JETWAY HPC150C-DCP1135G7 Manuale utente
Panel PC
User’s Manual
NO. G03-PCLZ0FRFP-F
Manual Revision: 2.0
Release Date: 2022/11/18
i
Safety Precautions............................................................................................................................... ii
User’s Notice..........................................................................................................................................iii
Package Contents.................................................................................................................................iii
Environmental Protection Announcement .................................................................................. iii
Chapter 1 Introduction......................................................................................................................1
1-1 General Descriptions...........................................................................................................1
1-2 Specifications........................................................................................................................ 2
1-3 I/O Outlets...............................................................................................................................7
1-4 Connector Description........................................................................................................7
Chapter 2 Hardware and Installation............................................................................................ 7
2-1 Dimensions and Outlines................................................................................................... 11
2-2 To Open the Chassis........................................................................................................... 13
2-3 Jumper Settings....................................................................................................................14
2-4 Hardware Installation...........................................................................................................17
2-4-1 To Install SO-DIMM to the Board........................................................................17
2-4-2 To Install M.2 M-Key Card.................................................................................... 18
2-4-3 To Install M.2 E-Key Wi-Fi Card..........................................................................19
2-4-4 To Install M.2 B-Key Card along with Nano-SIM Card..................................22
2-4-5 To Install HDD......................................................................................................... 25
Chapter 3 Introducing BIOS............................................................................................................ 26
3-1 Entering Setup..................................................................................................................... 27
3-2 BIOS Menu Screen.............................................................................................................. 27
3-3 Function Keys...................................................................................................................... 27
3-4 Getting Help.......................................................................................................................... 27
3-5 Menu Bars............................................................................................................................. 28
3-6 Main Menu............................................................................................................................. 28
3-7 Advanced Menu................................................................................................................... 29
3-8 Chipset Menu........................................................................................................................38
3-9 Security Menu.......................................................................................................................40
3-10 Boot Menu............................................................................................................................. 41
3-11 Save & Exit Menu.................................................................................................................42
APPENDIX...............................................................................................................................................43
TABLE OF CONTENT
ii
Safety Precautions
Operate the product according to the correct installation steps and with great care to make sure
safety and comfort using experience. Please refer to the following safety instruction guide to avoid
danger of electric shock or fire. Abide by the previous safety instruction guide to use and maintain
the product and the hard disk to make sure of safe operating environment.
Please follow the instruction manual for operation guide.
The appropriate operating temperature ranges from 0 °C–50 °C.
The operation humidity for this product is 5% to 80% RH.
To avoid high temperature, please DO NOT overload the maximum power of the external power
supply while the system is consuming high voltage. Be aware of the maximum temperature
allowance of the power supply.
See to it that the product is not working near the water.
Always unplug power cable and other hardware cables from the system before cleaning.
Apply only dry cloth for cleansing the product.
Make sure that there is no heat source nearby when the product is working.
Make sure that the thermal louver of the product is not blocked.
Make sure to remove the power plug from the product when there is a thunder storm.
Please remove the power plug from the product when you are not going to use the product for a
long time.
Make sure to set up or use the product on a stable surface.
Make sure not to drop the product or strike it by any means.
Make sure not to move the product when the power is on.
Make sure not to step on the power cables and other cables or rest anything in them..
Be sure to ground yourself to prevent static charge when installing any internal components. Use a
grounding wrist strap and place all electronic components in any static-shielded devices. Most
electronic components are sensitive to static electrical charge.
Disconnect the power cord from the Panel PC unit prior to any installation. Be sure both the
system and all external devices are turned off. Sudden surge of power could ruin sensitive
components. Make sure the Panel PC unit is properly grounded.
Do not open the system’s back cover. If opening the cover for maintenance is a must, only a
trained technician is allowed to do so. Integrated circuits on computer boards are sensitive to static
electricity. To avoid damaging chips from electrostatic discharge, observe the following
precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. This will help to discharge any static electricity on
human body.
When handling boards and components, wear a grounding wrist strap available from
most electronic component stores.
Please contact qualified technician for maintenance or repair.
Use only accessories and parts that are made by the qualified manufacturer.
iii
User’s Notice
Copyright of this manual belongs to the manufacturer. No part of this manual, including the products
and software described in it may be reproduced, transmitted or translated into any language in any
form or by any means without written permission of the manufacturer.
This manual contains all information required for the utilization of this product to meet the user’s
requirements. But it will change, correct at any time without notice. Manufacturer provides this manual
“as is” without warranty of any kind, and will not be liable for any indirect, special, incidental or
consequential damages (including damages for loss of profit, loss of business, loss of use of data,
interruption of business and the like).
