Joy-it Arduino Nano V3 Manuale utente
3
Arduino Nano V3
Published: 04.04.2018 Copyright by Joy-IT 3
3Arduino Nano V3
1. Introduction
Dear customer,
thank you for choosing our product.
In the following, we will show you how to use your product.
Should you encounter any unexpected problems during use, please do not hesitate to contact us.
Published: 04.04.2018 Copyright by Joy-IT 4
3Arduino Nano V3
2. Installation
To use the Arduino Nano, you rst need the appropriate Arduino soware. This is available here.
Download and install the soware package (Arduino IDE).
Aer you have started the soware, it must be set to the board.
Open the "Tools" tab and select the "Arduino Nano" board under "Boards".
Published: 04.04.2018 Copyright by Joy-IT 5
3Arduino Nano V3
3. Usage
The soware is now congured and ready for use.
Now connect your Arduino Nano to your computer with a mini USB cable.
To check the basic funcons of the board, you can transfer a short example program to your Arduino
Nano.
Select the "Examples" menu on the "File" tab and the "Blink" example under "01.Basics".
Transfer this program to your Arduino.
It will acvate the built-in LED, which is connected to digital pin 13, and switch it on and o repeatedly.
All important connecons are also marked here:
Published: 04.04.2018 Copyright by Joy-IT 6
3Arduino Nano V3
4. Support
We also support you aer your purchase. If there are any quesons le or if you encounter any problems,
please feel free to contact us by mail, phone or by our cket-supportsystem on our website.
E-Mail: service@joy-it.net
Ticket-System: hp://support.joy-it.net
Phone: +49 (0)2845 98469 – 66 (11- 18 Uhr)
Please visit our website for more informaons:
www.joy-it.net
