Jabra Pro 930 Mono Manuale utente

jabra.com/pro930

NEED MORE HELP?

For all support go to jabra.com/support

81-03324 I

Jabra

PRO 930

Quick start guide

Jabra

PRO 930

of GN Audio A/S.

MADE IN CHINA

MODEL: WHB003BS/ WHB003HS

www.jabra.com

LANGUAGES

ENGLISH / EN 2

FRANÇAIS / FR 8

DEUTSCH / DE 14

ESPAÑOL / ES 20

繁體中文 / CHT 26

Optional accessories

PACKAGE CONTENTS

Speaker

Noise-cancelling

microphone

Speaker volume down

Speaker volume up

Mute

Microphone boom arm

Multi-function buttton

LED indicator

JABRA PRO 930 HEADSET

JABRA PRO 930 BASE

Mute indicator Audio link

indicator

Battery indicator

Power adapter port

USB port

Speaker

Foldable base

stand

Icon Event

Battery charging (slow ash)

Full battery

Medium battery

Low battery

Very low battery (fast ash)

Sleep mode (slow ash)

Unknown battery status

Microphone muted

Active audio link between

headset and base

Searching for headset

SETUP

STEP 1: ATTACH THE HEADBAND

1. Align the headset and the headband wearing-style attachment, as illustrated, and press firmly together until

they click into place (snap-to-click).

2. Rotate the microphone boom arm for left or right ear use.

3. Adjust the length of the headband to fit snug against the head.

CLICK

OPTIONAL ACCESSORIES

Attaching the earhook (not supplied in all regions)

1. Assemble the earhook wearing-style attachment for left or right ear use. If necessary, remove the earbud

and replace with another size for best t.

2. Align the headset and the earhook wearing-style attachment, as illustrated, and press firmly together until

they click into place (snap-to-click).

3. Shape the earhook to t snug around the ear.

CLICK

STEP 2: UNFOLD THE BASE

The Jabra PRO base stand can be

folded into three positions: open,

closed, and standing position.

CLICK

STEP 3: CONNECT TO PC

1. Plug the supplied USB cable into the

port marked on the base.

2. Connect the USB cable to any free

USB slot on the PC.

3. Install Jabra Direct software from

www.jabra.com/direct

STEP 4: CONNECT TO POWER

1. Plug the supplied power adapter

into the port marked on the

base.

2. Connect the power adapter to the

mains power socket.

STEP 5: DOCK THE HEADSET

Dock the headset. When docked

correctly the headset battery will begin

charging, if needed.

Charge for 20 minutes or until the

battery indicator on the base is

steady green.

IMPORTANT

Set the Jabra PRO 930 as speaker and microphone in the softphone audio settings.

YOU HAVE NOW SUCCESSFULLY CONNECTED YOUR JABRA PRO 930

DID YOU KNOW?

The Jabra PRO 930 has advanced settings that you can quickly and easily congure yourself. Refer to section 7.6 in

the User Manual to learn how.