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and they are used only for identification or explanation and to
the owner’s benefit, without intent to infringe.
Package Contents
Power Core
90W AC-DC Adapter
Panel PC System
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.
1
Chapter 1
Introduction
1-1 General Descriptions
Thank you for purchasing the system, a new product developed, designed and
manufactured under leading technical power and consistent dedication to fine
workmanship.
Highlight Features for this Panel PC product series:
TFT LCD with LED backlight
10-points Multi Capacitive Touch
Support Open frameless design
A true Flat, easy-to-clean front surface with edge-to-edge design
Front IP65 for protection against water and dust
Cable less design for easy hardware expansion
12-36V DC-in, with Electrical Over Stress (EOS) and OVP design
Onboard Intel® Tiger Lake SoC Processor
Support 2* DDR4 3200MHz Dual Channel SO-DIMM up to 64GB
Support HDMI Display
Support 1 * 7+15 Pin SATAIII (6Gb/s) device expansion
1* M.2 M-key (2242/2280), PCIe 4.0 x4interface, supports NVMe)
1* M.2 E-key (2230) USB2.0/PCIex1 interface supports CNVi
1* M.2 B-key (3042/3052/6570) supports 3G/4G/5G Module)
1* SIM card slot
2* Intel GbE, 2* USB3.2 (Gen2), 4* USB2.0
Support 2* RS232/422/485 & 2* RS232
Support CPU Smart FAN
Compliance with ErP standard
Support Watchdog function
The system has the following features besides other basic functions:
WiFi: the onboard M.2 E-key type-2230 PCI-E slot in the board supports
compatible WiFi card that can act as a mini wireless modem when external
antennas are connected. Different computers in the house can build wireless
connections through the system and take necessary data from it, thus reducing
the complexity in network establishment.
Dual Giga LAN: The system is integrated with dual Gigabit LAN network
controller realizing efficient power management for the operating system.
USB3.2 (Gen.2): Experience Fastest data transfers at 10Gb/s with USB3.2 Gen.2
the latest connectivity standard. Built connect easily with next-generation
components and peripherals, USB USB3.2 Gen.2 transfers data much faster
compatible with previous USB generations.
2
CPU Usage: The CPU Usage diagram shows a beautiful data curve that
indicates a pretty low CPU usage percentage for video playback of different
formats. GPU performances are excellent as well.
dB Value: The design of the system takes into consideration the needed quiet
operating environment in the living room and the average dB value is below 26
under normal operation to ensure the tranquility.
1-2 Specifications
Panel PC Model Common Specifications:
Main System Parameters
Embedded CPU
Intel®Tiger Lake series processor
*Note: CPU model may vary from different options. Please please
visit our website or consult your dealer for more information of
onboard CPU.
RAM
Support 2* DDR4 SO-DIMM (Max 64GB)
Flash ROM
256MB SPI Flash ROM
Watchdog Timer
256 levels, 0~255 sec.
OS Support
Windows 10/Linux
Storage
SATA Port
Support 1* 2.5” SATA HDD (UPS Cell Option)
M.2 M Slot
1* M.2 M key (2242/2280, SATA/PCI-Ex4)
Expansion
M.2 Expansion Slot
1* M.2 E key (2230) for WIFI
1* M.2 B key (3042/3052/6570) for 4G/5G Module (4pcs
Built in Antenna)
I/O Connector
I/O Ports & Switches
2* USB 3.2 (Gen.2)
4* USB 2.0
2* RS232/422/485
2* RS232 or 2* GPIO(Optional)
1* HDMI
1* AT/ATX mode button
2* RJ-45 LAN (1* Intel® I225V 2.5G, 1* Intel® I219LM
GbE)
1* 12~36V DC-in locking power jack
1* Power button
1* 2-pin front power button
CASE
Panel Material
Aluminum
Case Material
Iron
Color
White
Coating Requirement
Spray Paint
Certification Compliance
Certifications
CE, FCC, IP65(Front)
3
Safety
Shock
1ms duration
Vibration
