Julabo ME Manuale utente

19510506.doc 24.01.11

Operating Manual

English

Heating Circulators

ME-4

ME-6

ME-12

ME-26

Printed in Germany

Changes without prior notification reserved

1.951.0506 01/11

JULABO Labortechnik GmbH

77960 Seelbach / Germany

+49 (0) 7823 / 51-0

+49 (0) 7823 / 24 91

|[email protected]

Þwww.julabo.de

Congratulations!

You have made an excellent choice.

JULABO thanks you for the trust you have placed in us.

This operating manual has been designed to help you gain an understanding of the operation and

possible applications of our circulators. For optimal utilization of all functions, we recommend that you

thoroughly study this manual prior to beginning operation.

The JULABO Quality Management System

Temperature control devices for research and industry are developed,

produced, and distributed according to the requirements of

ISO 9001:2008. Certificate Registration No. 01 100044846

Unpacking and inspecting

Unpack the circulator and accessories and inspect them for possible transport damage. Damage

should be reported to the responsible carrier, railway, or postal authority, and a damage report should

be requested. These instructions must be followed fully for us to guarantee our full support of your

claim for protecting against loss from concealed damage. The form required for filing such a claim will

be provided by the carrier.

Printed in Germany Changes without prior notification reserved

TABLE OF CONTENTS

Operating manual............................................................................................................................5

1. Intended use.............................................................................................................................5

1.1. Description...........................................................................................................................5

2. Operator responsibility – Safety recommendations..................................................................6

2.1. Disposal...............................................................................................................................7

2.2. EC Conformity......................................................................................................................8

2.3. Warranty conditions.............................................................................................................8

2.4. Technical specifications.......................................................................................................9

Operating instructions ...................................................................................................................11

3. Safety notes for the user ........................................................................................................11

3.1. Explanation of safety notes................................................................................................11

3.2. Explanation of other notes.................................................................................................11

3.3. Safety recommendations ...................................................................................................12

4. Operating controls and functional elements...........................................................................14

4.1. Circulator............................................................................................................................14

5. Preparations...........................................................................................................................16

5.1. Installation..........................................................................................................................16

5.2. Bath fluids..........................................................................................................................16

5.3. Temperature application to external systems ....................................................................17

5.1.1.Tubing ...........................................................................................................................18

5.4. Filling / draining..................................................................................................................19

5.5. Countercooling...................................................................................................................20

6. Operating procedures.............................................................................................................21

6.1. Power connection ..............................................................................................................21

6.2. Switching on / Start - Stop .................................................................................................21

6.2.1.Switching on the circulator.............................................................................................21

7. Setting of temperatures.............................................................................................22

7.1. Using the pre-settings in the menu.......................................................................22

7.2. Direct setting of temperatures............................................................................................23

8. Safety installations, warning functions......................................................................24

8.1. Excess temperature protection ..........................................................................................24

8.1.1.Early warning system, low level protection....................................................................25

8.2. Switch-over from warning to shutdown function.................................................................26

8.3. Over and Sub temperature warning function.....................................................................27

9. Menu functions .........................................................................................................28

9.1. MENU PROGRAM – START.............................................................................................29

9.2. MENU PROGRAM – creation, administration....................................................................31

9.3. MENU PUMP – Setting of pump pressure.........................................................................33

9.4. MENU CONFIG – Configuration of unit.............................................................................34

9.4.1.REMOTE.......................................................................................................................35

9.4.2.AUTOSTART.................................................................................................................35

9.4.3.OFF-MODE...................................................................................................................36

9.4.4.Setting of clock and date...............................................................................................36

9.4.5.RESET – Factory settings.............................................................................................36

9.5. MENU CONTROL – Control characteristics and parameters............................................37

9.5.1.CONTROL – Control INTERNAL / EXTERNAL ............................................................38

9.5.2.Dynamic internal............................................................................................................39

9.5.3.Control parameters – XPU-, XP-, TN-, TV- EXTERNAL ...............................................39

9.5.4.Control parameters– XP-, TN-, TV- INTERNAL............................................................40

9.6. MENU SERIAL - BAUDRATE, HANDSHAKE, PARITY ....................................................41

9.7. MENU ATC - Absolut Temperature Calibration.................................................................42

9.7.1.ATC SENSOR - INTERNAL / EXTERNAL....................................................................44

9.7.2.ATC STATUS - YES / NO.............................................................................................44

