How do I avoid the humming noise in my headset when using

an Avaya 1400/9400/9500 series desk phone?

Jabra Pro 925 Dual Connectivity

When a Jabra wireless headset with a desk phone interface – such as the

Jabra Pro 920, Jabra Pro 9450, or Jabra Motion Office – is connected to the

headset port on an Avaya 1400/9400/9500 series desk phone, a humming

noise may occur when the headset is in use. The level of humming noise

may vary, depending on the speaker volume that is set on the desk phone

and on the Jabra wireless headset.

To avoid the humming noise, there are alternative ways to connect a Jabra

wireless headset to an Avaya 1400/9400/9500 series desk phone by using

the handset port.

Basic audio connection using the Avaya handset port

Follow these steps to connect*:

1. Remove the Avaya handset cable from the handset port on the desk

phone.

2. Connect the Avaya handset cable to the handset port on the Jabra base.

3. Connect the Jabra phone cable supplied between the Jabra base line

port and the handset port of the Avaya desk phone.

05/04/2021 09:27

https://www.jabra.co.nz/supportpages/jabra-pro-925/925-15-508-203/faq/73b24ef0-09d8-

4159-85be-93b2bc887a1a

Page 1 of 4

How to answer/end calls*:

Answer: While wearing the headset, lift the handset of the desk phone

and set it down next to the desk phone during a call.

End: Place the handset back on the dedicated handset area on the desk

phone.

*Ensure the Jabra base setting Open desk phone line when undocked is set

to “on”. This will ensure an active link between the headset and the base

when lifting the handset off the desk phone, at any given time. If you

undock the headset and discover that the link has become inactive, press

the Multifunction (answer/end) button on the headset or base (product

dependent) to reactivate the link between the base and headset.

Remote call control using the Jabra GN1000 remote handset lifter and

the Avaya handset port

Follow these steps to connect*:

1. Remove the Avaya handset cable from the handset port on the desk

phone.

2. Connect the Avaya handset cable to the handset port on the Jabra base.

3. Connect the Jabra phone cable supplied between the Jabra base line

port and the handset port of the Avaya desk phone.

05/04/2021 09:27

https://www.jabra.co.nz/supportpages/jabra-pro-925/925-15-508-203/faq/73b24ef0-09d8-

4159-85be-93b2bc887a1a

Page 2 of 4

4. Mount the Jabra GN1000 underneath the Avaya handset in accordance

with the Jabra GN1000 setup guide.

5. Connect* the Jabra GN1000 cable to the AUX port on the Jabra base.

How to answer/end calls*:

Answer: Undock the headset from the base. Alternatively, while wearing

the headset press the Multifunction (answer/end) button on the

headset or on the base (product dependent).

End: Dock the headset in the base. Alternatively, press the

Multifunction (answer/end) button on the headset or on the base

(product dependent).

*Ensure the Jabra base setting Electronic hook lifter shows Jabra GN1000

as the selected solution for remote call control. You can find more details

05/04/2021 09:27

https://www.jabra.co.nz/supportpages/jabra-pro-925/925-15-508-203/faq/73b24ef0-09d8-

4159-85be-93b2bc887a1a

Page 3 of 4

in the user manual for the specific Jabra headset. Go to Jabra Support to

search for and find the relevant user manual for your product.
