JET TURNING
Bench Lathes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Geared Head Engine Lathes . . . . . . . . . . . . . . . . . . . . . . 42
Large Spindle Bore Lathes . . . . . . . . . . . . . . . . . . . . . . . 44
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
DRO’s for Lathes
ANILAM®, ACU-RITE®, AND NEWALL® . . . . . . . . . . . . . 50
34
JET TURNING
jettools.com
jettools.com
TURNING
35
JET TURNING
JET has the most extensive selection of turning machines available and offers
a full range of lathes and accessories. All models are available in a range of sizes.
We offer packages that include taper attachments, collet closers, and digital
readouts to meet the needs of any operation.
TURNING PACKAGES
STOCK NUMBER 321360A 321357A 321810 321820 321830
Model Number BDB-1340A GHB-1340A GH-1340W-1 GH-1340W-3 GH-1440W-1
Swing Over Bed (in.) 13 13 13 13 14
Swing Over Cross Slide (in.) 7-25/32 7-25/32 7-1/2 7-1/2 8-1/2
Swing Through Gap (in.) 18-3/4 18-3/4 19 19 20
Length of Gap (in.) 8 8
Distance Between Centers (in.) 40 40 40 40 40
Spindle Bore (in.) 1-3/8 1-3/8 1-1/2 1-1/2 1-1/2
Spindle Mount D1-4 D1-4 D1-4 D1-4 D1-4
Spindle Taper (with sleeve) MT-5 (MT-3) MT-5 (MT-3) MT-5 (MT-3) MT-5 (MT-3) MT-5 (MT-3)
Number of Spindle Speeds 12 8 12 12 12
Range of Spindle Speeds (RPM) 60-1,240 70 - 2,000 40 - 1,800 40 - 1,800 40 - 1,800
Number of Longitudinal and Cross Feeds 40 40 40 40 40
Range of Longitudinal Feeds (in./rev.) .0036 – 0.1005 0.0036 – 0.1005 0.0012 – 0.0294 0.0012 – 0.0294 0.0012 – 0.0294
Range of Cross Feeds (in./rev.) .0012 – .0345 0.0012 – 0.0345 0.0003 – 0.0103 0.0003 – 0.0103 0.0003 – 0.0103
Number of Inch Threads 40 40 40 40 40
Range of Inch Threads (TPI) 4-112 4 - 112 4 - 112 4 - 112 4 - 112
Number of Metric Threads 27 27 22 22 22
Range of Metric Threads (mm) 0.2-6 0.2-6 0.45-7.5 0.45 -7.5 0.45-7.5
Tool Size (max./in.) 5/8 x 5/8 5/8 x 5/8 5/8 x 5/8 5/8 x 5/8 5 5/8 x 5/8
Compound Slide Travel (max./in.) 2-11/16 2-11/16 3-1/2 3-1/2 3-1/2
Cross Slide Travel (max./in.) 6-5/16 6-5/16 6-3/8 6-3/8 6-3/8
Carriage Travel (in.) 35 35 37-1/2 37-1/2 37-1/2
Tailstock Spindle Travel (in.) 3-3/4 3-3/4 4-3/4 4-3/4 4-3/4
Tailstock Taper MT-3 MT-3 MT-3 MT-3 MT-3
Steady Rest Capacity (in.) 2-5/8 2-5/8 3-3/4 3-3/4 3-3/4
Follow Rest Capacity (in.) 2-3/4 2-3/4 2-3/4 2-3/4 2-3/4
Width of Bed (in.) 7-3/8 7-3/8 10-1/2 10-1/2 10-1/2
Overall Dimensions (in./L x W x H) 71 x 32 x 45 71 x 32 x 47 73-3/4 x 29-1/2 x 46-3/4 73-3/4 x29-1/2 x 47-1/2 73-3/4 x29-1/2 x 47-1/2
Motor 2 HP, 1Ph, 230V 2 HP, 1Ph, 230V 3HP, 1Ph, 230V 3HP, 3Ph, 230 /460V 3HP,1Ph, 230V
Prewired 230V
Net Weight (lbs.) 954 1,015 2081 2081 2191
LATHE INCLUDED IN ALL PACKAGE NUMBERS LISTED BELOW
Taper Attachment 321120 321119 321521 321516 321517
Collet Closer 321555 321518
Taper Attachment & Collet Closer
Acu-Rite 100S DRO
Acu-Rite 200S DRO 321121 321122 321532 321459 321549
Acu-Rite 200S 3-Axis DRO
Acu-Rite 200S DRO & Taper Attachment 321123 321550
