i.safe MOBILEEnglish

This document contains informaon and safety regulaons which are to be

observed without fail for safe operaon of the mobile phone CHALLENGER

2.0 under the described condions. Non-observance of this informaon and

instrucons can have serious consequences and / or may violate regulaons.

More detailed instrucons on the use of the phone can be found at

www.isafe-MOBILE.com or directly at i.safe MOBILE GmbH.

Please read the manual and these safety instrucons before using the

phone. In case of contradicng informaon, the text of these safety instruc-

ons shall apply.

In case of any doubt, the German version shall apply.

The current EC declaraon of conformity, EC and IECEx cerﬁcates of con-

formity, safety instrucons and manual can be found at www.isafe-

mobile.com, or requested from i.safe MOBILE GmbH.

Reservaon: Technical Data is subject to change without noce. Changes,

errors and misprints may not be used as a basis for any claim for damages.

i.safe MOBILE GmbH cannot be held responsible for any data or other loss

and direct or indirect damages caused by any improper use of this phone.

Ex-Speciﬁcaons

The CHALLENGER 2.0 is a mobile phone suitable for use in potenally explo-

sive atmospheres classiﬁed as Zone 2 in accordance with direcves 94/9/EC

(ATEX 95) and 99/92/EC (ATEX 137).

Ex-markings

ATEX II 3G Ex ic IIC T4 Gc

EPS 14 ATEX 1 662 X

2004

Temperature range: -20 ... +60°C

Manufactured by: i.safe MOBILE GmbH

i_PARK TAUBERFRANKEN 10

97922 Lauda-Koenigshofen

Germany

i.safe MOBILEEnglish

EC Declaraon of Conformity

The EC declaraon can be found at the end of this manual.

Faults and Damages

If there is any reason to suspect that the safety of the phone has been com-

promised, it must be withdrawn from use and removed from any ex-

hazardous areas immediately.

Measures must be taken to prevent any accidental restarng of the phone.

The safety of the phone may be compromised, if, for example:

· malfuncons occur.

· the housing of the phone or the baery shows damage.

· the phone has been subjected to excessive loads.

· the phone has been stored improperly.

· markings or labels on the phone are illegible.

It is recommended that a phone which shows or which is suspected of faults

and damages is returned i.safe MOBILE GmbH for inspecon.

Ex-relevant Safety Regulaons

Use of this phone assumes that the operator observes the convenonal safe-

ty regulaons and has read and understood manual, safety instrucons and

cerﬁcate.

The following safety regulaons must also be complied with:

· Inside ex-hazardous areas the phone must be closed. The baery cover

has to be ﬁxed by the two screws and the covers of the interfaces have to

be closed.

· To ensure the IP-protecon, it has to be ensured that all gaskets are pre-

sent and funconal. The screws at the top and the boom of the back of

the phone need to be covered by the black gaskets, so that the screw

heads are not visible. There must be no large gap between the two halves

of the housing.

· The baery may only be exchanged or charged outside ex-hazardous are-

as.

i.safe MOBILEEnglish

· The phone may only be charged outside ex-hazardous areas using the

appropriate charger or other equipment approved by i.safe MOBILE

GmbH.

· Use only the appropriate baery type BPC02A.

· It is not allowed to carry spare baeries into ex-hazardous areas.

· The phone may be charged only at temperatures in between 0°C ... 45°C.

· The phone must not be exposed to abrasive acids or bases.

· The phone must not be taken into zones 0, 1, 20, 21 or 22.

· Only accessories approved by i.safe MOBILE GmbH may be used.

Further Safety Advises

· Do not touch the screen of the phone with sharp objects. Dust parcles

and nails may scratch the screen. Please maintain the screen clean. Re-

move dust on the screen with a so cloth gently, and do not scratch the

screen.

· Charge the phone under indoor condions only.

· Do not put the phone in environments with excessive temperatures, as

this could lead to heating of the battery, resulng in ﬁre or explosion.

· Do not charge the phone near any ﬂammable or explosive substances.

· Do not charge the phone in environments with much dust, humidity, or

excessively high or low temperatures (the permied charging tempera-

ture range is 0 ... 45°C).

· Do not use the phone in areas where regulaons or legislaves prohibit

the use of a mobile phone.

· Do not expose the phone, baery or charger to strong magnec ﬁelds,

such as are emied from inducon ovens or micro-waves.