9.7.3.CALIBRATION TYPE: 1 -/ 2 -/ 3 POINT........................................................................45

9.7.4.Example: 3-point calibration for internal control...........................................................46

9.8. MENU LIMITS....................................................................................................................48

9.8.1.Limits for internal control...............................................................................................49

9.8.2.Limits for external control..............................................................................................49

10. Troubleshooting guide / error messages................................................................................51

11. Electrical connections.............................................................................................................54

12. Remote control.......................................................................................................................55

12.1. Setup for remote control ....................................................................................................55

12.2. Communication with a PC or a superordinated data system.............................................56

12.3. List of commands...............................................................................................................57

12.4. Status messages ...............................................................................................................59

12.5. Error messages..................................................................................................................59

13. JULABO Service – Online remote diagnosis..........................................................................61

14. Cleaning / repairing the unit....................................................................................................62

Operating manual

1. Intended use

JULABO circulators have been designed to control the temperature of specific fluids in a bath tank.

The units feature pump connections for temperature control of external systems (loop circuit).

JULABO circulators are not suitable for direct temperature control of foods, semi-

luxury foods and tobacco, or pharmaceutical and medical products.

Direct temperature control means unprotected contact of the object with the bath

medium (bath fluid).

1.1. Description

1x10

PID3

ATC

RS232

Pt100

PUMP

SMART

The circulators are operated via the splash-proof keypad. The microprocessor

technology allows different values to be set, stored, and displayed on the VFD

COMFORT-DISPLAY. Three menu keys facilitate the adjustment of setpoints,

warning and safety functions, and menu functions.

Temperature- and time-dependent processes can be stored and executed using

the integrated programmer.

The adjustable PID cascade temperature control automatically adjusts the heat

supply to the thermal requirements of the bath.

Absolute Temperature Calibration (ATC3) provides high temperature stability at all

points in the bath. With the 3-point calibration, an offset is adjusted at three

temperatures to ensure an accurate temperature pattern at the selected spot in the

bath over the entire temperature range.

Electrical connections:

RS232 interface for modern process technology without an additional interface.

Connection for external Pt100 sensor for external temperature measurement and

control.

Alarm output for external alarm message or control of JULABO refrigerating baths

or solenoid valve (cooling water).

The excess temperature protection according to IEC 61010-2-010 is a safety

device independent from the control circuit. Its safety value can be displayed and

adjusted on the VFD COMFORT-DISPLAY.

The early warning system for low level signals that bath fluid needs to be refilled

before the low level protection according to IEC 61010-2-010 triggers a safety

shutdown of the main functional elements.

Intelligent pump system: the pump capacity (electronically adjustable via the motor

speed) can be adapted to different conditions for internal and external temperature-

control applications.

Operator responsibility – Safety recommendations

2. Operator responsibility – Safety recommendations

The products of JULABO ensure safe operation when installed, operated, and maintained according to

common safety regulations. This section explains the potential dangers that may arise when operating

the circulator and also specifies the most important safety precautions to preclude these dangers as

far as possible.

The operator is responsible for the qualification of the personnel operating the units.

The personnel operating the units should be regularly instructed about the dangers involved with

their job activities as well as measures to avert these dangers.

Make sure all persons tasked with operating, installing, and maintaining the unit have read and

understand the safety information and operating instructions.

When using hazardous materials or materials that could become hazardous, the circulator may be

operated only by persons who are absolutely familiar with these materials and the circulator.

These persons must be fully aware of possible risks.

If you have any questions concerning the operation of your unit or the information in this manual,

please contact us!

Contact JULABO Labortechnik GmbH

Eisenbahnstraße 45

77960 Seelbach / Germany

Tel. +49 (0) 7823 / 51-0

Fax +49 (0) 7823 / 24 91

[email protected]

www.julabo.de

Safety instructions for the operator:

You have received a product designed for industrial use. Nevertheless, avoid strikes to the

housing, vibrations, damage to the operating-element panel (keypad, display), and contamination.

Make sure the product is checked for proper condition regularly (depending on the conditions of

use). Regularly check (at least every 2 years) the proper condition of the mandatory, warning,

prohibition and safety labels.