Acu-Rite 200S DRO & Collet Closer 321526 321548
Acu-Rite 200S DRO, Taper Attachment & Collet Closer 321538 321546
Anilam 311 DRO 321545
Anilam 311 DRO & Collet Closer
Anilam 550 DRO
Anilam 550 DRO, Taper Attachment & Collet Closer
Newall C80 DRO 321130 321131 321132 321133 321134
Newall C80 DRO & Taper Attachment 321143
Newall C80 DRO & Collet Closer 321581 321536
Newall C80 DRO, Taper Attachment & Collet Closer
34
JET TURNING
jettools.com
jettools.com
TURNING
35
JET TURNING
STOCK NUMBER 321840 321910 321920 321930
Model Number GH-1440W-3 GH-1440ZX GH-1460ZX GH-1640ZX
Swing Over Bed (in.) 14 14 14 16
Swing Over Cross Slide (in.) 8-1/2 7-5/8 7-5/8 10
Swing Through Gap (in.) 20 23-5/8 23-5/8 25-7/8
Length of Gap (in.) 12-1/4 12-1/4 12-1/4
Distance Between Centers (in.) 40 40 60 40
Spindle Bore (in.) 1-1/2 3-1/8 3-1/8 3-1/8
Spindle Mount D1-4 D1-8 D1-8 D1-8
Spindle Taper (with sleeve) MT-5 (MT-3) MT-7 (MT-5) MT-7 (MT-5) MT-7 (MT-5)
Number of Spindle Speeds 12 12 12 12
Range of Spindle Speeds (RPM) 40 - 1,800 42 -1,800 42 -1,800 25 -1,800
Number of Longitudinal and Cross Feeds 40 122 122 122
Range of Longitudinal Feeds (in./rev.) 0.0012 – 0.0294 0.0015 – 0.0913 0.0015 – 0.0913 .0015 – .0913
Range of Cross Feeds (in./rev.) 0.0003 – 0.0103 0.0006 – 0.0365 0.0006 – 0.0365 .0006 – .0365
Number of Inch Threads 40 61 61 61
Range of Inch Threads (TPI) 4 - 112 1-5/8 - 72 1-5/8 - 72 1-5/8 - 72
Number of Metric Threads 22 24 24 24
Range of Metric Threads (mm) 0.45-7.5 0.05-20 0.05-20 .05-20
Tool Size (max./in.) 5/8 x 5/8 1 x 1 1 x 1 1 x 1
Compound Slide Travel (max./in.) 3-1/2 5-1/8 5-1/8 5-1/8
Cross Slide Travel (max./in.) 6-3/8 9 9 9
Carriage Travel (in.) 37-1/2 35 55 35
Tailstock Spindle Travel (in.) 4-3/4 5 5 5
Tailstock Taper MT-3 MT-4 MT-4 MT-4
Steady Rest Capacity (in.) 3-3/4 1/2 to 3-1/2 1/2 to 3-1/2 1/2 - 3-1/2
Follow Rest Capacity (in.) 2-3/4 3/8 to 7 3/8 to 7 3/8 - 7
Width of Bed (in.) 10-1/2 13-3/8 3/8 to 7 13-3/8
Overall Dimensions (in./L x W x H) 73-3/4 x29-1/2 x 47-1/2 97-1/2 x 40 x 46-7/8 116-1/2 x 40 x 46-7/8 97-1/2 x 40 x 48
Motor 3HP,3Ph, 230V/460V 7-1/2HP,3Ph, 230/460V 7-1/2HP, 3Ph, 230/460V 7-1/2HP,3Ph, 230/460V
Prewired 230V 230V 230V 230V
Net Weight (lbs.) 2191 5187 5380 5475
LATHE INCLUDED IN ALL PACKAGE NUMBERS LISTED BELOW
Taper Attachment 321522 321467 321480 321474
Collet Closer 321531 321439
Taper Attachment & Collet Closer
Acu-Rite 100S DRO
Acu-Rite 200S DRO 321533 321469 321478 321475
Acu-Rite 200S 3-Axis DRO 321525
Acu-Rite 200S DRO & Taper Attachment 321563 321507 321503 321508
Acu-Rite 200S DRO & Collet Closer 321524 321501 321490 321495
Acu-Rite 200S DRO, Taper Attachment & Collet Closer 321572 321509
Anilam 311 DRO 321540 321523
Anilam 311 DRO & Collet Closer 321542
Anilam 550 DRO 321499
Anilam 550 DRO, Taper Attachment & Collet Closer 321541
Newall C80 DRO 321135 321136 321137 321138
Newall C80 DRO & Taper Attachment 321570 321571
Newall C80 DRO & Collet Closer 321441 321494
