IP-COM G3210P Manuale utente
Copyright Statement
i
Copyright Statement
is the registered trademark of IP-COM Networks Co., Ltd. All the products
and product names mentioned herein are the trademarks or registered trademarks of their
respective holders.Copyright of the whole product as integration, including its accessories
and software, belongs to IP-COM Networks Co., Ltd. No part of this publication can be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means without the prior written permission of IP-COM
Networks Co., Ltd. If you would like to know more about our product information, please
visit our website at www.ip-com.com.cn.
Disclaimer
Pictures, images and product specifications herein are for references only. To improve
internal design, operational function, and/or reliability, IP-COM reserves the right to make
changes to the products described in this document without obligation to notify any person
or organization of such revisions or changes. IP-COM does not assume any liability that
may occur due to the use or application of the product or circuit layout(s) described herein.
Every effort has been made in the preparation of this document to ensure accuracy of the
contents, but all statements, information and recommendations in this document do not
constitute the warranty of any kind, express or implied.
Preface
ii
Preface
Thank you for choosing IP-COM! Reading this manual will be helpful for you to configure
this device.
Convention
If not specifically indicated, the switch, this product, or this device mentioned in this Install
Guide stands for IP-COM 8GE+2SFP Managed PoE Switch G3210P.
Symbols in this Install Guide:
Symbol
Meaning
Note
Ignoring this type of note may result in a malfunction or
damage to this device.
Tip
This format is used to highlight a procedure that will save
time or resources.
Overview of this Install Guide
Chapter
Description
Chapter I Product
Overview
Introduction to this switch’s package contents, physical
appearance and features
Chapter II Installation
Introduction to this switch’s installation considerations and
installation procedures
Chapter III Device
Management
Introduction
Introduction to how to manage the switch via Web manager
and fundamental operations about Web manager
Chapter IV Advanced
Settings
Introduction to how to configure functions of the switch
Chapter V Appendix
Introduction to technical specifications, default settings and
safety statement of the switch
Technical Support
Website: http://www.wirelessnetworkproducts.com
Tel: 1.631.588.3877
Email: techs@hdcom.com
iii
Contents
Contents
Copyright Statement ...................................................................................................................... i
Disclaimer ........................................................................................................................................ i
Preface............................................................................................................................................. ii
Convention.......................................................................................................................................... ii
Overview of this Install Guide.......................................................................................................... ii
Technical Support.............................................................................................................................. ii
Contents......................................................................................................................................... iii
Product Overview ..........................................................................................................................1
Package Contents.............................................................................................................................2
Physical Appearance ........................................................................................................................ 2
Installation ...................................................................................................................................... 6
1 Installation Considerations............................................................................................................ 7
2 Tools................................................................................................................................................. 8
3 Installation .......................................................................................................................................8
4 Connect to Protective Grounding Cable ................................................................................... 10
5 Connect to Power Supply............................................................................................................11
6 Cable Connection......................................................................................................................... 11
7 Power up the Device....................................................................................................................14
Device Management Introduction............................................................................................. 15
1 Web Administration......................................................................................................................16
2 Web Login ..................................................................................................................................... 16
3 Web Logout...................................................................................................................................18
4 Layout of Web Browser-Accessible Administrator Page........................................................ 18
5 Commonly Used Elements on Web Browser-Accessible Administrator Page.................... 19
Advanced Settings ...................................................................................................................... 21
Administration .................................................................................................................................. 22
Port Management............................................................................................................................31
VLAN Management......................................................................................................................... 43
PoE Management............................................................................................................................ 62
Time Range Management..............................................................................................................64
Device Management....................................................................................................................... 66
iv
Contents
QoS.................................................................................................................................................... 97
Security...........................................................................................................................................108
Maintenance................................................................................................................................... 113
Logout .............................................................................................................................................119
Save Configurations......................................................................................................................121
Appendix..................................................................................................................................... 124
FAQs................................................................................................................................................125
Technical Specifications ...............................................................................................................125
Default Settings..............................................................................................................................129
Safety and Emission Statement .................................................................................................. 133
Product Overview
Package Contents
Physical Appearance
Product Overview
2
Package Contents
Open the package and verify the following items:
Switch (1)
Power Cord (1)
L-shaped Bracket (2)
Screw (6)
Footpad (4)
Install Guide (1)
If any item is missing or damaged, contact the place of purchase immediately.
