John Lewis BALDWIN Manuale utente

John Lewis Partnership

171 Victoria Street

London SW1E 5NN

johnlewis.com

Made in China Please retain these instructions for future reference.

5 year guarantee

If you experience any unresolvable technical issues with the product,

contact your nearest John Lewis & Partners shop or John Lewis & Partner

Technical Support on 03301 230106.

Aftercare and

Troubleshooting

Max. power: 40W

Voltage: 220–240V, 50Hz

IP rating: 20

Weight: 5kg

At John Lewis & Partners we test every light to high quality standards so we are

able to offer you a 5 year guarantee.

Specification

Recycling

Caring for

your product

We recommend cleaning with a soft dry cloth. Do not use abrasive materials as

these will damage the nish.

This symbol indicates that this product should not be treated as

normal household waste and it should be recycled. John Lewis & Partners

do not operate instore take back, but as members of the Distributor

Take Back scheme have funded the development and upgrade of

recycling facilities across the UK. Please take it to your nearest

collection facility or for further details contact your local council

or visit www.recycle-more.co.uk.

BALDWIN FLOOR LAMP

USER GUIDE

10/05/2021

01 02

Parts list Qty

Introduction Thank you for purchasing this Baldwin Floor Lamp.

Please read the instructions carefully before

use to ensure safe and satisfactory operation

of this product.

Warnings This is a Class ll product and must NOT be earthed.

Please read these instructions carefully before commencing any work.

Your standard lamp has been packaged as separate parts to prevent damage

during transit.

When manoeuvring or assembling this product, it must be lifted from

the bottom section.

The lamp must be protected by a 3 amp fuse in the mains plug.

If you are in any doubt, please consult a qualied electrician.

For your safety, always switch off the supply before cleaning or adjusting.

If the mains cable becomes damaged it must only be replaced by a technically

competent, qualied person.

Recommended bulb

Product assembly

Recommended bulb (not included)

1 x 7W E27 LED Energy Efcient GLS, or

1 x 28W E27 Eco Halogen GLS, or

1 x 40W (Max.) E27 GLS

When changing a bulb, always switch off at the mains and allow the bulb to cool

before handling. Dispose of used bulbs carefully. Do not exceed the rated power

stated or use a different shape bulb from that indicated on the tting.

Carefully unpack the carton, making sure all the

parts are present before assembly.

Join the upper (A) and middle (B) sections of

stem into the lower section (C) by screwing in

a clockwise direction. Take care not to trap the

cable or cross the threads.

Fit the shade (G) by slotting over the lampholder

and secure with the shade ring (H). Fit the bulb (I)

per the detail overleaf.

Plug the lamp in and switch on using the foot switch.

The shade position can be adjusted by loosening

the thumb screw in the join of the shade and arm ( J).

PLEASE NOTE: The lamp head will become hot

during use. Always switch off and allow to cool before

adjusting the lamp head. Ensure the stem is held while

adjusting the lamp head.

Light tting 1

Shade 1

Spanner 1

2Slot the stem (D) into the base (E) and gently pull

through any excess cable. Secure the stem into

the base using the washer and nut and tighten with

the spanner (F).
