Operation
Once all equipments are powered on, it is shown by the blue link LED (refer to below
table). Then system will initiate a wireless link, successful connection of the link will
be shown by the blue link LED (refer to below table). This may take short time
depending on the distance between the units and other environmental factors.
When the initial wireless link has been established, the system will establish a video
link between the transmitter and receiver. Once it has been completed, the blue
video LED will be lit on both units (refer to below table *). If your HDMI source and
display devices support CEC then your source device can simply to control using the
displayer remote controller.
LED STATUS MEANING
Link LED slow flicker Power on
Link LED fast flicker Establishing link
Link LED lighting Established link
Remote controller operation
MENU Enter to setup mode
EXIT Exit setup mode
SOURCE Wireless transmitter source list
ADD Searching and adding a new
wireless transmitter
DELETE Delete a wireless transmitter
OK Confirm key
1 2 3 Change to source 1 2 3
Move cursor
CAUTION: Remove the paper from battery room please when you use controller first
time.
Use enclosed remote controller to search and add a new transmitter to delete a
transmitter. Use your remote controller point to transmitter.
