Kenwood KNA-RCDV331 Manuale utente

KNA-RCDV331

REMOTE CONTROL UNIT

INSTRUCTION MANUAL

TELECOMMANDE

MODE D’EMPLOI

FERNBEDIENUNG

BEDIENUNGSANLEITUNG

AFSTANDSBEDIENING

GEBRUIKSAANWIJZING

TELECOMANDO

ISTRUZIONI PER L’USO

UNIDAD DE CONTROL REMOTO

MANUAL DE INSTRUCCIONES

UNIDADE DE CONTROLO REMOTO

MANUAL DE INSTRUÇÕES

遥控器

使用说明书

B64-4632-0000KNA-RCDV331.indb1 09.11.1010:46:52AM

2 KNA-RCDV331

KNA-RCDV331

This unit cannot control the function that isn't included in the car audio.

• Put the Remote Controller in a place where it will not move during braking or other operations. A dangerous situation could

result, if the Remote Controller falls down and gets wedged under the pedals while driving.

• Do not place the battery near an open flame or heat source. This may cause the battery to explode.

• Do not recharge, short, break up or heat the battery or place it in an open fire. Such actions may cause the battery to leak

fluid. If spilled fluid comes in contact with your eyes or on clothing, immediately rinse with water and consult a physician.

• Place the battery out of reach of children. In the unlikely event that a child swallows the battery, immediately consult a

physician.

• Do not set the remote on hot places such as on the dashboard.

Battery installation

Use two "AAA"/"R03"-size batteries.

Slide the cover while pressing downwards to

remove it as illustrated.

Insert the batteries with the +and -poles

aligned properly, following the illustration inside

the case.

⁄

• If the Remote Controller operates only over shorter

distances or does not operate at all, it is possible that

the batteries are depleted. In such instances, replace the

both batteries with new ones.

Remote Controller mode switch

The functions operated from the remote

controller differ depending on the position of the

mode switch.

DVD mode

Switch to this mode when playing

DVDs or CDs etc. with the player

integrated in this unit.

AUD mode

Switch to this mode when

controlling a selected source or a

CD changer etc.

NAVI mode

This is switched when controlling

Navigation unit.

TV mode

This is switched when controlling

TV.

⁄

• The position of the remote control mode switch is

indicated in the title of each mode, e.g., "(AUD mode)".

• When controlling a player that is not integrated in the

unit, select "AUD" mode.

B64-4632-0000KNA-RCDV331.indb2 09.11.1010:46:52AM

English 3

Common operations (AUD mode)

Source switching

Switches to the source to be played.

Volume control

Adjusts the volume.

Volume attenuator

Press the key once to lower the volume. Press again

to restore the previous volume.

Dual Zone

Switches the Dual Zone function ON and OFF.

Rear volume control

Adjusts volume at rear when the Dual Zone

function is ON.

V.SEL

Switch video

Switches the video each time it is pressed.

Display angle (DDX)

Switches the display angle each time it is pressed.

OPEN (KVT)

Opens or closes the monitor each time it is pressed.

Cursor key

Moves the cursor when displaying menu.

ENTER

Enters options.

Hands-free communication

When a call comes in, it answers the call.

Function

Switches the function screen.

MODE

Switches the screen mode.

Screen mode changes each time you press this key.

B64-4632-0000KNA-RCDV331.indb3 09.11.1010:46:52AM

4 KNA-RCDV331

DVD/DVD Audio/VCD/CD/Audio files

(DVD mode)

Folder search

Selects the folder to be played.

Track search and file search

Selects the track or file to be played.

Play/Pause

Pauses the track.

Press again to resume playing.

Stop

Memorizes the last point where the disc stopped.

When pressed again, the last point is deleted.

Direct search

Pressing this button switches the features that can

be searched directly.

DVD

Title number

Chapter number

Play time

Item number*

Cancel

* You may not be able to use this function with some discs

or scenes.

Radio (AUD mode)

Band switching

Switches to bands received by the unit.

Station selection

Switches to broadcast stations received by the unit.

Seek mode switching

Switches the Seek mode (AUTO1, AUTO2, MANU).

