iPazzPort KP-810-61 Manuale utente
User manual
KP-810-61
(Bluetooth version)
www.iPazzPort.com
Email: support@iPazzPort.com
Video tutorial on YouTube: iPazzPortfan
1
Home
Searching
E-mail
Android Browser
Previous
Play/Pause
Next Track
Volume Down
Volume Up
Mute
Back
FN+ L ock/Unlock the
keyboard
FN+ 8 exclusive buttons of
IR learning function
To lock/unlock the
function of the touchpad
Turn on/off backlit or
change the backlit color
QWERTY layout
Battery cover
is inside, need to be
removed before use
Battery insulation sticker
1 Basic information:
1.1 Application:
Windows,Mac, Android/Google, Linux,
Computer,Smart TV, Raspberry Pi, TV box,set-top box
- Mini bluetooth/IR backlit keyboard for home entertainments,
education, training, meeting, speech and projector
-
- Firestick, Apple TV, Tablet, iPad, Mobile phone,etc or
1.4 Specifications:
- Wireless connection
- Max Distance:10 m
- Dimensions: 142.5X97X19.8mm
- Weight: 121g
- voltage: 3.3V
- Power Supply:
Working
Rechargeable Li-ion battery
2
1.3 Package:
- Mini Keyboard 1
- User manual 1
- USB cable 1
1.2 Feature:
- 8 exclusive buttons of IR learning function;
- Bluetooth connection(Do not provide bluetooth dongle)
- Miniature, portable to carry out;
- Multiple gesture recognitions and scrollbar;
- QWERTY full keyboard layout;
- Multiple languages version (needed to be customized);
- Backlit for convenient operation in dim room;
- Powered by Li-ion battery, long standby.
1.5 System Requirement:
- Windows
- Mac OS
- Linux
- Android/Google/Smart TV
2 How to use:
.
2.1. Recharge your keyboard: when your keyboard is always flashing even without any operation, this means your
keyboard is in low power capacity. Please charge it by connecting micro end of USB cable to your keyboard and
another end to computer.
(the will light up and be steady on, and then go out when it is fully charged.)
Note: To ensure a better performance, please charge the keyboard the first time you use it.
3
Low-power indicator
IR/Charging indicator
Signal indicator
1
2.3 Establish Bluetooth connection:
Step 1.Find and turn on ‘Bluetooth’ function on your devices, search new devices around;
Step 2.Turn on ipazzport keyboard and press key ‘FN’ and ‘Esc’ (with an signal icon) simultaneously till the
blue indicator flashes (about 2-5 seconds)
Step 3.Your devices will display “iPazzPort Bluetooth’ option, click it to connect, the blue indicator goes off after done.
2.2 Open the battery cover and remove the insulation sticker;
(If can’t find it,need to delete the existing bluetooth records,because device only support limited bluetooth connection)
3 .IR learning
4
1) On iPazzPort keyboard,hold down the button “ ” seconds, until the second light flash to solid.
2) Put together your keyboard remote and the source IR remote, head to head, approximately 1 inch apart.
3) Press the button on keyboard "+" for example, and the LED will start blinking and be steady on, then press
the button V+ on your source IR remote.
4)The LED on the keyboard will blink 3 times quickly, indicating a successful learning
5) While LED is on solid, repeat steps 3) & 4) to program other target buttons.
6) When the learning process is all completed, just wait for its auto setting process approximately 10 seconds
till the LED goes off.
7) It is ready to use, now.
Note: Please wait for 3 seconds before programming the next button.
1The detailed steps are printed
on the battery cover
.
Power/Source/Volume+-/
Channel up/down /
Other two free buttons
Note:
1.Only work for the TV Remote which support IR learning feature;
2.All the 8 buttons could program with each tv remote key,the mark
is to remind the common feature.
Steps:
5
4.Multi-touch function：
the touchpad supports various gesture as described below:
One finger:
( 1)Slide to move the cursor;
(2)Keep pressing " FN" and slide freely to scroll up/down the screen (to change the entire touchpad to a scrollbar);
(3)Single click to act as the left mouse;
(4)Double click to open a file or application;
(5)Two quick clicks on the touchpad, and don't let your finger go on the second click and slide to move the file or picture.
(6) Hold down the left mouse button and slide your finger on touchpad to select the target.
Two finger: Click to act as right mouse.
Scroll Bar:slide the scroll bar to up/down the page.
5.FAQ:
1).No response between keyboard with devices?
1.1 power off and on the keyboard;
1.2 Pair keyboard with your device as instruction 2.2.
2 ).Touchpad works unnormally?
2.1 Press Fn+Spacebar to adjust the sensitivity;
2.2 Charge keyboard with full power;
3).Get repeated letter in just one keystroke?
3.1 Charge the keyboard for hours;
3.2 Pair keyboard with your devices again refer to step 2.3;
5).What about the backlit?
Click button to turn on backlit and change the
color between RGB
.
If still can't solve the issues or any other needs ,
contact email: before return it.
Solution will be offered within 24 hours,
What’s more, you will be invited to review our
latest products for free in the future.
support@ipazzport.com
6).The OK button can’t work?
The Enter or Spacebar key do the same function
as device system change
4).Can’t find bluetooth signal or fail to connect?
Delete the existing bluetooth records on your device,
it only supports limited bluetooth connection.
Notice to customers
WEEE Directive & Product Disposal:
At the end of its serviceable life,this product should not be treated as household or general waste. It should be handed
over to the applicable collection point for the recycling of electrical and electronic equippment, or returned to the supplier
for disposal.
This symbol on the battery indicates that the battery is to be collected separately.
The following applies only to users in European countries.
This battery is designed for seperate collection at an appropriate collection point.
Do not dispose of this battery as household waste.
For more disposal information, please contact the retailer or local authorities in charge of waste, management.
Caution :
1) Your changes or modifications that are not permitted by the dealer may result in product damage and invalid warranty
2) Please use the right battery replacement to avoid battery explosion in charging process.
3) Please dispose of the used battery properly as we suggested
6