· Do not aempt to open or repair the phone. Improper repair or opening

can lead to the destrucon of the phone, ﬁre or explosion. Only author-

ized personnel are allowed to repair the phone.

· Only use accessories approved by i.safe MOBILE GmbH.

· Please do not directly connect the poles of the baery, to avoid short-

circuiting the baery.

· Power oﬀ the phone in hospitals or other places where the use of mobile

phones is prohibited. This phone may aﬀect proper work of medical

equipment, such as pacemakers, so always keep a distance of at least 15

cm between the phone and these devices.

· Observe all corresponding laws that are in force in the respecve coun-

tries regarding the use of mobile phones while operang a vehicle.

i.safe MOBILE

English

· Please power oﬀ the phone and disconnect the charging cable before

cleaning the phone.

· Do not use any chemical cleaning agents to clean the phone or the

charger. Use a damp and an-stac so cloth for cleaning.

· Do not discard old and abandoned lithium baeries into the trash, send

them to designated waste disposal locaons or return them to i.safe

MOBILE GmbH.

· The user alone is responsible for any and all damages and liabilies caused

by malware downloaded when using the network or other data-exchange

funcons of the phone. i.safe MOBILE GmbH cannot be held responsible

for any of those claims.

Warning

i.safe MOBILE GmbH will not assume any liability for damages caused by

disregarding any of these advices or by any inappropriate use of the phone.

Maintenance / Repair

Thank you for using the CHALLENGER 2.0. If there is a problem with the

phone, please contact your vendor or consult the service center. If your

phone is in need of repair, you can either contact the service center or your

vendor.

Baery

The baery is inserted into the back of the phone. The baery is not fully

charged when the phone is purchased, but it contains enough energy to

power on the phone. To obtain best baery performance and baery life, let

the baery discharge completely before charging it completely for the ﬁrst

three charging cycles.

Installing the Baery

Turn the mobile phone upside down, open the screws and remove the bat-

tery cover. Install the baery by inserting the teeth at the top of the baery

into the corresponding notches of the phone.

When installing the baery cover, insert the teeth at the boom of the cover

into the corresponding notches of the mobile phone, then press the baery

cover down and secure it by turning the two screws. Ensure that the baery

is safely in place before installing the baery cover and powering on the

phone.

i.safe MOBILEEnglish

Charging the Baery

Connect the USB-cable with the USB connector at the boom of the phone.

Connect the other side of the USB cable with the socket of the Power Supply.

Aer charging, remove the USB-cable from the charger.

Baery Use

In actual use, the standby me and talk me of the phone varies with the

network status, working environment and usage.

When the power of the baery is lower than normal, the phone will prompt

you to charge it. Please charge the baery; otherwise you may lose any ﬁles

which are not saved.

If you do not charge for a long me, the phone will be powered oﬀ automat-

ically.

Warning

The phone may only be charged at ambient temperatures in a range from

0°C…45°C. Please do not use charging equipment if the temperature exceeds

this range.

Installaon of the SIM Cards

The phone features two SIM card slots. The slots are accessible aer removal

of the baery. If you have installed two SIM cards, you can choose your pri-

mary card in <Sengs> → <Dual SIM sengs>.

Warning

Do not try to insert or remove any of the SIM cards when any external power

supply is connected, otherwise the SIM cards or the phone may be damaged.

Installaon of the Micro-SD Card

The slot for the Micro-SD card is accessible aer removal of the baery.

Open the Micro-SD card holder, and insert the Micro -SD card into the slot,

then close the Micro-SD card holder.

Keys and Special Features

(see ﬁgure on page 2)

(1) Power: Lock the phone.

Long press to power up or down the phone.

(2) Send: Bring up the call log.

Answer a call when the phone is ringing.

(3) Contacts: Context sensive key.

Opens the Phonebook while on the home screen.

(4) Menu: Context sensive key.

Enter sengs while on the home screen.

(5) OK: Conﬁrm the selected item or funcon.

(6) Navigaon: 4-way navigation through menus.

(7) Keypad: Use for text or number entry.

(8) Torch: Turn the torch on or oﬀ.

(9) Volume: Adjust the volume.

(10) Baery: Use these screws to open the baery compartment.

(11) Camera: Not installed in CHALLENGER 2.1.

(12) USB: USB connector for charging and data-transfer.

Security Sengs

To change security relevant sengs, the phone may ask for a password. The

standard password is 1122.