Direct tuning

After pressing this key, use the keypad to specify

the broadcast station you wish to receive.

Example: 92.1MHz (FM)

WXYZ

2ABC

➜or

Example: 810kHz (AM)

8TUV

➜or

Numeric keypad

• To use preset tuning, press the number of a

programmed broadcast station. (

–

MNO )

• Press the direct tuning key first, then specify the

frequency of the station to receive.

KNA-RCDV331

B64-4632-0000KNA-RCDV331.indb4 09.11.1010:46:54AM

English 5

DVD Audio

Group number

Track number

Item number*

Cancel

* You may not be able to use this function with some discs

or scenes.

Track number

Play time

Cancel

Audio files

Folder number

File number

Cancel

VCD 1.X, VCD 2.X (PBC OFF)

Track number

Cancel

VCD 2.X (PBC ON)

Scene number

Number

Cancel

Once you have switched to the direct search

feature, specify the search number from the

numeric keypad, and then press [ENTER] key.

Numeric keypad

• Specify the number to search in direct search.

• Press

2ABC

to fast forward/backward.

Switches the fast forward/backward speed each

time you press this key.

• Press

4GHI

5JKL

to slow forward/backward.

Switches the slow playback speed each time you

press this key.

DVD Top Menu

Returns to the DVD top menu.

DVD Menu

Displays the DVD menu.

Turns the playback control on or off while playing

VCD.

Subtitle

Switches the subtitle language.

Zoom

Switches the zoom ratio each time you press this

key.

Picture Angle

Switches the picture angle each time you press this

key.

AUDIO

Switch Voice Language

Switches the voice language each time you press

this key.

B64-4632-0000KNA-RCDV331.indb5 09.11.1010:46:56AM

6 KNA-RCDV331

KNA-RCDV331

iPod (AUD mode)

Music/Video search

Selects the music/video to be played.

Play/Pause

Pauses the music/video.

Press again to resume playing.

USB (AUD mode)

Folder search

Selects the folder to be played.

File search

Selects the file to be played.

Play/Pause

Pauses the file.

Press again to resume playing.

TV (TV mode)

Switching Band/Video

Switches between the station of the TV band to

receive and video input.

Channel Selection

Selects the TV channel to be received.

Direct tuning

(Function of NTSC TV type only)

Press this key first, and then specify the station to

receive with the numeric keypad.

Example: In case of Channel 6 (2-digit)

MNO

Numeric keypad

• The number of the memorized station is

selected. (

–

MNO )

• Press the direct tuning key first, then specify the

channel of the station to receive.

B64-4632-0000KNA-RCDV331.indb6 09.11.1010:46:57AM

English 7

NAVI (NAVI mode)

Cursor key

Scrolls the map, or moves the cursor.

ENTER

Performs the selected function.

Zoom

Zooms in or out the navigation map.

Displays Main menu.

CANCEL

Displays previous screen.

POSITION

Displays the current position.

ROUTEM

Displays Route Option menu.

VIEW

Switches between 2D and 3D map displays.

VOICE

Plays Voice guidance.

MAP DIR

Switches between the heading up navigation and

north up navigation map displays.

Hands-free communication

When a call comes in, it answers the call.

B64-4632-0000KNA-RCDV331.indb7 09.11.1010:46:58AM

U.S.A. only

FCC WARNING

This equipment may generate or use radio

frequency energy. Changes or modifications to

this equipment may cause harmful interference

unless the modifications are expressly approved

in the instruction manual. The user could lose

the authority to operate this equipment if an

unauthorized change or modification is made.

FCC NOTE

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment may cause harmful

interference to radio communications, if it is

not installed and used in accordance with the

instructions. However, there is no guarantee

that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which

can be determined by turning the equipment off

and on, the user is encouraged to try to correct

the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a

circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV

technician for help.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC

RULES. OPERATION IS SUBJECT TO THE FOLLOWING

TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL

INTERFERENCE, AND

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE

RECEIVED, INCLUDING INTERFERENCE THAT MAY

CAUSE UNDESIRED OPERATION.

B64-4632-0000KNA-RCDV331.indb53 09.11.1010:48:05AM
