Intex FastFill I637USB Manuale utente

(37IO) I637USB ELECTRIC PUMP ENGLISH 4.875” X 7.25” 06/19/2021

English 37

SAVE THESE INSTRUCTIONS

Page 1

IMPORTANT SAFETY INSTRUCTIONS

READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT

INTEX® OWNER’S MANUAL

FastFill™ USB Pump

Model I637USB 5V 2A

037-*IO-R0-2206

•NEVER PLACE AN INFANT TO SLEEP ON AIR MATTRESSES.

• Never introduce any flammable substance into the inflatable airbed, SUCH AS AEROSOL TIRE

REPAIR PRODUCTS, as it may ignite or explode.

•This is not a toy. Children must not be left unattended when using the airbed.

•If a storage bag is included,

keep the storage bag away from babies and children. The storage bag is

not a toy. When not in use, fold the bag and put it away out of the reach of children.

•Do not walk, stand on or jump on or use the airbed as a trampoline.

•Do not use on or near water. This is not a raft.

•Do not set up bed near stairs, doors, sharp edges or breakable objects. Provide adequate space

between bed and objects to avoid entrapment.

•Make sure the area is flat, smooth, even and free of sharp objects that could puncture the bed.

•Keep pets away from the airbed. Pets may puncture the surface of the bed.

•Avoid sleeping on the edge of the airbed. Edges produce less support than the middle of the bed.

•Do not obstruct the air passage opening or insert any objects into the air passage opening.

•

To reduce the risk of electric shock, do not expose to rain. Store indoors.

• Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswithreduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe way and understand the hazards

involved.

• Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshallnotbemadeby

children without supervision.

FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID SUFFOCATION, PROPERTY

DAMAGE, ELECTRIC SHOCK, BURNS OR OTHER INJURY.

WARNING

®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas registradas

utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/

a/an Intex Development Co. Ltd., Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801•DistributedintheEuropeanUnion

by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld

9, 4705 RR Roosendaal – The Netherlands

www.intexcorp.com

(37IO) I637USB ELECTRIC PUMP ENGLISH 4.875” X 7.25” 06/19/2021

English 37

SAVE THESE INSTRUCTIONS

Page 2

NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.

Due to a policy of continuous product improvement, Intex reserves the right to change

specifications and appearance, which may result in updates to the instruction manual,

without notice.

PARTS REFERENCE

Part Descriptions:

1. Control dial

2. Inflation mark ( )

3. Off mark ( )

4. Deflation mark ( )

5. Manual inflation port and cap

6. Cord compartment cover

7. USB cable

8.Airbed

INSTRUCTIONS

The pump uses the power supplied by a standard USB socket. Older USB adapters do not

supply enough power for the pump to fully inflate the airbed. Newer “fast charge” adapters

need to be used. Check that your adapter’s output is 2A or more for optimum operation.

Most USB charge ports in vehicles are too weak: a 12 volt USB adapter (12V Car Charger)

may be needed. If the pump won’t inflate the bed fully within 7 minutes, you probably need

higher output.

General

• Theairpumprequiresanexternalpower adapter (not included) to operate.

• Airpumpinputvoltage/currentrating: 5V / 2A or more.

• Makesuretheoutputoftheexternalpoweradapter,suchasUSB Wall Charger, Portable

USB Charger, 12V Car Charger or USB Port is rated 5V / 2A or more.

• Nospecific air pump maintenance is required. Air pump has no user serviceable parts.

• Make sure the area is flat, level, clean and free from sharp objects. To prevent puncture

or damage to the airbed, never drag the airbed across the ground. Lift the inflated airbed

when moving or changing location.

• During outdoor use, place a protective layer such as a tarp (not included) between the

selected surface and the airbed in order to prevent damage to the airbed.

• For cleaning use only clean cloth with mild soapy solution. Do not use any chemicals.

• Incaseofrepairs,useonlycommonPVCrepairglueandpatches.For flocked surfaces:

rub away the flocking material with an eraser first before applying the glue and/or patch.

(37IO) I637USB ELECTRIC PUMP ENGLISH 4.875” X 7.25” 06/19/2021

English 37

SAVE THESE INSTRUCTIONS

Page 3

2. Connect the USB cable to one of the following external power adapters (not included):

• USB Wall Charger rated 5V / 2A or more. See Fig (2).

 •Portable USB Charger rated 5V / 2A or more. See Fig (3).

 • 12V Car Charger rated 5V / 2A or more. See Fig (4).

 • USB Port rated 5V / 2A or more. See Fig (5).

3. Turn the control dial to the inflation mark ( ). See Fig (6).

4. When the airbed is fully inflated, turn the control dial back to the off mark ( ) position

closing the inflation valve. See Fig (7).

5. Lie down on the airbed to test the firmness.

6. If the airbed feels too firm, release some air by simply turning the control dial to the

deflation mark ( ) until desired firmness is achieved, then turn the control dial back to

the off mark ( ) position. If the bed feels too soft, repeat steps #3 to #6 as necessary.

