Jensen VM9725BT Manuale utente

VM9725BT

Operating Instructions

160

watts peak

40W x 4

VM9725BT

Thank you for choosing a Jensen product. We hope you will nd the instructions

in this owner’s manual clear and easy to follow. If you take a few minutes to look

through it, you’ll learn how to use all the features of your new Jensen VM9725BT

Mobile Multimedia Receiver for maximum enjoyment.

CONTENTS

Features..................................................................................................................3

Controls and Indicators.........................................................................................6

Remote Control......................................................................................................8

Operating Instructions........................................................................................14

Steering Wheel Controls .....................................................................................22

Settings Menu......................................................................................................23

Tuner Operation ..................................................................................................31

DVD/VCD Video Operation .................................................................................37

DVD/CD Audio Operation ...................................................................................43

MP3/WMA Operation ..........................................................................................47

iPod®/iPhone® Operation....................................................................................53

Pandora Operation..............................................................................................57

Bluetooth Operation ...........................................................................................61

SiriusXM® Radio Operation.................................................................................70

Rear Camera Operation.......................................................................................80

Troubleshooting ..................................................................................................81

Care and Maintenance ........................................................................................85

Specications.......................................................................................................86

Common Replacement Parts ..............................................................................87

VM9725BT

FEATURES

Congratulations on your purchase of the Jensen VM9725BT Mobile Multimedia

Receiver. It’s a good idea to read all of the instructions before beginning the

installation. We recommend having your Jensen VM9725BT installed by a reputable

installation shop.

DVD

• Fast Forward/Reverse - 2X, 4X, 8X, and 20X

• Slow Motion Forward/Reverse - 1/2, 1/4, 1/6, and 1/8

• Play, Pause, Stop, Next Chapter, and Previous Chapter

CD / MP3 / WMA

• CD-Text Compatible

• ID3 Tag Compatible

• Directory Search (MP3 / WMA Only)

• Burn up to 1500 MP3 and WMA Files onto a DVD+R / RW

• Audible Forward / Reverse Track Search (CD-DA Only)

• Random, Repeat and Intro

• Play, Pause, Stop, Next Track, and Previous Track

AM-FM

• USA / Europe / Latin America / Asia Frequency Spacing

• 30 Station Presets (18 FM / 12 AM)

• Auto Stereo / Mono

• Local / Distance

• Auto Store / Preview Scan

iPod®/iPhone®

• iPod®/ iPhone® via USB

• High Speed Direct Connect Interface to Access iPod® Playlists, Artists, Albums

and Songs. Play music and view video/photo* les from your iPod®. *Video/photo

playback requires jLink-USB iPod® interface cable (sold separately).

• Power Management Charges iPod® while Connected

SiriusXM® Ready

• Satellite Channel Name, Artist, Song and Categories Displayed on Monitor

VM9725BT

Chassis

• 2.0 DIN (Import / ISO-DIN Mountable)

• Fixed Front Panel

• 6.2” High Denition TFT LCD

• 1,152,000 Sub Pixels (800 x 3 X 480)

• Beep Tone Conrmation (ON-OFF Option)

• Heat Management System - Forced-Air Cooling To Keep The Chip-Sets Operating

at Nominal Temperatures

General

• Built-In Bluetooth® with external microphone, providing Hands-Free operation

for safety and convenience and A2DP for streaming music from your

smartphone or other Bluetooth® device.

