Jabra Storm Scheda tecnica

81-03924 C

GET STARTED IN UNDER

NEED MORE HELP?

For all support go to jabra.com/support

jabra.com/storm

QUICK START

DOWNLOADS

CONTACT SUPPORTTROUBLESHOOTING

FAQ

VIDEOS

1-2-3

jabra.com/storm

JABRA STORMTM

GET STARTED IN UNDER

MINUTES

MADE IN CHINA

MODEL: BTE7

GN Netcom. All other trademarks included herein are the property of their

respective owners. The Bluetooth®word mark and logos are owned by

the Bluetooth SIG, Inc. and any use of such marks by GN Netcom is under

license. (Design and specifications subject to change without notice).

外

箱・中箱外箱・袋

ENGLISH..........................................1

简体中文.........................................5

繁體中文.........................................9

日本語 ............................................13

ภาษาไทย.......................................17

BAHASA MALAYSIA ..................21

한국어............................................25

1 HOW TO CONNECT

CONNECT TO MOBILE DEVICE

1. Turn the headset on (set the On/o switch to

the On position).

2. Press and hold (3secs) the Answer/end

button until the Bluetooth indicator ashes

blue. Pairing mode will be announced in the

headset.

3. Wear the headset and follow the voice-guided

pairing instructions to pair to your Bluetooth

device.

CONNECT TO MOBILE DEVICE (USINGNFC)

1. Ensure that NFC is enabled on your mobile

device.

2. Slowly slide the NFC zone of the headset

against the NFC zone of the mobile device

until a connection is conrmed.

ENGLISH

2 HOW TO WEAR

The headset can be worn on the left or right ear. Simple rotate the

speaker and twist the eargel to t your ear.

CHARGE THE HEADSET

Pull open the charging cover to expose the USB charging port.

It takes approx. 2hours to fully charge the battery.

Battery

indicator

Bluetooth

indicator Answer/end

button

USB charging

port

On/o

switch

Volume up

Volume down

3 HOW TO USE

On/o Slide the On/o switch

Answer call Tap the Answer/end button, or say ‘Yes’

(when voice commands enabled)

End call Tap the Answer/end button

Reject call

Double-tap the Answer/end button,

or say ‘No’(when voice commands

enabled)

Redial last number Double-tap the Answer/end button

when not on a call

Activate Siri®,

Google Now™,

Cortana (phone

dependent)

Press and hold (1 sec) the Answer/end

button (when not on a call)

Speaker volume Tap the Volume up/down buttons

Mute/unmute Tap both the Volume up and Volume

down buttons at the same time

Enable/disable

voice commands

Press and hold (1 sec) both the Volume

down and the Answer/end button at

the same time, not on a call

1 如何连接

连接到移动设备

1.打开耳机（将开启/关闭开关设定为开

启位置）。

2.按住接听/挂断按钮 3 秒钟直到蓝牙指示灯闪

烁蓝光。耳机中将会响起进入配对模式的语

音提示。

3.戴上耳机，按照语音配对说明与您的蓝牙设

备配对。

连接到移动设备（通过 NFC 近场通信功能）

1.确定移动设备上的 NFC 近场通信功能已开

启。

2.正对着移动设备上的 NFC 近场通信感应区慢

慢滑动耳机上的 NFC 近场通信感应区，直到

确认已建立连接。

简体中文

2 如何佩戴

可以将耳机戴在左耳上，也可以戴在右耳上。只需旋转扬声器并扭

转耳塞以贴合您的耳朵。