Make sure that the mains power supply has low impedance to avoid any negative effects on

instruments being operated on the same mains.

This unit is designed for operation in a controlled electromagnetic environment. This means that

transmitting devices (e.g., cellular phones) should not be used in the immediate vicinity.

Magnetic radiation may affect other devices with components sensitive to magnetic fields

(e.g., monitors). We recommend maintaining a minimum distance of 1 m.

Permissible ambient temperature: max. 40 °C, min. 5 °C.

Permissible relative humidity: 50% (40 °C).

Do not store the unit in an aggressive atmosphere.

Protect the unit from contamination.

Do not expose the unit to sunlight.

Appropriate operation

Only qualified personnel is authorized to perform configuration, installation, maintenance and repairs of

the circulator.

Routine operation can also be carried out by untrained personnel who should however be instructed by

trained personnel.

Use:

The bath can be filled with flammable materials. Fire hazard!

There might be chemical dangers depending on the bath medium used.

Observe all warnings for the used materials (bath fluids) and the respective instructions (safety data

sheets).

Insufficient ventilation may result in the formation of explosive mixtures. Only use the unit in well

ventilated areas.

Only use recommended materials (bath fluids). Only use non-acid and non corroding materials.

When using hazardous materials or materials that could become hazardous, the operator must affix

the enclosed safety labels (1 + 2) to the front of the unit so they are highly visible:

Warning label W00: Colors: yellow, black

Danger area. Attention! Observe instructions.

(operating manual, safety data sheet)

Mandatory label M018: Colors: blue, white

Carefully read the user information prior to beginning operation.

Scope: EU

Semi S1-0701 Table A1-2 #9

Carefully read the user information prior to beginning operation.

Scope: USA, NAFTA

Particular care and attention is necessary because of the wide operating range.

There are thermal dangers: Burn, scald, hot steam, hot parts and surfaces that can be touched.

Warning label W26: Colors: yellow, black

Hot surface warning.

(The label is put on by JULABO)

Observe the instructions in the manuals for instruments of a different make that you connect to the

circulator, particularly the respective safety recommendations. Also observe the pin assignment of

plugs and technical specifications of the products.

2.1. Disposal

The circulator contains a back-up battery that supplies voltage to memory chips when the unit is

switched off. Do not dispose of the battery with household waste!

Depending on battery regulations in your country, you might be obliged to give back used or defect

batteries to gathering places.

The product may be used with oil as bath fluid. These oils fully or partially consist of mineral oil or

synthetic oil. For disposal, observe the instructions in the safety data sheets.

Valid in EU countries

Directive 2002/96/EC of the European Parliament and of the Council of 27 January

2003 on waste electrical and electronic equipment (WEEE).

This directive requires electrical and electronic equipment marked with a crossed-

out trash can to be disposed of separately in an environmentally friendly manner.

Contact an authorized waste management company in your country.

Disposal with household waste (unsorted waste) or similar collections of municipal

waste is not permitted!

Operator responsibility – Safety recommendations

2.2. EC Conformity

The products described in the operating instructions conform to the requirements

of the following European guidelines:

Directive of the European Parliament and of the Council on the approximation of

the laws of the Member States relating to machinery.

EMC guideline with respect to legal harmonization of the member countries

concerning electromagnetic compatibility.

JULABO Labortechnik GmbH

Eisenbahnstr. 45

77960 Seelbach / Germany

2.3. Warranty conditions

JULABO Labortechnik GmbH warrants its products against defects in material or in workmanship,

when used under appropriate conditions and in accordance with appropriate operating instructions

for a period of ONE YEAR.

Extension of the warranty period – free of charge

With the ‘1PLUS warranty’ the user receives a free of charge extension to the warranty of up to 24

months, limited to a maximum of 10 000 working hours.

To apply for this extended warranty the user must register the unit on the JULABO web site

www.julabo.de, indicating the serial no. The extended warranty will apply from the date of JULABO

Labortechnik GmbH’s original invoice.

JULABO Labortechnik GmbH reserves the right to decide the validity of any warranty claim. In case of

faults arising either due to faulty materials or workmanship, parts will be repaired or replaced free of

charge, or a new replacement unit will be supplied.

Any other compensation claims are excluded from this guarantee.