• One Composite Video Output for Additional Screens

• Front Panel Audio/Video Input

• Three-Band Tone control (Bass, Mid and Treble) with Eight Preset EQ Curves

• Front Panel A/V Aux Input for Portable Media Devices

• Rear Subwoofer Line Output

• Programmable Volume Control

• Rear Camera Input (Normal and Mirror Image View)

• Touch Screen Calibration Mode

• 4VRMS Line Output - All Channels

• Rotary Encoder Audio Control

• Front / Rear / Sub Line Output

• Rear USB Input

Navigation

• TTS Voice Guidance – Street Names Announced

• English, French and Spanish TTS Voice

• Tele Atlas Map Data

• 11 Million Points of Interest

• 4GB SD Card with Continental US, Alaska, Hawaii, and Puerto Rico

• Latest Map Guarantee (Limited time only - Must be used within 90 days of

initial activation)

Rear Camera

The VM9725BT is “camera ready.” Before accessing any camera features, you must

purchase and install a rear video camera. Once the camera is connected and

operating properly, the CAMERA source mode will become active. While the

camera is not installed, the CAMERA option appears gray, indicating the function

is not available.

VM9725BT

WARNING! Never install this unit where operation and viewing could interfere

with safe driving conditions.

WARNING! To reduce the risk of a trac accident (except when using for rear

view video camera) never use the video display function while driving the

vehicle. This is a violation of federal law.

WARNING! Never disassemble or adjust the unit.

WARNING! To prevent injury from shock or re, never expose this unit to

moisture or water.

WARNING! Never use irregular discs.

VM9725BT

CONTROLS AND INDICATORS

NAV

SRC

EJECT

OPEN

VM9725BT

1. Disc Slot

2. EJECT Button

Press to eject a disc.

3. SRC Button

Press to switch between the available audio/video sources applied to the unit.

4. NAV Button

Press to toggle back and forth between the navigation and currently selected

source.

5. Internal Microphone

Internal microphone for Bluetooth calls.

6. Reset Button

Press to reset system settings to factory default (except password and parental

lock settings).

7. Rotary Encoder / Power On/O ( ) Button

Rotate to adjust the volume. Press momentarily to activate the MUTE function.

Press again to resume normal listening.

Press to turn the unit ON. Press and hold to turn the unit OFF.

8. Remote Sensor

9. USB/SD/AV Interface Connector Cover

10. USB Interface Connector

Connect a USB device for playback of music/video les.

11. SD Interface Connector

Insert an SD card for playback of music/video les.

12. A/V Input

Accepts a 3.5mm jack through which signals from various audio/video devices

can be applied to the unit.

13. TFT Display

14. Map Cover

Covers the Mini SD card slot. The Mini SD card is used for the Navigation Map

only, not for music or other les. This may be used for rmware updates if

required.

VM9725BT

REMOTE CONTROL

See Table 1 for remote control functions.

MUSIC PHOTO VIDEO

iPod

SCN

MIX

VM9725BT

Table 1: Remote Control Functions

Button Function

Name # DVD VCD TUNER CD/MP3/

USB

iPod

EQ 1 Accesses

equalizer

menu.

Accesses

equalizer

menu.

Accesses

equalizer

menu.

Accesses

equalizer

menu.

Accesses

equalizer

menu.

POWER

( ())

2 Turns the

power on/

o.

Turns the

power on/

o.

Turns the

power on/

o.

Turns the

power on/

o.

Turns the

power

on/o.

PHOTO/

SUBTITLE

3 Language

selection

for

subtitle.

Selects


mode.

VIDEO/

ANGLE

4 Plays back

disc in

dierent

angle for a

scene.

Plays back


CD with

dierent

angle of


displayed.

Selects

Video

mode.

MENU 5 Enters

the main

menu of

the disc.

Turns on/o

PBC when

playing

VCD.

Selects


mode.

TITLE 6 Enters the

title menu

of the disc.

Plays the

rst ten

seconds

of each

chapter/

title.

Selects

Music

mode.

CLEAR 7 Delete

entry or

move

backwards

to correct

error in

Direct

Access

mode.

Delete entry

or move

backwards to

correct error

in Direct

Access mode.

Delete entry

or move

backwards

to correct

error in

Direct

Access

mode.

Delete

entry or

move

backwards

to correct

error in

Direct

Access

mode.

Delete

entry or

move

backwards

to correct

error in

Direct

Access

mode.

