TempStar™ HH
Models
TempStar™ HH
Door Type
Project
Item
Quantity
CSI Section 11400
Approval
Date
Highway 25E
P. O. Box 1060
Barbourville, KY 40906
Tel: 606-523-9795
Tel: 1-888-800-5672
Fax: 606-523-9196
E-mail: [email protected]om
www.jacksonmsc.com
07610-002-66-60B (09/07)
Mandatory Specs
Specify voltage
Specify booster size
Specify electric or steam
Optional Features
Optional 70˚F (21˚C ) rise
booster heater is available
with no additional cost
(must be specified)
Drain quench system
Scaltrol
Flanged feet
Water hammer arrestor
Standard Features
Accessories
36” (914 mm) compartment
rack 4 1/6” (4 mm) tall
36” (914 mm) compartment
rack 5 5/8” (16 mm) tall
36” (914 mm) compartment
rack 7” (178 mm) tall
Combination rack
Peg rack
Sheet pan rack (18” X 26”
/ 457 mm X 660 mm baking
pans)
Uses 1.36 gallons (5 liters) of 180˚F
(82˚C) w a t e r p e r r a c k
T o t a l a u t o m a t i c ( n o r m a l ) c y c l e - 6 2
seconds
5 3 r a c k s p e r h o u r n o r m a l c y c l e
2 H P W a s h P u m p M o t o r
Single Point connections for all utilities
B u i l t - i n w a t e r p r e s s u r e r e g u l a t o r a n d
gauge
Field convertible from straight through
t o c o r n e r o p e r a t i o n s
Heavy duty stainless steel construction
Specifications
Sani-Sure™ feature assures proper rinse
water temperature
Multi-cycle timer (Extra Heavy, Heavy,
Medium, Normal)
Extended 15 sec. high-temperature rinse
provides superior coverage and rapid
drying
20 3/4” (527 mm) wide X 27” (686 mm)
high opening accommodates 18” (457)
X 26” (660 mm) sheet pans and 60 quart
mixing bowls
Auto-fill / auto-start
Safety door switch
Delime/manual wash switch
Low watt density electric wash tank
heater
Hi-limit thermostat and low water pro-
tection
Adjustable bullet feet
Uses standard 20” X 20” (508 mm X 508
mm) racks
Front dress panel
Detergent/rinse additive signal connec-
tion fuse box
Built-in 40˚F (60˚C) booster heater is
standard; 70˚F (21˚C) booster is avail-
able. Must be specified at time of order.
Lower counter-rotating wash arms and
upper wash arm provide optimum spray
coverage and superior cleaning action
Self-draining stainless steel pump
Split-door design accommodates instal-
lations with low ceiling heights
Large scrap tray
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
We reserve the right to change specications appearing in this bulletin without incurring any obligation for equipment previously or subsequently sold.
Highway 25E
P. O. Box 1060
Barbourville, KY 40906
Tel: 606-523-9795
Tel: 1-888-800-5672
Fax: 606-523-9196
E-mail: [email protected]om
www.jacksonmsc.com
07610-002-66-60B (09/07)
OPERATING CAPACITY
Racks per Hour Normal
53
Medium
28
Heavy
19
Extra Heavy
11
OPERATING CYCLE (sec) Wash Rinse Dwell Total Cycle
Normal 45 15 2 62
Medium 103 15 2 120
Heavy 163 15 2 180
Extra Heavy 283 15 2 300
OPERATING TEMPERATURES
Wash (Minimum) 150˚F / (66˚C)
Rinse (Minimum) 180˚F / (82˚C)
MODEL NO.
SIZE DRAIN
HEIGHT
SHIPPING INFO DIMENSIONS
HEIGHT WIDTH DEPTH WEIGHT CLASS CUBE HEIGHT WIDTH DEPTH
TempStar™HH 76-3/4”
(1949 mm)
25-1/4”
(641 mm)
25-1/4”
(641 mm)
11-3/4”
(298 mm)
420 lbs
(191 kg)
92.5 71.4
cu. ft.
85”
(2159 mm)
44”
(1118 mm)
33”
(838 mm)
DIMENSIONS--STANDARD MODEL
How To Specify - TempStar™ HH
STEAM REQUIREMENTS
Steam Flow Pressure (PSIG) 15-20
Consumption @ 15 PSIG (lbs/hr) 45
WATER REQUIREMENTS
Inlet Tempterature
40˚F / (4˚C) Rise 140˚F / (82˚C)
70˚F / (21˚C) Rise 110˚F / (60˚C)
Gallons per hour 72.1 / 273 Ltr.
Gallons per rack 1.36 / 5 Ltr
Waterline Size IPS (Minimum-inches) 3/4
Drainline Size IPS (Minimum-Inches) 1-1/2
Waterline Flow Rate (GPM) 5.44
Flow Pressure (PSI) 15-25
Tank Capacity 3 gals / (11 ltrs)
Wash Tank 8 Gal. / (30 ltr)
Booster Tank 3 Gal. / (11 ltr)
APPROXIMATE LOAD AMPS
40˚F (4˚C) Rise 70˚F (21˚C) Rise
Power Supply AMPS AMPS
208V/60HZ/1PH 74.2 81.4
208V/60HZ/3PH 47.6 51.8
230V/60HZ/1PH 80.9 89.0
230V/60HZ/3PH 51.4 56.2
460V/60HZ/3PH 23.4 25.8
DIMENSION REQUIREMENTS
Minimum Ceiling Height (Recommended) 88” / (2 meters)
Wall Clearance (Minimum) 4” / (102 mm)
Standard Table Height 34” / (864 mm)
Inside Clearance 17-1/4” / (438 mm)
34 [861mm]
731
4[1863mm]
25 [637mm]
863
4[2202mm] B
17 [432mm]
C
73 [1856mm]
27 [687mm]
LEGEND
A - DRAIN 1 1/2" IPS
B - WATER INLET 3/4" IPS
C - ELECTRICAL CONNECTION
All vertical dimensions are +/- 1/2" due to
adjustable bullet feet.
A
251
4[639mm]
B
1 [27mm]
3 [79mm]
C
151
4[387mm]
113
4[298mm]
A
3 [76mm]
4 [101mm]
4 [102mm]
B
WASH PUMP MOTOR
Wash Pump Motor Horsepower 2 HP
Volts KW
Electric Wash Tank Heater 208V 4.1
230V 5.0
460V 5.0
Electric Rinse Tank Heater 40˚F (4˚C) Rise 208V 9.0
230V 11.0
460V 11.0
70˚F (21˚C) Rise 208V 10.5
230V 12.9
460V 12.9