2.4. Technical specifications

Heating circulators ME-4 ME-6 ME-12 ME-26

Working temperature range °C 20 ... 200 20 ... 200 20 ... 200 20 ... 200

Temperature stability °C ±0,01 ±0,01 ±0,01 ±0,01

Bath opening (WxL) cm 13x15 13x15 22x15 22x30

Bath depth cm 15 20 20 20

Filling volume liters 3 ... 4,5 4,5 ... 6 7,5 ... 12 18 ... 26

Overall dimensions (WxDxH) cm 21x42x38 21x43x42 30x43x45 36x61x45

Weight kg 9,6 12,5 13,0 26,0

All measurements have been carried out at:

rated voltage and frequency ambient temperature: 20 °C

bath fluid: water operating temperature: 70 °C

Technical changes without prior notification reserved.

Mains power connection 230 V/50 Hz V/ Hz 190 ... 253 / 50-60

Current draw (at 208 V / 230 V) A 8 / 9

Mains power connection 115 V/60 Hz V/ Hz 90 ... 127 / 50-60

Current draw (at 100 V / 115 V) A 8 / 9

Temperature selection digital

via keypad indication on VFD COMFORT-Display

remote control via personal computer indication on monitor

Temperature indication VFD COMFORT-DISPLAY

Resolution °C 0.1

Absolute Temperature Calibration INT/EXT °C ±3 / ±9

Temperature control PID3 cascade temperatur control

Heater wattage (at 230 V) kW 2,0

Heater wattage (at 115 V) kW 1,0

Electronically adj. pump capacity stages 1 ... 4

Flow rate at 0 bar l/min 11 ... 16

Pressure max. at 0 liter bar 0.22 ... 0.45

Electrical connections:

External alarm device Vdc/mA 24-0 / max. 25

Computer interface RS232

External temperature sensor Pt100

Ambient temperature °C 5 ... 40

Operator responsibility – Safety recommendations

Safety installations according to IEC 61010-2-010:

Excess temperature protection adjustable from 0 °C ... 230 °C

Low liquid level protection float switch

Classification according to DIN 12876-1 class III

Supplementary safety installations

Early warning system for low level float switch

High temperature warning function optical + audible (in intervals)

Low temperature warning function optical + audible (in intervals)

Supervision of working sensor plausibility control

Reciprocal sensor monitoring between

working and safety sensors difference >35 K

Alarm message optical + audible (permanent)

Warning message optical + audible (in intervals)

Environmental conditions according to IEC 61 010-1:

Use only indoor.

Altitude up to 2000 m - normal zero.

Ambient temperature: +5 ... +40 °C

Air humidity:

Max. rel. humidity 80 % for temperatures up to +31 °C,

linear decrease down to 50 % relative humidity at a temperature of +40 °C

Max. mains fluctuations of ±10 % are permissible.

Protection class according to IEC 60 529 IP21

The unit corresponds to Class I

Overvoltage category II

Pollution degree 2

Caution:

The unit is not for use in explosive environment

Standards for interference resistance according to EN 61326-1

This unit is an ISM device classified in Group 1 (using high frequency for internal purposes) Class A

(industrial and commercial range).

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Julabo Sistema di riscaldamento

Julabo

Julabo F38-ME Manuale utente

Manuali Sistema di riscaldamento popolari di altre marche

aerauliqa

aerauliqa QR350ABP Manuale utente

WatchGas

WatchGas ATEX BEACON Manuale utente

Viessmann

Viessmann Vitoligno 300-H Istruzioni operative

Lampoassa

Lampoassa 203GT Manuale utente

MSA

MSA SOA-1022 Manuale utente

nilan

nilan Compact P Manuale utente

ITR

ITR OASIS NE-S Manuale utente

Carrier

Carrier 48LJD Dimensioni e guida di installazione

aldes

aldes EVEREST XV Manuale utente

Kober

Kober C22SPV23MEF Manuale utente

Oxygen

Oxygen X-Air V400 Manuale utente

Carrier

Carrier FB4CNF Manuale utente

Kroll

Kroll HM200 Manuale

Kroll

Kroll HM200 Manuale

NuAire

NuAire XBOXER XBC Series Manuale utente

Trane

Trane VR104GD-U Series Manuale utente

Vents

Vents VUT V mini Manuale utente

Viessmann

Viessmann Divicon Manuale utente