Newall C80 DRO, Taper Attachment & Collet Closer
TURNING PACKAGES
36
JET TURNING
TURNING
jettools.com
jettools.com
TURNING
37
JET TURNING
JET® TURNING PACKAGES
STOCK NUMBER 321940 321950 321960 321970
Model Number GH-1660ZX GH-1840ZX GH-1860ZX GH-1880ZX
Swing Over Bed (in.) 16 18 18 18
Swing Over Cross Slide (in.) 10 11 11 11
Swing Through Gap (in.) 25-7/8 27-1/2 27-1/2 27-1/2
Length of Gap (in.) 12-1/4 12-1/4 12-1/4 12-1/4
Distance Between Centers (in.) 60 40 60 80
Spindle Bore (in.) 3-1/8 3-1/8 3-1/8 3-1/8
Spindle Mount D1-8 D1-8 D1-8 D1-8
Spindle Taper (with sleeve) MT-7 (MT-5) MT-7 (MT-5) MT-7 (MT-5) MT-7 (MT-5)
Number of Spindle Speeds 12 12 12 12
Range of Spindle Speeds (RPM) 25 -1,800 25 -1,800 25 -1,800 25 -1,800
Number of Longitudinal and Cross Feeds 122 122 122 122
Range of Longitudinal Feeds (in./rev.) .0015 – .0913 .0015 – .0913 .0015 – .0913 .0015 – .0913
Range of Cross Feeds (in./rev.) .0006 – .0365 .0006 – .0365 .0006 – .0365 .0006 – .0365
Number of Inch Threads 61 61 61 61
Range of Inch Threads (TPI) 1-5/8 -72 1-5/8 -72 1-5/8 -72 1-5/8 -72
Number of Metric Threads 24 24 24 24
Range of Metric Threads (mm) 0.05-20 0.05-20 0.05-20 0.05-20
Tool Size (max./in.) 1 x 1 1 x 1 1 x 1 1 x 1
Compound Slide Travel (max./in.) 5-1/8 5-1/8 5-1/8 5-1/8
Cross Slide Travel (max./in.) 9 9 9 9
Carriage Travel (in.) 55 35 55 75
Tailstock Spindle Travel (in.) 5 5 5 5
Tailstock Taper MT-4 MT-5 MT-5 MT-5
Steady Rest Capacity (in.) 1/2 -3-1/2 1/2 -3-1/2 1/2 -3-1/2 1/2 -3-1/2
Follow Rest Capacity (in.) 3/8 - 7 3/8 - 7 3/8 - 7 3/8 - 7
Width of Bed (in.) 13-3/8 13-3/8 13-3/8 13-3/8
Overall Dimensions (in./L x W x H) 116-1/2 x 40 x 48 97-1/2 x 40 x 48-7/8 116-1/2 x 40 x 48-7/8 136-1/8 x 40 x 48-7/8
Motor 7-1/2HP, 3Ph, 230/460V 7-1/2HP, 3Ph, 230/460V 7-1/2HP, 3Ph, 230/460V 7-1/2HP, 3Ph, 230/460V
Prewired 230V 230V 230V 230V
Net Weight (lbs.) 5795 5980 6245 6590
LATHE INCLUDED IN ALL PACKAGE NUMBERS LISTED BELOW
Taper Attachment 321477 321466 321463 321486
Collet Closer
Taper Attachment & Collet Closer 321544
Acu-Rite 100S DRO 321489
Acu-Rite 200S DRO 321455 321481 321484 321487
Acu-Rite 200S 3-Axis DRO 321530
Acu-Rite 200S DRO & Taper Attachment 321543 321483 321504 321560
Acu-Rite 200S DRO & Collet Closer
Acu-Rite 200S DRO, Taper Attachment & Collet Closer 321505
Anilam 311 DRO 321528
Anilam 311 DRO & Collet Closer
Anilam 550 DRO
Anilam 550 DRO, Taper Attachment & Collet Closer
Newall C80 DRO 321139 321140 321488
Newall C80 DRO & Taper Attachment 321529 321452
Newall C80 DRO & Collet Closer
Newall C80 DRO, Taper Attachment & Collet Closer 321502
36
JET TURNING
TURNING
jettools.com
jettools.com
TURNING
37
JET TURNING
STOCK NUMBER 321373
Model Number BD-920N
Swing Over Bed (in.) 8-3/4
Swing Over Cross Slide (in.) 5-1/4
Distance Between Centers (in.) 20
Spindle Bore (in.) 25/32
Spindle Mount (in. x TPI) 1-1/2 x 8
Spindle Taper MT-3
Spindle Speeds 6
Spindle Speed Range (RPM) 130-2,000
Longitudinal Feeds 27
Longitudinal Feed Range (in./rev.) .005-.011