Recycling

The crossed-out wheeled-bin symbol on your product, baery, literature, or

packaging reminds you that all electrical and electronic products, baeries,

and accumulators must be taken to separate collecon at the end of their

working life. This requirement applies in the European Union. Do not dispose

of these products as unsorted municipal waste.

Always return your used electronic products, baeries, and packaging mate-

rials to dedicated collecon points. This way you help prevent uncontrolled

waste disposal and promote the recycling of materials.

More detailed informaon is available from the product retailer, local waste

authories, naonal producer responsibility organisaons, or your local

i.safe MOBILE GmbH representave.

i.safe MOBILEEnglish

The content of this document is presented as it currently exists. i.safe

MOBILE GmbH does not provide any explicit or tacit guarantee for the accu-

racy or completeness of the content of this document, including, but not

restricted to, the tacit guarantee of market suitability or ﬁtness for a speciﬁc

purpose unless applicable laws or court decisions make liability mandatory.

i.safe MOBILE GmbH reserves the right to make changes to this document or

to withdraw it any me without prior noce.

i.safe MOBILEEnglish

i.safe MOBILEDeutsch

Dieses Dokument enthält Informaonen und Sicherheitsvorschrien die für

einen sicheren Betrieb des Mobiltelefons CHALLENGER 2.0 unter den be-

schriebenen Bedingungen unbedingt zu berücksichgen sind. Nichtbeach-

tung dieser Informaonen und Anweisungen kann gefährliche Folgen haben

oder gegen Vorschrien verstoßen.

Lesen Sie die Bedienungsanleitung und diese Sicherheitshinweise bevor Sie

das Telefon benutzen!

Im Falle widersprüchlicher Informaonen gelten die deutschen Anweisungen

in diesen Sicherheitshinweisen.

Die gülge EG-Konformitätserklärung, EG und IECEx Baumusterprüeschei-

nigung, Sicherheitshinweise und Bedienungsanleitung können unter

www.isafe-mobile.com heruntergeladen oder bei der i.safe MOBILE GmbH

angefordert werden.

Vorbehalt: Technische Änderungen behalten wir uns vor. Änderungen, Irr-

tümer und Druckfehler begründen keinen Anspruch auf Schadensersatz.

Für Datenverluste oder andere Schäden gleich welcher Art, die durch den

unsachgemäßen Gebrauch des Mobiltelefons entstanden sind, übernimmt

die i.safe MOBILE GmbH keine Haung.

Ex-Speziﬁkaonen

Das Mobiltelefon CHALLENGER 2.0 ist geeignet für den industriellen Einsatz

in explosionsgefährdeten Bereichen der Zone 2 nach Richtlinien 94/9/EG

(ATEX 95) und 99/92/EG (ATEX 137) und dem IECEx-System.

Ex-Kennzeichnungen

ATEX II 3G Ex ic IIC T4 Gc

EPS 14 ATEX 1 662 X

2004

Temperaturbereich: -20 ... +60°C

Hersteller: i.safe MOBILE GmbH

i_PARK TAUBERFRANKEN 10

97922 Lauda-Koenigshofen

Germany

Altri manuali per CHALLENGER 2.0

Indice

Lingue:

Altri manuali ISAFE MOBILE Telefono cellulare

ISAFE MOBILE

ISAFE MOBILE M655A01 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS530.1 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS655.RG Manuale dell'operatore

ISAFE MOBILE

ISAFE MOBILE IS310.2 Manuale dell'operatore

ISAFE MOBILE

ISAFE MOBILE M53A01 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE RG930EX Manuale elenco delle parti

ISAFE MOBILE

ISAFE MOBILE IS725.2 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS740.2 Manuale dell'operatore

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS320.1 Manuale dell'operatore

ISAFE MOBILE

ISAFE MOBILE IS330.1 Manuale dell'operatore

ISAFE MOBILE

ISAFE MOBILE IS760.2 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE EXECUTIVE 1.0 Manuale dell'operatore

ISAFE MOBILE

ISAFE MOBILE innovation 2.0 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE innovation 2.0 Manuale dell'operatore

ISAFE MOBILE

ISAFE MOBILE IS530.RG Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS330.2 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS310.2 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS330.RG Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE EXECUTIVE 2.0 Manuale dell'operatore

ISAFE MOBILE

ISAFE MOBILE IS730.2 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS330.1 Manuale di istruzioni

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

LG Thrive Manuale utente