5~500Hz/1Grms
Environment
Temperature
Operating: -10°C ~ 50°C
Storage: -20°C ~ 70°C
Warranty
Warranty
2 Years Limited Warranty （Panel and Touch is only
Warranty 1 Year）
Panel PC Model Differences:
HPC150C-DCP6305E & HPC150C-DCP1135G7
Display
Front Bezel
IP65, NEMA 4 rugged protection, metal front bezel
Display Type
15.0" with LED Backlight
Brightness (cd/m²)
350 nits
Display Color
16.7m
Resolution
1024 x 768 @60Hz
Viewing Angle
178°/178° (H/V)
Pixel Pitch
0.099 x 0.297mm
Aspect Ratio
4:3
Contrast Ratio
1000:1
Response Time
35 ms
Touch Screen
Type
Projected capacitive type
Active Range
336.3 x 260.6mm ±0.3mm
Transparency
≧85%
Surface Hardness
≧6H (JIS-5400)
Power
Power Input
12~36V DC-in
AC version: 100~240V AC‐DC 60W power adapter or
DC version: 12VDC with over current protection fuse
Power Consumption
45W
Dimensions
Case Dimensions
382.3 x 288.6 x 63.1mm
4
HPC156C-DCP1135G7 Series
Display
Front Bezel
IP65, NEMA 4 rugged protection, metal front bezel
Display Type
15.6" with LED Backlight
Brightness (cd/m²)
250 nits
Display Color
256K
Resolution
1920 x 1080 @60Hz
Viewing Angle
170°/170° (H/V)
Pixel Pitch
0.17925 x 0.17925mm
Aspect Ratio
16:9
Contrast Ratio
800:1
Response Time
35ms
Touch Screen
Type
Projected capacitive type
Active Range
386.81 x 237.12mm ±0.3mm
Transparency
≧85%
Surface Hardness
≧6H (JIS-5400)
Power
Power Input
12~36V DC-in
AC version: 100~240V AC‐DC 60W power adapter or
DC version: 12VDC with over current protection fuse
Power Consumption
42W
Dimensions
Case Dimensions
406.81 * 259.12 * 56.00mm
5
HPC215C-DCP1135G7 Series
Display
Front Bezel
IP65, NEMA 4 rugged protection, metal front bezel
Display Type
21.5" with LED Backlight
Brightness (cd/m²)
250 nits
Display Color
16.7M display color
Resolution
1920 x 1080 @60Hz
Viewing Angle
170°/160° (H/V)
Pixel Pitch
0.24825 x 0.24825mm
Aspect Ratio
16:9
Contrast Ratio
1000:1
Response Time
8ms
Touch Screen
Type
Projected capacitive type
Active Range
386.81 x 237.12mm ±0.3mm
Transparency
≧85%
Surface Hardness
≧6H (JIS-5400)
Power
Power Input
12~36V DC-in
AC version: 100~240V AC‐DC 60W power adapter or
DC version: 12VDC with over current protection fuse
Power Consumption
45W
Dimensions
Case Dimensions
535.80 * 327.31 * 68.50 mm
6
HPC270C-DCP1135G7 Series
Display
Front Bezel
Rugged protection, metal front bezel
Display Type
27.0" with LED Backlight
Brightness (cd/m²)
300 nits
Display Color
16.7M display color
Resolution
1920 x 1080 @60Hz
Viewing Angle
178°/178° (H/V)
Pixel Pitch
0.1038 x 0.1038mm
Aspect Ratio
16:9
Contrast Ratio
1000:1
Response Time
13ms
Touch Screen
Type
Projected capacitive type (LG in-cell Touch)
Active Range
597.888 x 336.312mm ±0.2mm
Surface Hardness
≧3H (JIS-5400)
High-end Features
Support High Touch Performance
Support Strengthened Polarizer for in-TOUCH
Support High Picture Quality
Support Low Reflection / Deep Black
Support No deterioration of PQ caused by TOUCH Film
Support Low color Shift
Support Stable Touch without Flash
Power
Power Input
12~36V DC-in
AC version: 100~240V AC‐DC 60W power adapter or
DC version: 12VDC with over current protection fuse
Power Consumption
48W
Dimensions
Case Dimensions
611.20 x 359.18 x 59.00mm
Questo manuale è adatto per i seguenti modelli
2
Indice
Altri manuali JETWAY Pannello touch
JETWAY
JETWAY HPC-156 Manuale utente
JETWAY
JETWAY HPC-104BR-2930-4G Istruzioni per il montaggio
JETWAY
JETWAY HPC104GR-HD1900B Series Manuale utente
JETWAY
JETWAY G03-PCNC7ACFP-F Manuale utente
JETWAY
JETWAY HPC150BR-FP7200 Manuale utente
JETWAY
JETWAY HPC170SR-ITQ170 Series Manuale utente
JETWAY
JETWAY HPC-WV133 Manuale utente
JETWAY
JETWAY HPC150R-DCP6305E Series Manuale utente
JETWAY
JETWAY HPC-101 Manuale utente
JETWAY
JETWAY HPC070SC-FP2807A Series Manuale utente
