IOGear GBP301 Manuale utente
Bluetooth Combo Print Adapter
User Manual (GBP301)
Welcome
Thank you for purchasing the IOGEAR Bluetooth Combo print adapter supporting both parallel and
USB printers. This print adapter is a first rate connectivity accessory designed to help reduce the
frustration of dealing with cables in your home or office. IOGEAR Combo print adapter with Bluetooth
Technology allows Bluetooth enabled computers to send print job wirelessly to either parallel or USB
printers.
©2004IOGEAR. AllRightsReserved. PKG-M0112
IOGEAR,theIOGEARlogo,MiniView,VSEaretrademarks orregisteredtrademarksofIOGEAR,Inc. Microsoft andWindows
areregisteredtrademarks of MicrosoftCorporation. IBMis a registeredtrademarkof International BusinessMachines,Inc.
Macintosh,G3/G4andiMacareregisteredtrademarksofAppleComputer,Inc. IOGEARmakesnowarrantyofanykind with
regardstotheinformationpresentedinthisdocument. Allinformationfurnishedhereisforinformationalpurposesonlyandis
subjecttochangewithoutnotice. IOGEAR,Inc. assumesnoresponsibilityfor anyinaccuraciesorerrors thatmayappearinthis
document.
PackageContent
Overview
Features
Requirements
Introduction
Installation
Application
- Print from Computers
- Print from PDAs
The Utility Software
Specification
TechnicalSupport
Radio and TV Interference Statement
LimitedWarranty
2
3
4
5
6
8
12
12
13
31
32
33
34
35
Table of Contents
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○
○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
2
This package contains:
1– Bluetooth Print Adapter
1–Manual on CD
1– Quick Start Guide
1–Warranty/Registration Card
1–Power Adapter
* If any items are damaged or missing, please contact your dealer.
Package Contents
IOGEAR’s palm sized ComboWireless Print Adapter with BluetoothTechnology allows any Bluetooth enabled
computer or PDA to wirelessly send the print job to a USB or a parallel printer. It complies with USB 1.1,
IEEE 1284, and the Bluetooth 1.1 specifications. It supports data transmission rates of up to 723 Kbps, and
a wireless access range of up to 330ft (100 meters).
This unit supports HCRP (Hardcopy Cable Replacement Profile) and SPP (Serial Port Profile), all of which
resides on onboard flash memory.The RF circuitry on the RF chip includes complete receiver and transmitter
functions.
This is a plug-n-play unit, it doesn’t require any special driver, plug it in the USB or parallel printer is all that
entails.
Overview
3
Features
• Allows any Bluetooth enabled computer or PDA to wirelessly send print jobs to a USB or a parallel printer
• Plug and Play, easy to install
• Bluetooth Class 1 device with a 330 ft range (100 meters)
• Supports data rate of 723 Kbps
• Supports Pico-net and Scatter-net and up 7 devices
• Complies with USB 1.1, IEEE 1284, and the Bluetooth 1.1 specifications
• Supports HCRP (Hardcopy Cable Replacement Profile) and SPP (Serial Port Profile)
4
System Requirements
ComputersandPDAs:
• Windows based & Bluetooth enabled
• Additional software may be required for PDAs
Printer:
• Either a USB or a parallel printer.*
*Only 1 printer is recommended to be connected, does not support two printers simultaneously.
Multifunction printers not supported.
5
Introduction
1. USB printer port
2. IEEE1284 parallel printer port
3.Power connection
4. Reset button
5.PowerLED
6.Bluetooth LED
7.Printer LED
6
IOGEAR Bluetooth Combo Print Adapter supports both IEEE1284 and USB printers, but only one connection
at a time. In other words, it doesn’t support two printers simultaneously. If you plug printers to both parallel
and USB ports, only the parallel printer connected will work.
The RESET button is to re-initialize the printer adapter. Use a pointed object to initialize the Reset process.
The Power LED turns on when power is supplied through the power adapter.
The Bluetooth LED blinks when Bluetooth link is established but no data is transmitted on the line. It stays
on when data is transmitted.
The Printer LED is on when there is a USB or parallel printer connected to the Bluetooth print combo adapter.
It is OFF when no printer is connected. It blinks when the print combo adapter is receiving data transmis-
sion.
Introduction
7