Physical Appearance
1 Front Panel
The following parts are located on the front panel shown as below.
Reset Button
With the switch powered on, pressing the Reset button for at least 5 seconds and then
releasing it, restores the switch to factory default settings. The switch will reboot
automatically after reset and this process takes about 45 seconds.
While rebooting, the following will occur: All LEDs light upSYS LED is offAll LEDs are
off except the Power LEDSYS is on and blinking.
LEDs
The following table describes the LED designations：
LED
Status
Description
Power
Solid
Proper connection to power supply
Off
Improper connection to power supply or malfunction
occurs.
SYS
Blinking
The system is functioning properly.
Solid
The system is functioning improperly.
Off
The system is still rebooting.
Product Overview
3
Link/Act
Solid
A valid link is established on the corresponding RJ45 port.
Blinking
Data transmission is occurring on the corresponding RJ45
port.
Off
No link is established on the corresponding RJ45 port.
PoE/Status
Solid
The PoE powered device (PD) is connected on the
corresponding RJ45 port and the port is supplying power
successfully.
Off
No PoE powered device (PD) connected.
SFP1&SFP2
Solid
A valid link is established or data transmission on the
corresponding SFP port.
Off
No link is established on the corresponding SFP port.
RJ45 Ports
This switch comes with eight 10/100/1000Mbps auto-negotiation RJ45 ports. Each port
has a corresponding Link/Act LED. Speeds and corresponding working modes of all RJ45
ports are described in the following table.
Speed
Working Mode
10Mbps (auto-negotiation)
Half/Full duplex auto-negotiation
100Mbps (auto-negotiation)
Half/Full duplex auto-negotiation
1000Mbps (auto-negotiation)
Full duplex auto-negotiation
All RJ45 ports are PoE-capable, and can connect up to eight IEEE 802.3af-compliant PDs
(15.4W for each) or four IEEE 802.3at-compliant PDs (30W for each).
Tip:
As pair 1/2 and pair 3/6 are applying PoE power, it is advisable to use CAT 5 or higher
UTP/STP cables. Note that Ethernet specifications limit the cable length between the
switch and the attached device to 100 m (328 feet).
SFP Ports
This switch comes with two 1000Mbps SFP fiber ports, accommodating a standard SFP
fiber module.
SFP (Small Form-factor Pluggable）is a compact, hot-pluggable transceiver mainly used
Product Overview
4
for implementing the switchover between fiber and electricity signals, including fiber rate
control, modulation sending, signal detection, IV transformation and amplifier limiting
judgment regeneration.
An optical fiber connector terminates the end of an optical fiber. The optical fiber
connector (known as union), an indispensable passive device in optical fiber
communication, is mainly used for detachable optical fiber connection, which is not only
convenient for commissioning test and maintenance of the optical fiber system, but makes
this system’s switch-over and scheduling more flexible.
G3210P only supports LC optical fiber connector as shown below:
Tip:
The optical fiber module or photoelectric converter is not included in the package and you
need to prepare it by yourself.
2 Back Panel
The following parts are located on the back panel as shown below:
Power ON/OFF
Used for controlling power supply of this device.
Grounding Terminal
Used for connecting the protective grounding cable for inductive lightning protection. As
Product Overview
5
for the method of connecting protective grounding cable, please refer to Connect to
Protective Grounding Cable.
Power Socket
Used for connecting the included power cord for power supply.
