IQunix A80 Series Manuale utente

321

New Design

New Series

A80 SERIES

MECHANICAL KEYBOARDS

User Guide

使用说明书

321

English Version

Please read this manual guide and cautions

to ensure that using this product correctly.

Start Reading

Details

Product Speciﬁcation

Product Name: AVER 80

Keyboard Type: Mechanical Keyboard

Key Quantity: 83 Keys

Keyboard Material: ABS Case + PBT Keycaps

Character Technology: Dye Sublimation

Large Key Structure: Costar Stabilizers

Rating: 5V⎓1A

Connect Interface: USB Type-C

Cable Length: 180cm

Dimensions: 321*158*52mm

Origin: Shenzhen, China

Web: www.IQUNIX.store

Support E-mail: [email protected]

A Type-C Port

D Mode Switch E Silicone Pads

B Indicator C Feet

Three Ways of Connecting Devices

Bluetooth Connection Mode

IQUNIX AVER80 BT 1

Seaching Bluetooth Device

Enable Bluetooth matching (Computer / Phone / Tablet)

Toggle the keyboard Mode Switch to wireless side

(Bluetooth matching mode on when blue light blinks.)

Select the matching device 【IQUNIX AVER80 BT 1】

Indicator light turning oﬀ when matching successfully.

If you need to connect a new device, please hold FN+1 for 5 seconds to

remove the previous device. When the LED indicator blinks blue light,

you can connect your device following the Step 2.

Wired Connection Mode

Plug the USB cable into your device.

For Wireless Version, toggle the keyboard

Mode Switch to wired side.

2.4GHz Connection Mode

Plug the 2.4GHz receiver into your computer.

Toggle the keyboard Mode Switch to wireless side.

Press FN+4 to enter 2.4GHz matching mode

(2.4GHz matching mode on when pink light blinks.)

Indicator light turning oﬀ means successful matching.

Function Keys Combinations

LED Indicator Keys Combinations

(RGB Version)

F1 F2 F3 F4 F9 F10 F11 F12

E R T Y U I O P

A S D F G H J K L

”

‘

ESC F5 F6 F7 F8

Z X C V B N M

‘

SHIFT

{

[

}

]

BACKSPACE

(

)

ALT CTRL

TAB

CAPSLOCK

CTRL ALT

SHIFT

WIN

ENTER

;

DEL

PRT

PGUP

PGDN

HOME

END

My Computer

(for Windows)

Browser

Calculator

(for Windows)

Win Lock

Play / Pause

Mute

Volume -

Volume +

InsTask Manager

(for Windows)

F1 F2 F3 F4 F9 F10 F11 F12

E R T Y U I O P

A S D F G H J K L

”

‘

ESC F5 F6 F7 F8

Z X C V B N M

‘

SHIFT

{

[

}

]

BACKSPACE

(

)

ALT CTRL

TAB

CAPSLOCK

CTRL ALT

SHIFT

WIN

ENTER

;

DEL

PRT

PGUP

PGDN

HOME

END

Backlight

On / Oﬀ

Brightness +

Brightness -

Backlight

Eﬀects

Switching

Backlight

Colors

Switching

Backlight Speed -

Backlight Speed +

F1 F2 F3 F4 F9 F10 F11 F12

E R T Y U I O P

A S D F G H J K L

”

‘

ESC F5 F6 F7 F8

Z X C V B N M

‘

SHIFT

{

[

}

]

BACKSPACE

(

)

ALT CTRL

TAB

CAPSLOCK

CTRL ALT

SHIFT

WIN

ENTER

;

DEL

PRT

PGUP

PGDN

HOME

END

Mac / Windows Layout Switching

Swap CapsLock and Left Ctrl Reset to Default

F1 F2 F3 F4 F9 F10 F11 F12

E R T Y U I O P

A S D F G H J K L

”

‘

ESC F5 F6 F7 F8

Z X C V B N M

‘

SHIFT

{

[

}

]

BACKSPACE

(

)

ALT CTRL

TAB

CAPSLOCK

CTRL ALT

SHIFT

WIN

ENTER

;

DEL

PRT

PGUP

PGDN

HOME

END

Switch to

Bluetooth Mode

Switch to

2.4GHz Mode

Battery Level Check

The LED Indicator blinks 1, 2, 3,…10 times,

which stands for 10%, 20%, 30%,…100% battery level.

Special Keys Combinations

(Hold for 5 Seconds）

Special Keys Combinations

(Wireless Mode)

LED Indicator Status Description

Device Charging and Battery Status

Bluetooth Device Matching

Special Status

2.4GHz Mode

Enter 2.4GHz Mode

Pink Light

Blinking

Charging

Yellow Light

Blinking

Charging Completed

(Wired Mode)

Green Light

Blinking 3 Times

Charging Completed

(Wireless Mode)

Green Light

Less than 10%

(Wireless Mode)

Red Light

Blinking

White Light

Blinking 5 Times

White Light

Reset to Default CapsLock On

Blue Light

Blinking

Bluetooth Matching on

Turquoise Light

Blinking

Bluetooth Device

Re-Connection

Mac / Windows Layout Switch

To learn more details, please reach out

to us on oﬃcial website or social media.

Oﬃcial website: www.IQUNIX.store

F1 F2 F3 F4 F9 F10 F11 F12

E R T Y U I O P

A S D F G H J K L

”

‘

ESC F5 F6 F7 F8

Z X C V B N M

‘

SHIFT

{

[

}

]

BACKSPACE

(

)

ALT CTRL

TAB

CAPSLOCK

CTRL ALT

SHIFT

WIN

ENTER

;

DEL

PRT

PGUP

PGDN

HOME

END

command command

option option

Hold for 5 seconds to switch the layout between macOS and windows systems.
