Keating Of Chicago Teppanyaki Griddle Manuale utente

TEPPANYAKI GRIDDLE

Ideal for presentation cooking

MIRACLEAN® surface reduces

flavor transfer

Saves 44% in clean up

High input elements rated at 240 volts

Zoned temperature control

Custom models available

The Keating Teppanyaki Griddle is exclusively designed to

meet the needs of your presentation cooking demands. The

MIRACLEAN® plate will keep your Teppanyaki griddle

looking clean and shiny even when not in use. The mirror

surface of the MIRACLEAN® is achieved in a special

eight step process.

FITS TO YOUR SPECIFICATIONS

The griddle plate size is determined by customer

specifications and can range from 24"x24" to 72"x30". Just

provide us with a drawing of the table that will be used so

that Keating can ensure a perfect fit. The actual heating

section on all griddle is 24"Wx18"D and is available in

electric only. Two high input elements rated at 240V are

standard. The heating section is thermostatically controlled

with one thermostat for each element. Keating does not

manufacture the table.

SAVES ON ENERGY COSTS

Documented energy savings of 32% by an independent

testing lab means dollar savings up to $400.00 per year in

energy costs on a 3-ft. model. The MIRACLEAN® surface

also reduces radiated heat loss to less than 10% of a

conventional steel plate griddle. By keeping heat on the

surface and away from your presentation area, the

MIRACLEAN® Griddle reduces air conditioning demands

and gives the chef and your customers a cooler cooking

environment.

SAVES 44% IN CLEAN UP

A documented study conducted by the University of

Illinois General Engineering department confirmed what

has long been known by MIRACLEAN® operators that

cleaning the MIRACLEAN® saves time! 44% savings

means less labor cost and higher productivity. Cleaning

just a three foot MIRACLEAN® versus a conventional

steel plate model twice daily would mean savings of $2600

over the life of the unit! When your cooking presentation

is completed, the chef can quickly and effortlessly clean

the MIRACLEAN® surface in just a few easy steps.

Scrape the surface with the Keating Scraper and then wash

with the Palmetto brush and water. Use Keating Klenzer

and a damp cloth to polish. No more griddle bricks, grill

screens or harsh chemicals are needed, and reseasoning the

plate is not necessary.

ACCURATE TEMPERATURE CONTROL

MIRACLEAN® Griddles feature zoned temperature

control to ensure temperature accuracy in cooking. The

MIRACLEAN® surface allows the operator to cook at

lower temperatures to control the degree of caramelization

and product shrinkage.

TEPPANYAKI GRIDDLE

“Serving Those Who Serve The Very Best”®

*Trough is optional.

TEPPANYAKI GRIDDLE

DESCRIPTION

The Keating Teppanyaki MIRACLEAN® Griddle

consists of a griddle plate equipped with electric elements.

An automatic temperature control mechanism is arranged

and designed for the proper cooking of food on a griddle

surface.

SPECIFICATIONS

Griddle Plate to be made of high carbon, 3/4" steel plate

upon which a trivalent chromium surface has been applied

in a special eight step process to ensure a mirror smooth

surface. The MIRACLEAN® plate has an emissivity

rating of .078.

Electric Elements to be two high input elements rated 7.9

kW at 240 volts. Elements are to be stainless steel. Each

element is encased in insulation and held tightly in place

with a molded steel cover.

Thermostat to be close range, hydraulic type, accurate to

±5° from 250° to 550°F, with one thermostat for each

element. Application of this thermostat is patented by

Keating.

Drain Trough an optional drain trough across the front

with a 4" x 1-1/2" drain in the left front (unless otherwise

specified). The drain is located above a large stainless

steel grease drawer with baffles and a rear handle. The

grease trough is 14 gauge stainless steel.

Standard Accessories to include one long-handle

palmetto brush, one egg turner, one can of Keating

Klenzer.

Electrical Connections to have 3 wire terminal block

with ground for field wiring. (See local codes for supply

line requirements).

Special Order Options may include stainless steel

perimeter, trough options, custom griddle styles and

configurations.

NOTE: Customer must provide drawing of table that will

be used, and table must be ventilated. Keating does not

manufacture the table.

TEPPANYAKI GRIDDLE

As continuous product improvement occurs, specifications may be changed without notice.

Printed in U.S.A. Teppanyaki2007 5/07

KEATING OF CHICAGO, INC.

Toll Free 1-800-KEATING

www.keatingofchicago.com

Electric Load

*480V is optional and must be specified.

5.9

6.6

7.9

*7.9

Volts AC

208

220

240

480

1-Phase Amps

–

3-Phase Amps

14-25-14

15-26-16

16-28-16

8-14-8

"A" dimensions: (per

customer specifications)

24" to 72"

"B" dimensions:

18", 24", 30"

NOT FOR OUTDOOR INSTALLATION

NOT FOR DOMESTIC INSTALLATION