Inch Threads 27
Inch Thread Range (TPI) 8-56
Metric Threads 11
Metric Thread Range (mm) .5-3
Maximum Tool Size (in.) 1/2 x 1/2
Compound Slide Travel (in.) 1-7/8
Cross Slide Travel (in.) 5
Carriage Travel (in.) 16
Tailstock spindle Travel (in.) 1-9/16
Tailstock Spindle Taper MT-2
Steady Rest Capacity (in.) 1-7/8
Follow Rest Capacity (in.) 1-7/8
Bed Width (in.) 4-7/8
Overall Dimensions with Stand (in./L x W x H) 37-1/2 x 20 x 45
Motor 3/4HP, 1Ph, 115V only
Net Weight (lbs.) 235
9"X20" BELT DRIVE BENCH LATHE
• Spindle supported by precision tapered roller bearings
• Hardened and ground bedways
• Power longitudinal feed allows threading
• Standard 1-1/2” x 8 TPI spindle mount allows for many
aftermarket accessories
• Reversing switch included for added versatility
• Backlash adjustments provided throughtout the carriage
• Tailstock is adjustable for taper cuts
• Quick-change gear box provides wide range of inch and
metric threads
STANDARD EQUIPMENT
• 4" 3-jaw chuck with threaded back plate
• 7" 4-jaw with threaded back plate
• Face plate
• Four-way tool post
• Single tool post
• Steady and follow rest
• Metric change gears
• Centers
• Threading dial
• Tool box and tools
OPTIONAL
EQUIPMENT
STOCK
NUMBER
Cabinet Stand 321374
MT-2 Live Center 465302
9"x20" BELT DRIVE BENCH LATHE
Shown with Optional Stand
38
JET TURNING
TURNING
jettools.com
jettools.com
TURNING
39
JET TURNING
13"x40" BELT DRIVE BENCH LATHE
• One of the most popular JET lathes now comes with an enclosed
gearbox as a standard feature
• Enclosed gearbox design provides smooth, quiet operation
• Fast, easy speed changes
• Low voltage motor controls
• Helical cut headstock gears reduce noise
• Change gears allow metric threading
• Spindle is supported by precision tapered roller bearings
• V-way bed is induction hardened and ground
• Gap bed section provided for large diameter work
• Independent leadscrew and feed rod
• T-slotted compound slide with four-way tool post
• Carriage mounted spindle control lever
• Automatic feeding and threading are fully interlocked
• Feed selectors travel in grooved ways
• Tailstock may be offset for turning tapers and includes an inch/
metric graduated quill
• Oil pan included
• Tolerance test certicate included
STANDARD EQUIPMENT
• 6" 3-jaw direct mount chuck with top
reversing jaws
• 8" 4-jaw chuck
• 12" faceplate
• Four-way tool post
• Steady and follow rest
• Metric change gear
• Centers with headstock center sleeve
• Threading dial
• Tool box with tools
Shown with Optional Stand
13"x40" BELT DRIVE BENCH LATHE
38
JET TURNING
TURNING
jettools.com
jettools.com
TURNING
39
JET TURNING
STOCK NUMBER 321360A
Model Number BDB-1340A
Swing over Bed (in.) 13
Swing over Cross Slide (in.) 7-25/32
Swing over Gap (in.) 18-3/4
Length of Gap (in.) 8
Distance between Centers (in.) 40
Spindle Bore (in.) 1-3/8
Spindle Mount D1-4
Spindle Taper (with sleeve) MT-5 (MT-3)
Number of Spindle Speeds 12
Range of Spindle Speeds (RPM) 60 – 1,240
