Bellavista™6

SALON®SPA BATH

MODEL NUMBER:

DY75

EXTERIOR DIMENSIONS:

72" long x 42" wide

x 26" high

INTERIOR DIMENSIONS:

43½" long x 23½" wide

# OF JETS/TYPE OF JETS:

4 PowerPro®Jets

4 AccuPro™ Neck Jets

2 AccuPro™ Foot Jets

OPERATING GALLONS:

87 gallons

In Italy, it means beautiful view. To you, a wonderful place to regain relaxed,

revitalized perspective.

FEATURES:

• Multi-speed motor

• 4 fully adjustable PowerPro® jets

• 4 AccuPro™ spinning neck jets

• 2 directionally adjustable AccuPro™ foot jets

• 900 watt variable speed heated air blower

• Bottom air channels for maximum massage

• Chromatherapy™ lighting system capable of 256 colors

• All-in-one electronic control panel

• Drain-assist purge system

• RapidHeat™ inline heater

• PrO3

™ Cleansing System

Bellavista™6 |SALON®SPA BATH

Detail:

The Bellavista™ whirlpool bath’s perfectly placed PowerPro®and AccuPro™ jets work in

concert with a deeply contoured backrest to offer the ultimate in hydrotherapy.

Bellavista™6

SALON® SPA BATH

Technical Speciﬁcations

DIMENSIONS

72” L x 42” W x 26” H

(1524 mm) L x (1067 mm) W x (660 mm) H

DRAIN/OVERFLOW

A: 20” (508 mm) B: 11-3/4” (298 mm)

CUTOUT

Template Provided P/N P187000

TOTAL WEIGHT

1231 lb (558 kg) / 59 lb/sq. ft. (288 kg/m2)

OPERATING GALLONAGE

87 U.S. Gal. (329 Liters)

PRODUCT WEIGHT

180 lb (82 kg)

SKIRT MOUNTING

Not Available

ELECTRICAL SPECIFICATIONS

Requires a dedicated GFCI protected separate circuit.

Blower: 120VAC, 20AMP, 60 Hz.

Motor/Pump and RapidHeat™: 240VAC, 20AMP, 60 Hz.

HEATER (STANDARD)

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N BN60000

INSTALLATION NOTES

Refer to installation instructions included with ﬁxture before

beginning installation. Please conﬁrm product availability and

speciﬁcations before commencing with any installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT

TO CHANGE WITHOUT NOTICE.

#FR19000 10/07

DY75

Bellavista

™

6 Salon® Spa, Right Hand

• Center Drain Location

• Accessories / Hardware:

PowerPro™ Jet Rings Kit: #M952

3 x AccuPro™ Neck Jet Rings Kit: #P556

Rotary Drain Kit, 30” Cable: #K606

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(849) – Oil Rubbed Bronze

4" x 4"*

42"

72"

10-1/2" 35-13/16"

11-3/4"

30-1/8"

Motor

12" H x 24" L

Service Access

Heater

Blower

END VIEW

SIDE VIEW

2" (Heater)

(Motor)

(51 mm)

(Blower)

72" 42"

26"

DRAIN/OVERFLOW

Product Shown: Bellavista™ 6 Salon™ Spa

Right Hand Shown, Model: DY75

* Measurements inside unit represent cutout in

ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
