IOGear MiniView G-CS102U Manuale utente



Microsoft and Windows 98 are registered trademarks of Microsoft

Corporation.

IBM is a registered trademark of International Business Machines,

Inc.

Macintosh, G3/G4 and iMac are registered trademarks of Apple

Computer, Inc.

ATEN is a registered trademark of ATEN Technology, Inc.

IOGEAR is a registered trademark of ATEN Technology, Inc.

ATEN Technology makes no warranty of any kind with regards to

the information presented in this document. All information fur-

nished here is for informational purposes only and is subject to

change without notice. ATEN Technology assumes no responsi-

bility for any inaccuracies or errors that may appear in this docu-

ment.

Packing List

This complete IOGEAR MiniViewTM package consists

of:

•One MiniViewTM: USB KVM switch

•Two or four USB A-B cables

•Two or four VGA cables

•One DC 5V Power Adapter

•One User Manual & Quick Setup Guide

Please check to make sure that all components are

included and nothing is damaged. If you discover a

problem, please contact your dealer. Before connect-

ing your MiniViewTM, read the manual thoroughly and

follow the installation and operation procedures care-

fully in order to prevent any damage to the unit and/or

any devices it connects to.

System Requirements:

Any PC or Macintosh computer with:

An available USB port

A USB-compliant operating system

(Windows 95 OSR 2.0, Windows 98, Windows

2000, MacOS 8.1 or later)

A standard HDB-15 video adapter

Packing List & System RequirementsPacking List & System Requirements

Contents

ContentsContents

Introduction ……...…………...……... 0101

Features ………………………………... 0202

Specifications ………………….……… 0303

Component Overview ….…..………… 0404

Front View

Back View ………………………………….. 0606

Installation …………………………..… 0808

Connection Diagram …..…………..… 0909

Operation ………………...…………..… 1010

Manual Port Selection

Auto Scan Mode 1111

Appendix A ……………………………… 1212

Troubleshooting

Appendix B ……………………………… 1313

Contacting IOGEAR

Appendix C ………………………………. 1414

Radio & TV Interference Statement

Limited Warranty

Introduction

Thank you for purchasing a MiniViewTM: USB KVM

switch, a revolutionary new KVM design from IOGEAR.

Recognizing the importance of USB for small office &

home office users, we’ve combined four downstream

USB ports and a standard HDB-15 video port into a sin-

gle KVM switch that fits right on your desktop. Now you

can use the MiniViewTM: USB to share a monitor and four

USB devices between two (G-CS102U) and four (G-

CS104U) computers. Connect a USB keyboard, USB

mouse and two other USB devices –any USB devices.

Scanners, Zip Drives, Printers and all other USB compli-

ant devices will work with the MiniViewTM: USB. If four

USB devices aren’t enough, connect a USB hub to one of

the shared ports and expand your USB capacity. Be-

cause the MiniViewTM: USB is platform-independent, you

can use it with Macs and PCs. Your only limitation is the

software support for your USB peripherals. Rest as-

sured, though, that if your peripherals will work with a

Mac and a PC, they’ll work with the MiniViewTM: USB as

well. We sincerely hope you enjoy using your new Mi-

niViewTM: USB. If you have any questions or comments

regarding this product, or any other IOGEAR products,

please feel free to contact us. Full contact information is

available on the Contacting IOGEAR page in this manual.

IntroductionIntroduction

Features

•Use one keyboard, monitor and mouse to control be-

tween two and four PCs.

•Share four USB devices among attached com-

puters.

•USB 1.1 compliance ensures full compatibility with

your USB devices.

•Operating System-independent operation.

•Connected PC’s can be added or removed from the

setup without powering off the KVM switch.

•Plug-n-Play monitor support.

•MiniviewTM switches support video resolutions up to

1920 x 1440.

•No software required.

•Built in Auto Scan mode.

•Buffering technology prevents system failure.

•LEDs allow for easy status monitoring.

•Saves space, power, and equipment costs.

•Trim-line, compact design for easy use.

•Uses standard connectors to connect PC’s.

•3 Year Limited Warranty.

FeaturesFeatures

Specifications

SpecificationsSpecifications

noitceleStroPsyeKtoHnottuBnoitceleStroP/

sDEL detceleS-troP

srotcennoCelosnoCrotinoM)F(AGV51-BDH

BSU)maertsnwoD(A-epyT

srotcennoCCProtinoM)M(AGV51-BDH

BSU)maertspU(B-epyT

noituloseRoediVB2CDD,0441x0291:xaM

nacSotuAlavretnI sdnoces51ro3

noitpmusnoCrewoPAm51V5CD

gnisuoHlateM/citsalP

erutarepmeTgnitarepOC°04~C°5

erutarepmeTegarotSC°06~C°02-

ytidimuHgnisnednocnoN,HR%08~0

thgieWsecnuo9.4:U201SC-G

secnuo38.83:U401SC-G

)HxWxL(snoisnemiD"1.1x"4.3x"0.4:U201SC-G

U401SC

Overview

OverviewOverview

Front View:

1 Selected LEDs

These LEDs indicate the currently selected port.

2 Auto Scan LED

The Auto Scan LED flashes when Auto Scan Mode is in

effect.

3 Port Selection Switch

The Port Selection Switch is located on the front panel,

just opposite the Select Arrow on the front panel. Press

this push button to cycle among the connected com-

puters. The Selected LED on the front panel lights to indi-

cate which port is selected.

4. On-Line LEDs

These LEDs indicate that a computer is properly con-

nected to the switch, powered on and operational.

5. Auto Scan Switch

This push button toggles Auto Scan Mode for the

MiniViewTM: USB.

Overview

Overview...Overview...

2 3

Overview

Rear View

1.) Console Video Connector

Connect your monitor here.

2.) Power Jack

If you choose to use an external DC 5V power adapter,

connect it here.

3.) Scan Time Selection Switch

This slide switch selects the amount of time the

MiniViewTM: USB will monitor each port (3 or 15 seconds)

when Auto Scan Mode is enabled.

4.) Downstream USB Ports

Connect your USB keyboard, USB mouse and two other

USB devices here.

5.) Upstream USB Ports

These Upstream ports connect to your Mac or PC to pro-

vide the necessary connection between the MiniViewTM:

USB and the computer.

6.) PC Video Ports

These video ports connect to your iMac, G3/G4 or PC to

provide the necessary connection between the MiniViewTM:

USB and the computer.

Overview...Overview...