FIG (2)

USB Wall Charger

FIG (3)

Portable USB Charger

FIG (4)

12V Car Charger 5V/2A USB Port

FIG (5)

FIG (7)

FIG (6)

Inflation

mark

INFLATION

1. Open line cord compartment cover and pull out the USB cable. See Fig (1).

FIG (1)

(37IO) I637USB ELECTRIC PUMP ENGLISH 4.875” X 7.25” 06/19/2021

English 37

SAVE THESE INSTRUCTIONS

Page 4

DEFLATION

1. Connect the USB cable to an appropriate external power adapter. See Fig (2-5).

2. Turn the control dial to the deflation mark ( ). See Fig(8).

3. With the airbed fully deflated begin rolling the airbed from the end opposite of the pump

towards the end where the pump is located. See Fig (9).

4. When all the air is removed from the airbed, turn the control dial back to the off mark

(

) closing the valve.

5. Disconnect the USB cable from the external power adapter, place it inside the cord

compartment and close the cover. Make sure the USB cable is free of twists, kinks or

knots.

FIG (9)

FIG (8)

Deflation

mark

Proper inflation of the airbed.

The ambient temperatures of air have an effect on the airbed internal pressure. At low

ambient temperature the air will contract within the airbed and the airbed will feel softer:

add air as necessary. At high ambient temperature the air within the airbed will expand

significantly and the airbed will become hard and may burst: release air to avoid damage

to the airbed or to soften the feel. Do not expose the airbed to extreme temperatures (hot

or cold). Stretching is a natural characteristic of new vinyl. During initial use, the airbed

may become soft and require additional inflation to maintain desired firmness. This is

normal for the first few days of use. Dimensions shown are approximate and will vary due

to the vinyl temperature and the air temperature.

In no event shall Intex, their authorized agents or employees be liable for damages

(such as pin holes) to the airbed caused by negligence, ordinary wear and tear,

abuse and carelessness, or external forces.

IMPORTANT NOTE

STORAGE INSTRUCTIONS

1. Deflate the airbed following the “DEFLATION” instructions.

2. Make sure the airbed is clean and dry.

3. Lay the airbed flat with the sleeping surface facing upwards and follow the folding steps

on Figs (10 - 14). Fold the airbed loosely and avoid sharp bends, corners and creases

which can damage the airbed.

FIG (10) FIG (11) FIG (12) FIG (14)

FIG (13)

4. Place the airbed inside the storage bag (if included) or the original packaging and store

in a dry place.

(37IO) I637USB ELECTRIC PUMP ENGLISH 4.875” X 7.25” 06/19/2021

English 37

SAVE THESE INSTRUCTIONS

Page 5

TROUBLESHOOTING GUIDE

PROBLEM CAUSE SOLUTION

Air pump does

not work

•Theexternalpoweradapter/

supply output is not correct.

•Pumprunningcontinuouslyfor

30 minutes, motor protection

system activated.

•Pumpcontinuouslyconnected

to a portable USB charger and

idled, hence the portable USB

charger is in rest mode.

•Makesuretheoutputoftheexternalpower

adapter, such as USB Wall Charger, Portable

USB Charger, 12V Car Charger or USB Port

is rated 5V / 2A or more. See “INFLATION”

section.

•Switchoffanddisconnectthelinecordfrom

the power adapter/ supply. Let the pump rest

for 1 minute before restarting.

•DisconnectandreconnecttheUSBcableto

the portable USB charger.

Airbed not fully

inatedafter

5 - 7 minutes

ofination

•Theexternalpoweradapter/

supply output amperage (A) is

less than 2A.

•Themanualinflationportcapis

not securely closed.

•Makesuretheoutputoftheexternalpower

adapter, such as USB Wall Charger, Portable

USB Charger, 12V Car Charger or USB Port

is rated 5V / 2A or more. See “INFLATION”

section.

•Pushthecapfirmlyintothemanualinflation

port.

Air leaking from

the pump panel

or compartment

cover

•Thecontroldialisnotintheoff

mark ( ) position.

•Themanualinflationportcapis

not securely closed.

•Turnthecontroldialtotheoffmark

( )

position after inflation is completed.

•Pushthecapfirmlyintothemanualinflation

port.

INFLATION OPTION

If electrical power is not available, a conventional foot, manual, or battery-operated air

pump can be used by connecting it to the manual inflation port located inside the line cord

compartment. Do not use high-pressure air compressors. See Fig (15). Follow these steps:

1. Open line cord compartment cover and locate the

manual inflation port.

2. Make sure the control dial of the internal electric

pump is still in the off mark ( ) position.

3. Remove the cap from the manual inflation port and

insert the nozzle of the pump into the port. Inflate the

airbed to desired firmness.

NOTE: Do not overinflate. The firmness should be

approximately the same as the level achieved with the internal electric pump.

4. Remove nozzle from manual inflation port and close the cap and the line cord cover.

FIG (15)
