Jacuzzi AMIGA PLUS Manuale utente

The AMIGAPLUS

WhirlpoolBath

PARTSCATALOG

MODEL#N888000

MODEL#N890000

ISSUEDATE:9/99

CATALOG #R340000

Guillen's Enterprises, inc

jacuzziparts.com

800-222-7855

www.guillens.com - (800) 222-7855

CONTENTS

DISCHARGEPLUMBING

SUCTIONPLUMBING

AIRLINEPIPING

See GeneralBathPartsCatalog forinformation on thefollowing:

J-Pump/MotorAssembly

3-PositionControlPanel

HTCJet

BMHJet

SuctionFitting

10 Amp115 Volt

J-Pump/MotorAssembly

SerialNumber/ProductSpecificationPlate

SuctionPlumbing

DischargePlumbing

AirLinePiping

3-PositionControlPanel

BMHJets(4)

SuctionCover

HTCJets(3)HTCJet

Guillen's Enterprises, inc

jacuzziparts.com

800-222-7855

www.guillens.com - (800) 222-7855

DISCHARGEPLUMBING

AMIGAPLUSMODEL#N880000

MODEL#N890000

ISSUEDATE:9/99

ITEMP/NDESCRIPTIONQTY

*See GeneralBathPartsCatalog

9250000

9231000

2949000

0167000

0157000

D189000

7298000

0239000

RepairKit,UnionAdapter

O-Ring,Union

Tee,Rdcng,11/2”x11/2”x2”

Tee,11/2”,SxSxS

Ell,45,11/2”,SxS

Tee,Rdcng,11/2”x11/2”x3/4”

Ell,90,3/4”Street

Ell,90,11/2”SxS

*ToHTC

Jet

11/2”x2.50”L.

*ToBMH

Jet

*ToBMH

Jet

*ToBMH

Jet

*ToBMH

Jet

*ToHTC

Jet

*ToHTC

Jet

11/2”Flex

x8.00”L.

11/2”Flex

x26.50”L.

11/2”Flex

x16.75”L.

11/2”Flex

x20.25”L.

11/2”Flex

x20.25”L.

11/2”Flex

x16.75”L.

11/2”Flex

x28.00”L.

*ToPump

Discharge

Guillen's Enterprises, inc

jacuzziparts.com

800-222-7855

www.guillens.com - (800) 222-7855

SUCTIONPLUMBING

AMIGAPLUSMODEL#N880000

MODEL#N890000

ISSUEDATE:9/99

*See GeneralBathPartsCatalog

ToPumpSuction

*ToSuction

Fitting

2”x24.00”L.

2”Flex

x6.00”L.

ITEMP/NDESCRIPTIONQTY

9250000

9231000

0426000

0851000

B072000

B071000

RepairKit,UnionAdapter

O-Ring,Union

Ell,90,2”SxS

Coupling,2”SxS

Ell,DrainDown,RH

Ell,DrainDown,LH

NOTE:P/NB071000 isusedonRHunits.P/NB072000 is

usedonLHunits.

Guillen's Enterprises, inc

jacuzziparts.com

800-222-7855

www.guillens.com - (800) 222-7855

AIRLINEPIPING

AMIGAPLUSMODEL#N880000

MODEL#N890000

ISSUEDATE:9/99

*See GeneralBathPartsCatalog

ITEMP/NDESCRIPTIONQTY

0647000

0455000

7164000

C279000

B777000

Coupling,1/2”SxS

Tee,1/2”SxSxS

Ell,90,1/2”Street

Adapter,1/2”SxSPGT

Plug,1/2”SPIG

*ToHTC

Jet

*ToHTC

Jet

*ToHTC

Jet

*To3-Position

ControlPanel

*ToBMHJet

1/2”Flex

x8.25”L.

1/2”Flex

x7.50”L.

1/2”Flex

x21.00”L.

1/2”x2.50”L.

1/2”x3.50”L.

1/2”Flex

x8.50”L.

1/2”Flex

x24.00”L.

1/2”Flex

x33.00”L.

1/2”x2.50”L.

1/2”Flex

x18.25”L.

1/2”Flex

x9.25”L.

1/2”Flex

x9.50”L.

Guillen's Enterprises, inc

jacuzziparts.com

800-222-7855

www.guillens.com - (800) 222-7855

PRODUCTSPECIFICATIONSARESUBJECTTOCHANGEWITHOUTNOTICE.

JacuzziWhirlpoolBathhasobtainedapplicablecode(standards)listingsgenerallyavailableonanational

basisforproductsofthistype.Itistheresponsibilityoftheinstaller/ownertodeterminespecificlocalcode

compliance priortoinstallationoftheproduct.JacuzziWhirlpoolBathmakesnorepresentationorwarranty

regarding,andwill notberesponsibleforanycodecompliance.

JACUZZIWHIRLPOOLBATH

JacuzziWhirlpoolBathNationalHeadquarters

P.O.DrawerJ,WalnutCreek,CA94596 (925)938-7070

ServiceSupport:(800)288-4002

1999 JacuzziWhirlpoolBathR340000 9/99