VM9725BT

Table 1: Remote Control Functions

Button Function

Name # DVD VCD TUNER CD/MP3/

USB

iPod

9 Selects the

chapter for

playback.

Selects the

chapter for

playback.

Searches

for an

available

radio

station by

decreasing

tuning

frequency.

Selects the

track for

playback.

Pauses

playback/

starts

playback.

10 Selects

the next

chapter for

playback.

Selects

the next

chapter for

playback.

Searches

available

radio

station by

increasing

the tuning

frequency.

Selects

the next

track for

playback.

Selects

the next

track for

playback.

PIC 11 Displays

set-up

parameters.

Displays

set-up

parameters.

VOL + 12 Increases

volume.

Increases

volume.

Increases

volume.

Increases

volume.

Increases

volume.

13 Fast

forwards

the disc

content.

Fast

forwards

the disc

content.

Fast

forwards

the disc

content.

Accesses

iPod

Menu..

VOL - 14 Decreases

volume.

Decreases

volume.

Decreases

volume.

Decreases

volume.

Decreases

volume.

15 Stops

playback.

Stops

playback.

Stops

playback.

Altri manuali per VM9725BT

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Jensen Sistema video per auto

Jensen

Jensen CAR110W Istruzioni operative

Jensen

Jensen VM9424 Manuale utente

Jensen

Jensen JRV4100 Istruzioni per l'installazione

Jensen

Jensen VX6628 Manuale utente

Jensen

Jensen CR271ML Istruzioni operative

Jensen

Jensen JE1569FDM Manuale utente

Jensen

Jensen VM9224BT Manuale utente

Jensen

Jensen VM9115 Manuale utente

Jensen

Jensen JMV111 - DVD Player With LCD Monitor Manuale utente

Jensen

Jensen VM9512HD Manuale utente

Jensen

Jensen VM9212 Manuale utente

Jensen

Jensen MS4200RS - Navigation System With CD Player Manuale utente

Jensen

Jensen CDR462 Manuale utente

Jensen

Jensen VM9212N - Multimedia CD/DVD Receiver Manuale utente

Jensen

Jensen VM9022HDN - Touch Screen Double Din MultiMedia... Manuale utente

Jensen

Jensen VX7021 Manuale utente

Jensen

Jensen CAR710X-BC Istruzioni operative

Jensen

Jensen VM9022HDN - Touch Screen Double Din MultiMedia... Manuale utente

Jensen

Jensen CMM720 Istruzioni operative

Jensen

Jensen VX4024 Manuale utente

Jensen

Jensen VX7023 Manuale utente

Jensen

Jensen Mobile Multimedia AM/FM/DVD Receiver VM9410 Manuale utente

Jensen

Jensen VM9114 Manuale utente

Jensen

Jensen CDR5620 Istruzioni operative

Manuali Sistema video per auto popolari di altre marche

Stinger

Stinger HEIGH10 RB10RAM13B Manuale utente

Eonon

Eonon E1057 Manuale utente

Milion

Milion D2223 Manuale utente

Metra Electronics

Metra Electronics 99-8153 Manuale utente

Voxx Electronics

Voxx Electronics HR8MA1 Manuale utente

Axxera

Axxera AV604Bi Manuale utente

Clarion

Clarion NX706E Manuale utente

Pyle view

Pyle view PLDN74BTi Manuale utente

Clarion

Clarion NX602 Manuale utente

PowerAcoustik

PowerAcoustik PTID-5850N Manuale utente

RCA

RCA DRC6296 - Twin 9" Mobile DVD System Guida utente

Lanzar

Lanzar SVDVD5 Manuale utente

Kia

Kia MTXM100YPPE Manuale utente

Eonon

Eonon E1060 Manuale utente

Macrom

Macrom M-AN900 Manuale utente

Hyundai

Hyundai BAPE-L3000N Manuale utente

r.LiNK

r.LiNK RL2-UCON8-SM Manuale utente

Blaupunkt

Blaupunkt DVP 01C Manuale utente
