air mattresses, etc.

2. SWITCH ON: Press "I"; SWITCH OFF: Press "0". See Fig (5).

INSTRUCTIONS

INSTALL OR REPLACE BATTERIES

1. Open battery compartment cover. See Fig (1).

2. Insert 6-"C" alkaline batteries (NOT INCLUDED) as shown on the drawings inside the battery compartment. See Fig (2).

3. Replace battery compartment cover. See Fig (3).

FIG (1)

FIG (3)

168

SAVE THESE INSTRUCTIONS

Page 2

DEFLATION

1. Attach nozzle to the deflation connector if necessary and hold pump against inflation valve on item to be deflated.

See Fig (6).

NOTE: On large items like inflatable boats and large air mattresses, the pump will fit directly into the inflation valves and

provide faster deflation times. Use the appropriate nozzle on small inflation valves as on small air mattresses, etc.

2. SWITCH ON: Press "I"; SWITCH OFF: Press "0". See Fig (5).

FIG (4): ATTACH NOZZLE

FIG (5): SWITCH

(168PO) AP638 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 05/06/2021

FIG (5): SWITCH

FIG (6): ATTACH NOZZLE

FIG (2)

®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas

registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/

Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach,

CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in

der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands

www.intexcorp.com