Number of Longitudinal & Cross Feeds (in./rev.) 40
Range of Longitudinal Feeds (in/rev) .0036 – .0325
Range of Cross Feeds (in/rev) .0012 – .0345
Number of Inch Threads 40
Range of Inch Threads (T.P.I.) 4 – 112
Number of Metric Threads 27
Range of Metric Threads (mm) 0.2 – 6
Maximum Tool Size (in.) 5/8 x 5/8
Compound Slide Travel (in.) 2-11/16
Cross Slide Travel (in.) 6-5/16
Carriage Travel (in.) 35
Tailstock Spindle Travel (in.) 3-3/4
Tailstock Taper MT-3
Steady Rest Capacity (in.) 2-5/8
Follow Rest Capacity (in.) 2-3/4
Width of Bed (in.) 7-3/8
Overall Dmensions with Stand (in./LxWxH) 71 x 32 x 45
Motor 2HP, 230V, 1Ph
Net Weight (lbs.) 954
OPTIONAL EQUIPMENT STOCK NUMBER
Cabinet Stand 321443AK
5C Lever-Type Collet Closer 321515A
5C Collet Set 650014
Taper Attachment Kit 321442
Coolant System 321444
Rocker Style Tool Post 321431
MT-3 Live Center 465303
Digital Readouts Available for installation and after-market sales
13"x40" BELT DRIVE BENCH LATHE
40
JET TURNING
TURNING
jettools.com
jettools.com
TURNING
41
JET TURNING
STANDARD EQUIPMENT
• 6" 3-jaw direct mount chuck with top
reversing jaws
• 8" 4-jaw chuck
• 12" face plate
• Four-way tool post
• Steady and follow rest
• Metric change gear
• Splash guard
• Centers and headstock center sleeve
• Threading dial
• Tool box and tools
13"X40" GEARED HEAD BENCH LATHE
• One of the most popular JET lathes now comes with an enclosed gearbox
as a standard feature
• Enclosed gearbox design provides smooth, quiet operation
• Fast, easy speed changes
• Hardened and ground gears are featured in the headstock and gearbox
• D1-4 spindle is precision ground for accuracy and supported by high
quality tapered roller bearings
• Headstock is constantly oiled during operation
• Gear box gives wide inch threading and feed capabilities with no
gear changes
• V-way bed design is induction hardened and ground
• Gap bed section provided for larger diameter work
• Independent leadscrew and feed rod
• Spindle actuation control is apronmounted
• Compound and cross slide have backlash elimination
• Adjustable gibs are incorporated in the carriage and slideways
• Tailstock may be offset for turning tapers and includes an inch-metric
graduated quill
• Oil pan included
• Tolerance test certicate included
13"x40" GEARED HEAD BENCH LATHE
Shown with Optional Stand
40
JET TURNING
TURNING
jettools.com
jettools.com
TURNING
41
JET TURNING
OPTIONAL EQUIPMENT STOCK NUMBER
Cabinet Stand 321443AK
5C Lever-Type Collet Closer 321514A
5C Collet Set 650014
Taper Attachment Kit 321442
Coolant System 321444
Rocker Style Tool Post 321431
MT-3 Live Center 465303
Digital Readouts Available for installation and
after market sales
STOCK NUMBER 321357A
Model Number GHB-1340A
Swing Over Bed (in.) 13
Swing Over Cross Slide (in.) 7-25/32
Swing Through Gap (in.) 18-3/4
Length of Gap (in.) 8
Distance Between Centers (in.) 40
Spindle Bore (in.) 1-3/8
Spindle Mount D1-4
Spindle Taper (With Sleeve) MT-5 (MT-3)
Number of Spindle Speeds 8
Range of Spindle Speeds (RPM) 70 – 2,000
Number of Longitudinal and Cross Feeds 40
Range of Longitudinal Feeds (in./rev.) .0036 – 0325
Range of Cross Feeds (in./rev.) .0012 – .0345
Number of Inch Threads 40
Range of Inch Threads (T.P.I.) 4 – 112
Number of Metric Threads 27
Range of Metric Threads (mm) 0.2 – 6
Max. Tool Size (in) 5/8 x 5/8
Compound Slide Travel (in.) 2-11/16
Cross Slide Travel (in.) 6-5/16
Carriage Travel (in.) 35
Tailstock Spindle Travel (in.) 3-3/4
Taper in Tailstock Spindle MT-3
Steady Rest Capacity (in.) 2-5/8
Follow Rest Capacity (in.) 2-3/4
Width of Bed (in.) 7-3/8
Overall Dimensions with Stand (in./L x W x H) 71 x 32 x 47
Motor 2HP, 230V, 1Ph
Net Weight (lbs.) 1015
13"x40" GEARED HEAD BENCH LATHE
42
JET TURNING
TURNING
jettools.com
jettools.com
TURNING
43
JET TURNING
13"x40" AND 14"x40" GEARED HEAD ENGINE LATHES
• Uniquely designed exclusively by JET
• Hardened and ground gears are featured in the headstock
and gearbox
• D1-4 spindle is precision ground for accuracy and supported by
high-quality tapered roller bearings
• Headstock is constantly oiled during operation
• Splined, not keyed, shafts are utilized in the headstock
• Gearbox gives large threading and feed capabilities with no
gear changes
• V-way bed design is induction hardened and ground
• Gap bed section provided for larger diameter work
• Independent leadscrew and feed rod
• Spindle actuation control is apron mounted
• Inch-metric dials are standard
• Compound and cross slide have backlash elimination
• Adjustable gibs are incorporated in the carriage and slideways
• Tailstock may be offset for turning tapers and includes an
inch-metric graduated quill
• Tolerance test certicate included
STANDARD EQUIPMENT
• Heavy-duty stand
• 6" 3-Jaw direct mount chuck with top reversing
jaws
• 8" 4-jaw chuck
• 12" face plate
• Four-way tool post
• Steady and follow rest
• Micro-carriage bed stop
• Front removable chip tray
• Spindle jog button
• Foot brake
• Coolant system with splash guard
• Metric change gears
• Halogen work lamp
• Centers and headstock center sleeve
• Threading dial
• Tool box and tools
13"x40" & 14"x40" GEARED HEAD ENGINE LATHES
321810
Questo manuale è adatto per i seguenti modelli
19
Indice
Altri manuali Jet Tornio
Jet
Jet JWL-1221VS Scheda tecnica
Jet
Jet 719103A Scheda tecnica
Jet
Jet JML-1014VS Manuale utente
Jet
Jet JWL-1640VS Manuale utente
Jet
Jet GH-1340W Manuale utente
Jet
Jet JWL-1840VS Manuale utente
Jet
Jet 708358 Manuale di servizio
Jet
Jet JWL-1442VSK Manuale di servizio
Jet
Jet 719201 Scheda tecnica
Jet
Jet BD-8 Manuale utente
Jet
Jet Elite E-1236VS Manuale di servizio
Jet
Jet JML-1014I Manuale utente
Jet
Jet BDB-1340A Manuale utente
Jet
Jet JWL-1220 Manuale utente
Jet
Jet JWL-1220VS Manuale utente
Jet
Jet BD-10VS Manuale utente
Jet
Jet GHB-1236 Guida alla risoluzione dei problemi
Jet
Jet BDB-1340A Manuale utente
Jet
Jet JWL-1840DVR Manuale di servizio
Jet
Jet GH-1440 Manuale di servizio
